MicroRocker
Instruction Manual
© Magenta LLC. 2021
Using the Vessels
Vessels can be used like a Magenta box or other re-
usable vessel with semi-solid or with liquid
medium.
Always autoclave with the lids on and seal the
edges with 3M Micropore tape or similar sealing
film.
Setting Up the Rocker
There are three steps to prepare your rocker.
1. Cut off the zip-ties from the center block.
2. The toothed belt can become loose in shipping.
To tighten it, use the provided Hex Key to
loosen the screws holding the motor mount.
Pull the motor mount away from the center of
the machine so the rubber belt is pulled
taught. While holding pulling, re-tighten the
screws.
3. Turn the wheel counterclockwise. Ensure the
small switch clicks when the wheel reaches the
end. You should hear an audible click.
Advertisement
Summary of Contents for AGENTA WE VITRO MicroRocker
- Page 1 screws. MicroRocker Instruction Manual © Magenta LLC. 2021 3. Turn the wheel counterclockwise. Ensure the small switch clicks when the wheel reaches the end. You should hear an audible click. Using the Vessels Vessels can be used like a Magenta box or other re- usable vessel with semi-solid or with liquid medium.
- Page 2 Normal Rocking Mode The MicroRocker has two operation modes. The first is normal rocking – leave the settings at their defaults: Tilt Time 30 seconds Left Angle 35 degrees Place plants in the vessels, leaving a gap on one Right Angle 35 degrees side.
- Page 3 Example settings for Half Rocking are below: Screen Contrast Tilt Time 60 seconds If the LCD screen is difficult to see, you can adjust Left Angle 0 degrees the contrast. Use a small screwdriver to adjust the (immerse) small screw in the hole in the top left of the Right Angle 35 degrees electronics case.
