TieYak 97-6090 Manual

Optional Safety Straps are available to secure your Kayak/SUP in place if you have windy
conditions, earthquakes, kids or critters! Order from TieYak.com for $19.95 per set. Includes shipping.
Safety:
Before assembly please read complete manual.
•
Do not modify rack.
•
Do not allow children to play on the rack.
•
If possible secure rack to ground.
•
Inspect the rack as needed, making sure all connections are tight.
•
06/19
Kayak/SUP Storage Rack
Full assembly videos can be
found by visiting:
- TieYak.com
- YouTube.com and search "TieYak" channel
- Scan QR Code ->
TieYak.com
Model # 97-6090
Parts List
Qty Name
2 24" Base
2 24" Base Post
2 20" Base Leg
2 Post
4 3" Carriage Bolt
8 3/4" Hex Bolt
4 2-3/4" Hex Bolt
8 3-1/2" Hex Bolt
8 Lock Washer
8 Thick Washer
28 Washer
16 Lock Nut
6 Anchor
6 Leveling Foot
1 Cross-Bar End (Male)
1 Cross-Bar End (Female)
1 Cross-Bar Center
2 Cross-Bar Plate
4 Rack Arm
1 Wrench
Page 1
