Summary of Contents for Fairmount Tools 31471
- Page 1 Item #31471 10 TON HYDRAULIC GEAR PULLER INSTRUCTIONS...
- Page 2 The FAIRMOUNT 10 TON HYDRAULIC GEAR PULLER is designed for universal use with versatile 2 or 3 arm configurability. Reversible arm positing accommodates outside or inside pulls equally well. The self-contained Hydraulic Ram design provides greatly amplified pulling force. This tool, constructed of robust, high-strength steel alloy forgings, will provide years of reliable service.
- Page 3 SAFETY INFORMATION READ INSTRUCTIONS • Thoroughly read and understand these product instructions before using the Puller. • Keep these product instructions for future reference. IMPROPER MOTOR VEHICLE REPAIR WORK CAN RESULT IN INJURY OR DEATH! • Performing automotive repair work can cause injury, death and vehicle accidents.
- Page 4 PULLER ASSEMBLY Please note that this Puller can be configured many different ways. It is very important to first determine which configuration is best for the particular pulling application. Some of the variables are as follows: - 2 or 3 Puller Arm arrangement. - Inside or outside Puller Arm finger directions.
- Page 5 PULLER OPERATION Before attempting to pull an object, be sure it is of sufficient strength to withstand the forces of pulling. Be aware that cracking and breakage of valued components can and may occur. Only apply whatever turning force is available by hand when rotating the “T”...
- Page 6 Eastwood Technical Assistance: 800.544.5118 >> techelp@eastwood.com...
- Page 7 To order parts and supplies: 800.345.1178 >> eastwood.com...
- Page 8 ADDITIONAL ITEMS #70448 Eastwood 1/2” Twin Hammer Super Mini Air Impact Wrench #30169 Eastwood Low Profile 2 Ton Aluminum Floor Jack #31338 1/2” Micrometer Torque Wrench, 30-250 ft/lbs. If you have any questions about the use of this product, please contact The Eastwood Technical Assistance Service Department: 800.544.5118 >>...
