Quick Start Guide
Version TP5.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the JetChill Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Acoura JetChill Pro

  • Page 1 Quick Start Guide Version TP5.0...
  • Page 2 JETCHILL PRODUCT SPEC - Pro Machine SPECIFICATIONS: Operation: Automatic Material: Styrene casing, PETG body, Steel/Brass/Aluminium Plastic components Size: 40cm x 20 x 20 (16" x 8" x 8") Total Weight: 5kg (11lb) Handle Adjustable for Cocktail/Shot Glass Lid Stand Handle Stand Removable Probe Nipple...
  • Page 3 JETCHILL PRODUCT SPEC - Pro Machine Product Spec Image British Standard BS 341 Part 1 No. 8 CYLINDER HOSE (Universal) USA CGA 320 POWER SUPPLY 100-240V 2.5A (Universal) CYLINDER STRAP 1M (3.3ft) Velcro CYLINDER HOSE 25mm (0.98”) CONNECTION 15mm (0.59”) WRENCH &...
  • Page 4 JETCHILL PRODUCT SPEC - Cocktail Glass SPECIFICATIONS: Material: Food grade polycarbonate (Wonderlite 110) Size: 19cm x 4 x 5 (7.5” x 1.6” x 2.0”) Volume: 200ml (7 oz) Total Weight: 50g (0.04lb) Warning: Not for use with Dry Ice pellets Body Durable and scratch resistant...
  • Page 5 JETCHILL PRODUCT SPEC – Shot-Tail Glass SPECIFICATIONS: Operation: Manual screw cap Material: Food grade polycarbonate (Wonderlite 110) Size: 19cm x 4 x 4 (7.5” x 1.6” x 1.6”) Volume: 125ml (4 oz) Total Weight: 80g (0.18lb) Warning: Not for use with Dry Ice pellets Body Delivery Pipe Centre Hole Durable and...
  • Page 6 JETCHILL PRODUCT SPEC - Shot Glass SPECIFICATIONS: Material: Food grade polycarbonate (Wonderlite 110) Size: 9cm x 4 x 4 (3.5” x 1.6” x 1.6”) Volume: 50ml (2 oz) Total Weight: 20g (0.04lb) Warning: Not for use with Dry Ice pellets Body Durable and scratch resistant...
  • Page 7 QUICK START GUIDE – Pre Use STEP 1 • Ensure black Rubber O Ring is on the Cylinder End of the Cylinder Hose • Replacement O Rings supplied in Tool Kit, contact JetChill additional replacement O Rings STEP 2 • Hand screw UK Cylinder Hose clockwise tight, onto Cylinder of Food Grade Liquid Co2 (with Dip Tube)
  • Page 8 QUICK START GUIDE – STEP 5 • Place two dry JetChill Glasses on Machine Probes and ensure Glasses locate correctly on Probe Nipples • Turn Handle down over Glasses, close Lid and press NORMAL Charge Button once to prime Gas through Machine STEP 6 •...
  • Page 9 QUICK START GUIDE – Post Use STEP 9 • To change Cylinder or at end of session use, close Cylinder Valve by hand turning valve 90 degrees clockwise STEP 10 • Press NORMAL Charge Button once to purge Gas through Machine STEP 11 •...
