Summary of Contents for Media Technologies Brick-HD
- Page 1 Brick-HD Video Wall Processor Product User Guide Media Technologies...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ..............................3 INSTALLING THE CONTROL SOFTWARE......................3 CONTROL USING RS232 ............................4 BRICK-HD IP NETWORK CONFIGURATION....................5 BRICK-HD CONTROL VIA IP ..........................6 VIDEO INPUTS ................................7 VIDEO OUTPUTS ..............................8 ALIGNING THE VIDEO WALL IMAGE ......................9 CONTROL SCRIPTS............................. 11 SAFETY / SEGURIDAD ............................ 15 COMPLIANCE .............................. -
Page 3: Introduction
The control software requires a connection to the Brick-HD. This can be either RS232 via a PC COM port, or via a network using the Ethernet port. The COM port is easier to set up. Also if the processor is initially connected via a serial port it will simplify the network configuration process. -
Page 4: Control Using Rs232
In this mode, the IP address of the Brick-HD will be determined via the serial connection, so there is no need to further configure the PC software. It is necessary to enable IP communication on the Brick-HD however. -
Page 5: Brick-Hd Ip Network Configuration
4 Brick-HD IP NETWORK CONFIGURATION The processor network port is permanently enabled. It will auto-configure for 10/100BaseT and auto-sense the connection direction. It is not necessary to use a cross-over cable to connect the network port directly to a network port on a PC. The status of the Ethernet connection can be viewed from the front panel display. -
Page 6: Brick-Hd Control Via Ip
5 Brick-HD CONTROL VIA IP The Brick-HD must be configured for IP communication before attempting to connect to it using the PC control software. The easiest way of doing this is as described in the previous section. If there is no PC with a serial port available it is still possible to set-up the processors network interface. -
Page 7: Video Inputs
The Standard Definition (SD) buttons are greyed out since current versions of firmware do not yet support any SD video formats via the Composite/S-Video inputs. IMPORTANT Select SAVE to configure the processor to use these values as power-up defaults. © Copyright Media Technologies 2011 Page 7 of 18... -
Page 8: Video Outputs
"configure unit" box. To configure all units the same, using unit 0 as the master use the "*" select all button. IMPORTANT Select SAVE to configure the processor to use these values as power-up defaults. © Copyright Media Technologies 2011 Page 8 of 18... -
Page 9: Aligning The Video Wall Image
Click on apply to try the values or click OK, to apply and exit from the dialog. To position the image, select Pan and use the sliders to move the image Up/Down and Left/Right. © Copyright Media Technologies 2011 Page 9 of 18... - Page 10 Channels can also be mapped dynamically as part of a timed sequence script to create effects. IMPORTANT When you have finished mapping the channels click on SAVE MAP in the channel mapping to ensure the new map is applied on power up. © Copyright Media Technologies 2011 Page 10 of 18...
-
Page 11: Control Scripts
To exit from the dialog box click Done. If changes to the project have been made you will be prompted to save these changes. If this request is cancelled the button dialog will remain, If the answer is No, changes since the last save are lost. © Copyright Media Technologies 2011 Page 11 of 18... - Page 12 In a multi-processor installation, sequence files are generally only installed on processor with ID = 0. Messages in the downloaded sequence intended for slave processors are sent by processor 0 to the © Copyright Media Technologies 2011 Page 12 of 18...
- Page 13 Stop. There is no need so select a specific sequence file to stop a running sequence. To delete a downloaded sequence file, select the line containing it and click Delete. © Copyright Media Technologies 2011 Page 13 of 18...
- Page 14 Char field will be blank. Files mapped to ASCII characters in the range 0..9 (decimal 48 to 51) can be invoked using the Sequence Keypad dialog or from the front panel display. © Copyright Media Technologies 2011 Page 14 of 18...
-
Page 15: Safety / Seguridad
NO intento de verificar la seguridad eléctrica utilizando cualquiera de los conectores de vídeo o de control o de fijación o conectores de la unidad dañada y será anulada la garantía. © Copyright Media Technologies 2011 Page 15 of 18... -
Page 16: Compliance
Contact your supplier and check the terms and conditions of your purchase contract to ensure this product is not mixed with other commercial waste for disposal. © Copyright Media Technologies 2011 Page 16 of 18... -
Page 17: Specification
Future software release : two independent sources displayed simultaneously. Video Outputs Up to 16 monitors - use multiple Brick-HD processors to build larger video walls. 16x Analog outputs (via DVI connector): Component, Composite-video, S-video. 16x DVI outputs (HDCP not supported). - Page 18 The information in this document is believed to be accurate in all respects at the time of printing, but is subject to change without notice. Media Technologies assumes no responsibility for any errors or omissions, and disclaims responsibility for any consequences resulting from the use of the information included herein.
