Matfer Bourgeat Precise BI-1000T User Manual

Induction range for buffet-line
Hide thumbs
1
2
3
4
5
6
7
8
9

Advertisement

Quick Links

Download this manual
Model No. BI-1000T
USER'S MANUAL
MODEL NO.: BI-1000T
INDUCTION RANGE
FOR BUFFET-LINE (HOLDING)
June 2011
Page 1 / 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the Precise BI-1000T and is the answer not in the manual?

Questions and answers

Summary of Contents for Matfer Bourgeat Precise BI-1000T

  • Page 1 Model No. BI-1000T USER’S MANUAL MODEL NO.: BI-1000T INDUCTION RANGE FOR BUFFET-LINE (HOLDING) June 2011 Page 1 / 9...
  • Page 2 Model No. BI-1000T USE AND CARE INSTRUCTIONS – IMPORTANT SAFEGUARDS READ ALL INSTRUCTIONS BEFORE OPERATION Use an individual 220volt~240volt electrical socket. DO NOT connect more than 3 units in the same power-resource if it’s connected to a 15A power-socket. DO NOT block the air-intake panel, blocking it may cause overheating of the unit. Use pans 12cm or larger in diameter.
  • Page 3 Model No. BI-1000T SUITABLE USTENSILS- FOR INDUCTION HEATING PLATES, SUITABLE POTS, 1. Iron 2. Cast iron 3. Stainless steel 4. Enamelware All pots and pans must have a magnetic bottom. All pots and pans must have a flat bottom. All pots and pans should have a diameter between 12cm (4 ”) and 24cm (10”).

  • Page 4: Safety Device

    Model No. BI-1000T SAFETY DEVICE Automatic Safety Shut-Off, If the induction range is left on for more than 60 seconds without a pan or with an incompatible pan, the unit will automatically shut off. Material Compatibility Detector If the pan’s material or it’s dimensions are not suitable for this induction range, the “Heating” indicator light will not light on.
  • Page 5 Model No. BI-1000T PRECAUTION BEFORE USING YOUR INDUCTION HOB 1. In case of breakage on glass-top, even if it's only slightly cracked, disconnect the appliance from the mains immediately and contact the after-sales service. 2. The appliances is equipped with 'small object detector'. But, it's recommended not to place metal kitchen utensils, pan lids, knives, or other metal objects on the induction heating zone.
  • Page 6 Model No. BI-1000T OPERATION INSTRUCTION 1. Plug power cord into 220volt~240volt power socket. 2. Place a suitable pot/pan on center position of top plate. 3. Turn on power by pressing the on/off key, digital-display will display will light on and show “0” 4.
  • Page 7 Model No. BI-1000T How to set-up, Place induction server on adapter, Place the control panel on the pocket, Place chafing dish on the glass-top, Push on/off button to activate, Push "High" button to select higher temperature setting, The unit will flash "H1" to explain it's set-up at H1 level. If the temperature isn't high enough, Please push "High"...
  • Page 8 Model No. BI-1000T Model# BI-1000T Table cut off size: 298 mm x 295 mm Control box cut off size: 55mm (H) x 120mm (W) Air In-Take Hole: 55(H) x 160 (W) mm Air Out-Take Hole: 55(H) x 280 (W) mm June 2011 Page 8 / 9...

  • Page 9: Specification

    Model No. BI-1000T SPECIFICATION: Model No. BI-1000T Voltage 220volt~240volt 50/60Hz Ceramic Top Plate Approx. 360*380mm Electrical Power Consumption Max. 1000w Safety Device Automatic Safety Shut-Off Material Compatibility Detector Small Object Detector Overheating Protection Device Remark: The switching frequency is verified by different power setting, it’s to be between 20 ~ 35 K Hz.
