Hydra Monoski

Owner's Manual

Version 2021-22

DynAccess Ltd

301 Broadway STE 114

Bethlehem, Pennsylvania 18015

info@dynaccessltd.com

USA

- tel. 484-767 0477

Table of Contents

Need help?

Do you have a question about the Hydra Monoski and is the answer not in the manual?

Questions and answers

Summary of Contents for DynAccess Hydra Monoski

Page 1: Table Of Contents
Table of Contents Introduction……………………...2 Safety First…………………………2 General Description……………4 Hydra Monoski Instructions…………………………6 Owner’s Manual Mounting the Seat…………6 Version 2021-22 Mounting Bindings………..7 Installing Monoski………….7 Sitting in the Seat ………….8 Adjusting the Foot Rest… 9 Buckling Your Belt………….9 The Shock……………………..12 Using the Lift………………..13 Evacuation…………………….15...
Page 2: Introduction
Introduction Thank you for purchasing a DynAccess Hydra monoski. We appreciate your business and are committed to providing you with not only a quality product, but also excellent service. The following pages will provide you with basic information for your new monoski. Upon receiving your monoski, read the information below and become familiar with your monoski.
Page 3 recommend you take it to a specialized workshop or contact us directly before riding. ➢ For fitting you in the bucket seat, see p.9 ➢ For footrest adjustment, see p.9 ➢ For adjusting the center of gravity, see p.8 ➢ For adjusting the ride height, spring rate, rebound and compression damping, please see the separate Shock Manual.
Page 4: General Description
➢ Pay attention to the snow conditions, which affects your ride significantly. National Ski Areas Association “Your Responsibility Code”: DynAccess is a member of the Rehabilitation Engineering and Assistive Technology Society of North America (RESNA). As a provider of adaptive sports equipment, we ask that you abide by...
Page 5 Various seat buckets can be mounted on the Hydra, including DynAccess' thermoformed bucket seat complete with seat belts and bucket straps. A photo below is that of Aspen Seating/Ride Design’s bucket. A. Lap Belt B. Bucket Seat C. Ratcheting thigh belt D.
Page 6: Instructions
“Loctite”, nuts and bolts can be reused with new thread locking compound applied. Caution! Please be advised that some non-DynAccess Seats are not optimal for the Hydra and mounting such a seat on the Hydra may result in serious injury or death. Mounting bindings and optional binding blocking set: The DynAccess Hydra can be fitted to the snow ski using conventional high-strength bindings.
Page 7 DynAccess offers a “blocking set” designed to fit the following bindings: Marker Comp 20 or 30 bindings, Marker Race Xcell/Xcomp 24, Head Freeflex Evo 20 X RD /Fischer RC 4 Z 20X Race Freeflex Bindings, and Atomic EGA X20 bindings. The blocking set consists of a front blocking plate and a rear block with a locking pin.
Page 8 5. Check to ensure that the foot has locked properly into the bindings. 6. Many programs and skiers pin the front binding and block the rear binding such that they cannot release. Adjusting the Center of Gravity (COG): The standard setting of the Hydra is in the center, from which the skier can move 3" (75mm) forward or 3"...
Page 9: Sitting In The Seat
To change the center of gravity: 1. Lay the monoski on its side. 2. Locate the two bolts connecting the foot tower to the foot. 3. Remove the two bolts, and put them and the six washer in a safe place. You may need to loosen the bolts just above the removed bolts to release the pressure.
Page 10: Adjusting The Footrest
Adjusting the Footrest: You can adjust the height of the monoski’s footrest. To do this: Locate the two long ¼” bolts attaching the footrest to the frame. Remove the bolts, nuts and spacers. Put them in a safe place. Note that there are O-rings in the spacers. Move the footrest up or down as desired and center it with the proper holes.
Page 11: The Shock
There is quite a range of adjustment possibilities. Your shock is equipped with either a single coil spring or dual coil springs. Your springs have been carefully selected by DynAccess based on the information provided by you. You can easily...
Page 12 adjust preload, rebound damping and high/low speed compression damping of your shock. With some more effort you can change spring rate(s) and crossover point of a dual rate spring setup. For adjusting your shock, please refer to the Shock Manual. Using the Chairlift The standard Hydra is not equipped with a lift mechanism.
Page 13 When using a chairlift: 1. Inform the lift attendants if you have any specific needs. They can slow down or stop the chair if desired. 2. Position your outriggers upright at your sides. As the chair approaches, push down on your outriggers to lift yourself up and back onto the seat.
Page 14: Evacuation
DynAccess uses a three-point evacuation strap system to distribute the weight from the rider and rig in the event of an evacuation. Three separate straps are currently used for the evacuation system.
Page 15: Maintenance And Service
All belts (seat belts, evacuation straps, etc.) should be replaced at least once every year. DynAccess recommends having the monoski professionally serviced once per year. DynAccess can check the monoski, replace worn hardware (bearings, rod ends, nuts and bolts, etc), repair any damage, and service the shock.
Page 16: Warranty
This warranty applies only to the product’s original owner and is non-transferrable. DynAccess Ltd. will, at its discretion, repair or replace any component that is deemed to be defective. DynAccess Ltd. is not responsible for the transportation or shipment costs associated with transporting the product to be repaired.
