quartersandcraft.com
Model No.QCLATCB
ATTENTION
Make sure all bolts, screws and other fasteners are fully tightened before use. Lubricate all moveing parts
and tighten all bolts/screws/other fasteners every 6 months or whenever needed.
WARNIN G !
To ensure proper assembly, follow all steps and use all parts. Failure to follow this warning can result
in serious injury to yourself or others.
1 of 6
Advertisement
Related Manuals for QUARTERS & CRAFT QCLATCB
Summary of Contents for QUARTERS & CRAFT QCLATCB
- Page 1 Model No.QCLATCB ATTENTION Make sure all bolts, screws and other fasteners are fully tightened before use. Lubricate all moveing parts and tighten all bolts/screws/other fasteners every 6 months or whenever needed. WARNIN G ! To ensure proper assembly, follow all steps and use all parts. Failure to follow this warning can result in serious injury to yourself or others.
- Page 2 Counter weight color may be different from the lateral color D. Length 35 mm ×15（1 for Spare ) ×27（1 for Spare ) ×27（1 for Spare ) ×41（1 for Spare ) E. Length 35 mm ×4 × 4 × 8 Hardware assembly instruction ※Put in “B”...
- Page 3 Step 2-1 Step 2-2 Step 3 X 12 Step 4 3 of 6...
- Page 4 Step 5 Step 6 Step 7 Step 8 4 of 6...
-
Page 5: Drawer Installation
Step 9 The installation steps for the two drawers are the same. Step 10 Drawer installation. Install the drawers one by one, Do NOT install two drawers at once. Step 11 When install the second drawer, please make sure the first drawer is closed completely! 5 of 6... - Page 6 Step 12 Step 13 Drawer Removal (You can follow this instruction to remove the drawer if it is needed) Press up the lever on the left slide and press down the lever on the right slide to disengage the slides. And then you can pull the drawer out.
