Summary of Contents for fybots Sweep XL
- Page 1 User Manual...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY WARNINGS SWEEPXL ET FY-DOCK FY-REMOTE FY-MONITOR MAINTENANCE WARENTY CONTACT... -
Page 3: Safety Warnings
- Do not enter the Fy-dock while the system is being operated SWEEP XL - Never lean on/get on top of the robot - Do not use the robot for transporting objects - Do not move or raise the robot with a machine (ex: forklift) -
Page 4: Sweepxl Et Fy-Dock
- Moving the robot should only be done with the remote control or fybot app, the last resort would be to gently push the robot using your hands. - Avoid contact with water on the robot - For maintenance actions, only disassembly of the red colored screws is allowed Do not clean the robot with a high pressure machine SWEEP-XL... - Page 5 1 – TURNING LIGHT 2 – ULTRASONIC SENSOR 3 – CAMERA 4 – TRUNK SCREW 5 – EMERGENCY STOP 6 – HEADLIGHT 7 – TURN SIGNAL 8 – CHARGE PLATE 9 – NEXT BUTTON 10 – RETURN BUTTON 11 – STATUS LED...
- Page 6 1 – CHARGING 4 – EMERGENCY STOP CONTACTOR 2 – STATUS LIGHT 2 – SWEEP-XL 3 - SHOVEL TRASH BIN...
-
Page 7: Fy-Remote
FY-REMOTE RADIO REMOTE... - Page 8 Sweep XL can be controlled using the radio remote control or the dedicated and preinstalled application on the tablet provided with the robot The radio remote control allows you to simply move the robot, it does not allow any settings of the SweepXL...
- Page 9 ON /OFF SWITCH Turns the radio remote control on or off. STEERING WHEEL Turn the wheel to give an orientation to the SweepXL.
- Page 10 POWER JOYSTICK Gives the speed and sense to the SweepXL. DIRECTION JOYSTICK Gives the direction to follow to the SweepXL. SWEEP XL MODES Robot mode: • AUTO: Standard mode of the SweepXL, it executes the missions programmed in the fy-Monitor, returns to the fy-dock to empty and reloads automatically.
-
Page 11: Fy-Monitor
FY-MONITOR... - Page 12 The Fy-monitor is an online tool that allows you to configure and track the activity of the robot http://www.fybots.com/espace-client/...
- Page 13 SUPPORT Hotline and technical support. ROBOT IN List of all robots in operation. OPERATION LOCALISATION Map showing the position of your robots in operation. IDENTIFICATION Area where you can find the serial number of the robot, its name and the latest alerts. OPTION List of options in use on the robot.
- Page 14 CREATION DES MISSIONS ET VISUALISATION DES RAPPORTS :...
- Page 15 SCHEDULE List of all SweepXL missions you have created. ACTIVATE / DEACTIVATE Click on the icon to activate or deactivate ROBOTS MISSION an already registered mission. MISSION MODIFICATION Click on the gear to modify an existing mission (times and zone). DELETE Click on the trash to delete an existing mission.
-
Page 16: Maintenance
MAINTENANCE In order for the robot to clean efficiently and to avoid abnormal wear of its cleaning systems it is necessary to maintain them regularly. Refer to the "SweepXL Cleaning Systems Maintenance" document for maintenance procedures and access to cleaning systems. •... - Page 17 The contract does not extend to cases of hardware malfunction caused by: • o Any changes made by people not mandated by FYBOTS o Neither in cases of defects or deteriorations caused by the bad state of the premises and / or not due to the use and / or the normal wear of the...
-
Page 18: Contact
To contact us, you will find in the fy-monitor, on the left banner, a button "Customer Service" You can also contact us by mail or phone: contact@fybots.com Phone (FR) : +33 (0)1 61 38 16 35 Phone (US) : 971 . 303 . 1515...
