- Page 1 F800W Indoor Safety Access Thermometer Installation manual Shenzhen Ophelia Technology Co. Ltd.
- Page 2 Declaration Thank you very much for purchasing our products, if you have any questions or need, please feel free to contact us. We have tried our best to ensure the completeness and accuracy of the contents of the document, but there are still some technical inaccuracies, discrepancies with the function and operation of the product or printing errors, in case of any doubt or dispute, please subject to our final explanation.
-
Page 3: Product Overview
Product Overview F800W intelligent terminal is a convenient and safe temperature measuring terminal for visual face recognition. The product can be applied to the traffic scene of intelligent community, access control channel, face attendance, hotel, office building, school, shopping mall and so on, which is helpful to realize intelligent safety control. -
Page 4: Product Characteristics
Product characteristics Using non-contact matrix to obtain measured temperature • A self-developed temperature algorithm to achieve accurate temperature measurement ,1 S rapid • temperature measurement Support Binocular In vivo Detection Support for Human Motion Face Tracking Exposure in Strong Inverse •... -
Page 5: Hardware Specifications
Hardware specifications Name Specificatin/model Note Hi3516DV300 Hayes 3516 DV300 Systems Linux Double MiPi Sensor Quantity :2 Camera pixels :200 W White Light Lamp Infrared Light Display screen IPS screen 8 inches 800*1280 WIFI Support Bluetooth Support Net access Support 8Ω1W Speakers Network 10/100/1000 Mbps Ethernet (support POE+ power supply) - Page 6 1. Gate Installation T e mperature m easurement m odule White Light Lamp C a mera s t and t ype s upport D i splay s creen C r edit c ard a rea g r ip n ut...
- Page 7 1.1 Installation Steps and Schematic Schemes A round hole of 32 mm is opened at the gate position as shown; through all wire locking nuts; Connect according to electrical wiring mode; P o r t connection I D c ard reader n etwork port C o n tact Point of N e t work Open Door...
- Page 8 1.2 Electrical wiring From the top down for the relay often on, power, network cable. Wiring photos Interface definition Serialnumber Name Number Remarks Network RJ45 Power supply DC12V IN USB2.0 KZ_OUT +NO KZ_OUT - Switch output ① VCC 12V ② Wegan Protocol Input Interface ③...
-
Page 9: Wall Mount
2. wall mount f i x s crew T e mperature m easurement m odule W h ite L ight L amp C a mera W a ll m ount s upport D i splay s creen f i x s crew C r edit c ard a rea... - Page 10 2.1 Installation Steps and Schematic Schemes Attach the positioning film to the installation equipment position and open the hole according to the positioning film position Electrical wiring mode good wiring: Remove the positioning film, wire through the back hole with M3*20mm screws fixed the machine;...
- Page 11 2.1 Installation Steps and Schematic Schemes...
- Page 12 2.2 Electrical wiring From the top down for the relay often on, power, network cable. Wiring photos Interface definition Serial number Name Number Remarks Network RJ45 Power supply DC12V IN USB2.0 KZ_OUT +NO Switch output KZ_OUT -COM ① VCC 12V Wegan Protocol ②...
-
Page 13: Equipment Start-Up
3. equipment start-up After the equipment is plugged into the power supply, the software starts itself; 4. recommended installation environment Equipment for indoor use only, should avoid direct sunlight, avoid wind; Application temperature :10~50 degrees Celsius; Recommended installation height of 1.5 m, specific can be adjusted according to the actual situation; Better to keep the ambient light intensity above 100 lux;... - Page 14 5. FAQ treatment 5.1 Equipment unable to start or crash If the equipment can not start up, check whether the positive and negative poles of the equipment power supply are connected back or whether the input voltage is insufficient, it is recommended to use DC 12V/2A, Note that too long wiring length will affect the input voltage; When the device is unable to perform an exit or termination operation, power it up reset and restart by cutting off and switching it on again.
- Page 15 5. FAQ treatment 5.3 Gate not open Check whether the network connection is normal, re-plug; Check whether the Wigan signal line is connected properly and re-plug;...
- Page 16 6. considerations ▲ do not immerse the machine in water in whole or in part separately to avoid damage to the equipment; ▲ this machine is absolutely not allowed to move or vibrate violently while working; ▲ please pay attention to switch the machine according to the normal steps to prolong the machine life; ▲...
- Page 17 6. considerations ▲Do not soak all or part of the machine in water alone to avoid damage to the equipment; ▲The machine is absolutely not allowed to move or violent vibration; ▲Please pay attention to switch the machine according to the normal steps to extend the machine life; ▲Handle with care;...
