Multiple measurement modes
LED digital screen
Measuring time 1s
Auto shutdown (in 8s)
infrared
THERMOMETER
ARU Med Non-Contact Infrared Thermometer helps to measure the
accurate temperature without touching the body. It has a digital
display with fast measurement of approx 3 sec. And can be used to
measure the temperature of food, A.c. Units, machinery, engines,
water etc. Equipped with button to switch between ℉ to ℃ & backlit
AMT-505
for easy use in dark environments.
SIX MONTHS WARRANTY
3-5 cm measuring distance
Intelligent 3 color backlight
Fever alarm technology
Reliable readings & memory storage
Advertisement
Summary of Contents for ARU Med AMT-505
- Page 1 AMT-505 infrared THERMOMETER ARU Med Non-Contact Infrared Thermometer helps to measure the accurate temperature without touching the body. It has a digital display with fast measurement of approx 3 sec. And can be used to measure the temperature of food, A.c. Units, machinery, engines, water etc.
- Page 2 PACKAGING...
- Page 3 CERTIFICATE...
- Page 4 USER MANUAL Scope of Application: 1. The body temperature of the measured object is displayed by measuring the thermal radiation on the forehead of the human body in the body temperature mode. 2. In the temperature mode can be measured baby milk temperature, bath water temperature, object temperature, air temperature and other environment that needs to test the temperature.
-
Page 5: Specifications
Product Function Key Name: Technical Specifications: The Product Name Infrared Thermometer CS-602 Specifications 35.0℃～42.1℃ Measuring Range 35.0℃～42.0℃，±0.2℃ Maximum 42.1℃～42.9℃，±0.3℃ Permissible Error 0.1℃ Display Resolution 3cm～5cm The Measured Distance ：16℃～35℃ ：≦85% The Operating The temperature humidity Environment ：-20℃～+55℃ ：≤93% Transportation and The temperature humidity Storage Conditions... -
Page 6: Proper Use
1.1 Classificationby shock proof type: equipment supplied by internal power supply. 1.2 Classificationby shock proof degree: belongs to type B application. 1.3 Classification according to the degree of protection against harmful liquid intake: common equipment. 1.4 According to the degree of safety in the use of flammable anesthetic gas mixed with air or mixed with oxygen or nitrous oxide: equipment that cannot be used in the use of flammable anesthetic gas mixed with air or mixed with oxygen or oxidation to nitrogen flammable anesthetic gas. - Page 7 (2) Please do not use rechargeable batteries, should use disposable batteries, try to use alkaline batteries. (3) Thestatic current is very small when the instrument is not working, but when it is not used for a long time, it is recommended to take out the battery to avoid battery leakage and damage the product.
- Page 8 Figure 3 (2) This product measurement without direct contact with the patient, please choose before measurement mode, press the set key can select the surface temperature and temperature model, temperature model, please see to it that the temperature sensor and forehead vertical distance of 3 ~ 5 cm (figure 4), but the hand press the measure button, the measurement is complete, a buzzer rang, and the results will be displayed (figure 5), each an effective measurement counter will increase 1, if the measurement result is "L0"...
- Page 9 (7) In the normal test mode, long press the setting key to display F1, continue to press the setting key to display F2, then enter the alarm temperature numerical setting, click the volume key to increase the value, click the memory key to decrease the value, the highest is 42.1 ℃, the lowest is 32.9 ℃, long press to continuously increase and decrease the value.
- Page 10 The Normal Temperature Clinical Deviation ≤±0.3℃ 0-2 years 36.4℃~38.0℃ ≤±0.2℃ 3 to 10 years 36.1℃~37.8℃ ≤±0.2℃ 11-65years 35.9℃~37.5℃ ≤±0.3℃ Under the age of 65, 35.8℃~37.4℃ Note: It is not unusual for temperature values to vary according to skin color, thickness, body parts, and ambient temperature.The reason is that the more exposed the body parts are more affected by the environmental temperature.
- Page 11 (12) After the replacement of components (such as batteries) and the host machine reaching the end of the life of the equipment may cause measurement errors and accuracy, please deal with them in accordance with local laws and regulations. warning (1) Be sure to remove the hair and sweat from your forehead before measurement.
- Page 12 Battery installation and replacement: When the low-voltage prompt appears on the display screen, please replace the special battery. Please refer to the "installation and use instructions" in this book for installation and replacement. Troubleshooting: The main reason the screen shows "HI" and "L0" : The reason for showing Treatment recommendations Warm hair or sweat...
