Summary of Contents for Paselec E-PAS GS9 Plus Series
- Page 1 I n t e t r i c e l e c PASELEC Bike Showroom & Service Center in Los Angeles US PASELEC Bike Shops Add.: ---Budd lake NJ 07828 US ---Orlando Florida 32824 US ---Las Vegas Nevada 89148 US Paselecbike service@paselecbike.com...
- Page 2 All the parts and accessories on the ebikes are the known brand, for example, Samsung battery. Every bike is fully inspected under QC standards. Paselec’s mission is to address all the customer issues in the fastest manner. All the issues or concerns will be...
- Page 3 Manual’s Page 04-07 08-09 E-PAS Assembling and Assembly Schematic Technology Adjustments 12-14 Usage guidance Battery charging and Troubleshooting maintenance 15-17 Warranty Return policy Maintenance cost policy 22-24 Service Maintenance & Safety Notes on cycling & Warranty & Disclaimer Range estimates www.paselec-ebikes.com...
- Page 4 Plus 6061 Intelligent Controller Aluminum Alloy 48v14.5AH 50-70 Alloy Lock-out suspension ７ 5 0 Mechanical disc brake...
-
Page 5: Product Specification
Product Specification E-BIKE: Pasele GS9 pluis series Frame: Paselec 27inch aluminum alloy frame Front suspension: Alloy suspension Brake：Mechanical Disc Brake Tire: CST 27.5"*4 Throttle Type: Thumb throttle E-DRIVE: 750W Speed: 18kmh to 24kmh depends on power, PAS level, load, terrain and weather. - Page 6 E·pas· Technology E-PAS Technology is a patented technology of Paselec , which has the characteristics of ultra-long mileage, energy saving loss, prolonging the service life of transmission system and so on.
-
Page 7: Adjustment Of The Front Derailleur
1. BIKE'S ASSEMBLING --------------------------------------------------- 1. take out a bicycle from the box and release him from packaging materials; 2. install the front wheel. Keep an eye so that direction is correspond with the direction of rotation of tires, properly use the quick release. -
Page 8: Rear Derailleur Adjustment
1.3 REAR DERAILLEUR ADJUSTMENT --------------------------------------------------- 1. before adjust the rear derailleur, make sure that element of the hang-er of rear derailleur isn"t distorted, and the frame with rollers parallel to the sur- face of sprockets of freewheel(pic. 15). 2. shift the right shifter to the "small sprocket" position, adjust cable tension bolt to the center position(pic.16) - Page 9 3. tighten the nut on the axle of quick release and fix the wheel at the turning point of the lever of quick release from the moment 20-30 Nm(pic.). 4. if you have on your bicycle V-Brakes after installing the wheel close brake levers and link inner cable guide(pic.4).
-
Page 10: Tire Inflation
1.8 TIRE INFLATION --------------------------------------------------- 1. before riding the bike inflate the tires to recommended pressure pointed out on the tires side. 2. use a pump that is suitable for your bike nipple. There are two main types of nipples: PRESTA valve and SCHRADER valve(pic.30). -
Page 11: Handlebar Installation
Handlebar installation Put the handlebar on the stem Move in the right direction Screw on and tighten Install the pedals Looking for "R" mark Installed on the chainwheel Rotate clockwise to tighten side crank Looking for "L" mark Rotate counterclockwise... -
Page 12: Seat Installation
Seat installation Open the clamp and put Adjust the height and lock the stem into the tube Front wheel installation Install the front wheel into Release the rod the fork Put it in the wheel Both sides must be tightened Assemble video http://www.paselecbikes.com/video... - Page 13 Usage Guidance Power switch on/off 1. To turn the power from the OFF to the ON position you must turn on the red button at the bottom of the downtube of the frame. (Right photo as reference) The power button of the display locates on the button pad on the left handlebar.
-
Page 14: Battery Charging And Maintenance
Battery Charging Maintenance Two keys are provided to lock or unlock the battery. The battery can be charged in the compartment or taking off. Please do not use any other chargers. Select a suitable charger based on applicable voltage. -
Page 15: Troubleshooting
Troubleshooting Disc brake system fault Brake level The display shows error code , which illustrates the failure to stop the bike by brake lever. This means the wires are not connected well or the brake lever is damaged. We suggest the customer can check whether any screw is loose and the lever can be returned to the position after grabbing. - Page 16 Battery fault Battery voltage loss Even if the customers had not ridden the bike for a long time, the battery should be charged one time in sixty days to avoid the battery voltage loss. The original charger cannot be used to charge the battery when the battery voltage is lower than the charger voltage.
- Page 17 Cannot charge The green light of charger keeps on. The charger cannot deliver electricity to the battery. The customer should replace the charger. The light cannot turn green The light of charger cannot turn green after 8 hours charging. The battery cannot get...
-
Page 18: Warranty
Paselec bikes warrants this product, including all individual components against defects in material or workmanship as follows:... - Page 19 5. This warranty does not include consumables or normal abrasion (tires, tubes, brake pads, cables and housing, grips, chain, spokes). 6. Paselec will not be liable and/or responsible for any damage, failure or loss caused by any unauthorized service or use of unauthorized parts.
- Page 20 Take pictures of any damage that is found, and mark the date the images if possible. Keep all packaging and paperwork until the inspection process is complete. Report damage claims within 10 days of delivery to an Paselec customer service representative. Please contact our customer service team for return/replacement instructions at: www.paselec-ebikes.com...
-
Page 21: Return Policy
Return Policy Purchased but not shipped or not processed with our fulfillment center: 100% full refund Return within 7 days after receipt of the bike. 1. Purchased but not shipped or not processed by our fulfillment center：100% full refund. - Page 22 Maintenance Cost Policy Within 1 month since receipt The maintenance cost and round-trip freight cost caused by the manufacturing defects of the vehicle itself are borne by the company. The maintenance cost incurred by the buyer's man-made damage shall be borne by the company, and the return freight shall be borne by the buyer.
-
Page 23: Service Concept
Service concept Passion Honesty Efficiency Improvement Service timeline hours online service Whatsapp: 008613428878989 or +447860416346 Warehouse and pick-up site Bestone 995 E Cedar St Bestone Ontario 91761... - Page 24 Notes on Cycling Please charging immediately every day to effectively prolong the service life of the battery Please do not use other brand chargers or other accessories, disassemble or modify bicy cles without authorization. We are not responsible for the accidents caused by the above situation.
- Page 25 b ike we do...
- Page 27 Paselec Paselec b...
Need help?
Do you have a question about the E-PAS GS9 Plus Series and is the answer not in the manual?
Questions and answers
Mi batería está full de carga todo funciona menos el motor Mi bicicleta no la recorro mucho La e tenido tiempo guarda y el motor no arranca . Hay una manera de resetear el sistema.
To reset the motor system on a Paselec GS9 Plus Series bike, follow these steps:
1. Check if any wires are loose.
2. Ensure all function buttons are in the correct position.
3. Rule out problems with the controller and display before checking the motor.
4. If the display shows an error code, it may indicate the Hall sensor is burned, the motor is overloaded, or the motor gear is damaged.
5. If these issues are confirmed, the motor needs to be replaced.
There is no specific reset procedure mentioned, but checking and ruling out related components is necessary.
This answer is automatically generated
The swift of Battery is required turn off when is charging.
The context does not provide instructions for turning off the battery switch while charging the Paselec E-PAS GS9 Plus Series.
This answer is automatically generated
PM9 manual where is it ? Also can you send me all relevant videos and manual that goes with that models bike .
Just recharged battery and the monitor (display) have not have any problems the power is on
На моём paselec gs9, проблема в том, когда я гачинаю крутить педали то мотор плмогает мне только при первом обороте педалей и потом не работает пока я не остановлюсь. Но на полностью элнктрическом ходу мотор работает. Как мне настроить функцию помощи мотора при вращении педалей. Скорость правильно показывает только когда я еду на электрическом ходу, но как только я с дроселя убираю палец и не добовляю склрость то спедометр не показывае правильно, сбрасывает показания. И ещё вышлите мне все настройки которые я могу изменить на дисплее.
