- Page 1 V E R S I O N 2 . 0 A U G U S T 2 0 2 1 HVA1500/50 User Manual Version 2.0...
-
Page 2: Table Of Contents
3. INSPECtion & Installation ..........Page6 3.1 What comes with thE HVA1500/50 ....Page6 3.2 incoming inspection ......Page6 3.3 INSTALLation . -
Page 3: Safety Instructions And Symbols Read First
HVA 1500/50 User Manual V2.0 1. Safety Instructions AND Symbols READ First To ensure safe operation and to keep the operator and the product safe, THE INFORMATION, CAUTIONS, AND WARNINGS IN THIS MANUAL MUST BE HEEDED. WARNING – WARNING STATEMENTS AND SYMBOLS IDENTIFY CONDITIONS OR PRACTICES THAT COULD RESULT IN INJURY OR LOSS OF LIFE. - Page 4 HVA 1500/50 User Manual V2.0 Before removing the cables from the load, switch off the amplifier and wait at least 10 minutes until the load capacitors are discharged. Never operate the high voltage amplifier if any housing part of the unit is defective or removed.
-
Page 5: Overview
HVA 1500/50 User Manual V2.0 2. Overview The HVA1500/50 is a single channel, high voltage power amplifier. The power amplifier is capable of delivering an output voltage in the range of -500 V to +1500 V with an output current of up to 50 mA DC. -
Page 6: Inspection & Installation
3. INSPECtion & Installation This section provides information for incoming inspection, damage claims, shipping, and installation of the HVA1500/50. 3.1 What comes with thE HVA1500/50 The HVA1500/50 package contains the following items: • Single channel high voltage amplifier unit HVA 1500/50, •... -
Page 7: Specifications
HVA 1500/50 User Manual V2.0 4. SPecifications 4.1 General Specifications The HVA1500/50 is designed to be operated as a high voltage power supply for the MFC, P1 type products. 90-264VAC, 47-63 Hz, 150VA AC Power supply Slow fuse 1.6A Standard three prong connector Ambient Temperature 0°C to 40°C... -
Page 8: Wave Generator Input
HVA 1500/50 User Manual V2.0 4.3 Wave Generator Input -2.5 V to +7.5 V, Input Voltage Range corresponds to -500 V to +1500 V output Input Resistance 100 kOhm Signal Frequency Range 0 Hz to 10 kHz Input Connector BNC coaxial connector 4.4 audio signal input Input Voltage Range 0.2 V to 3 V AC... -
Page 9: Interlock
HVA 1500/50 User Manual V2.0 4.8 interlock The output voltage is turned on only if the Function interlock signal is closed , i.e. pin 1 and pin 2 of the interlock connector are connected together Interlock Connector A 3-pole socket on the rear panel Pin 1: output signal, +5 V Signals Pin 2: input signal, i.e. -
Page 10: Operation
This section outlines the general procedure for operating the high voltage amplifier and the load. For more operating information, see also the manual for any used piezo actuators. 5.1 Front Panel controls Fig 2: HVA1500/50 front panel Power Toggle Switch Turns the power supply on and off. - Page 11 HVA 1500/50 User Manual V2.0 This indicator illuminates if the output voltage is turned on by the rotary HV On switch in the In/Out Control section and by the external interlock signal. This indicator illuminates if the output Limit voltage or current exceeds the limits Monitors This output signal monitors the high voltage at the output.
-
Page 12: Rear Panel Controls
HVA 1500/50 User Manual V2.0 5.2 Rear panel controls Fig 3: HVA1500/50 rear panel Connector International standard three-wire connector Line Line Voltage 90-264VAC, 47-63 Hz Voltage Input Power 150VA Fuse Two 1.6A slow blow fuses Ground Function Allows the grounding of the unit... -
Page 13: Operational Requirements
HVA 1500/50 User Manual V2.0 5.3 Operational requirements Before making any connections, make sure that the amplifier unit is turned off. • Connect the amplifier unit to the mains. • Connect the high voltage output connector of the amplifier to the load. -
Page 14: Further Resources
© Smart Material Corp. and Smart Material GmbH All rights reserved. No part of this manual may be reproduced without the prior permission of Smart Material Corporation. This document is for the instructional use of the HVA1500/50. Please read carefully before using the equipment. - Page 15 HVA 1500/50 User Manual V2.0 In Memory of Dr. Hooshang Tehrani The designer and creator of the HVA1500 and the microHVA-2 High Voltage Amplifier series. The founder of Physical Instruments. An exceptional engineer. P a g e 1 5 h t t p s : // w w w . s m a r t - m a t e r i a l . c o m...
-
Page 16: Limited Warranty
HVA 1500/50 User Manual V2.0 6.2 limited Warranty Seller warrants to the Buyer that, for a period of eighteen (18) months from the date of delivery of the Product(s) by Seller to a commercial carrier, the Product(s) will conform to Seller’s stated specifications and be free from defects in workmanship and materials. - Page 17 Governing Law; Jurisdiction/Venue. These Terms shall be governed by, and construed in accordance with, the laws of the State of Florida, U.S.A. if the unit is sold by Smart Material Corp., the laws of Germany if the unit is sold by Smart Material GmbH without reference to conflicts of law principles.
