Before use
Before use, thoroughly dry the coupling, handpiece, hose
joint section of the powder case, inside of the powder case,
and inside of the powder case cap.
AIR
Coupling
Powder case
AIR
Handpiece connection
AIR
AIR
AIR
Powder case cap
AIR
Attaching and Removing the Nozzle Tip
Attaching the Nozzle Tip ( Refer to the Operation Manual 6-6 )
Securely attach the Nozzle Tip to the handpiece nozzle by referring to the
figure below. After attaching, lightly pinch the Tip and check it is not
removed from the handpiece nozzle. If the Tip is attached incorrectly, the
Tip will come off and accidental ingestion may result.
Nozzle Tip
Removing the Nozzle Tip ( Refer to the Operation Manual 6-6 )
After treatment, remove the Nozzle Tip from the handpiece using the
Nozzle Tip Remover and dispose of it.
Nozzle Tip Remover
OM-TZ493E
2016.00.00 00 Y
Advertisement
Summary of Contents for smartdent smartgun PERIO
- Page 1 Before use Attaching and Removing the Nozzle Tip Before use, thoroughly dry the coupling, handpiece, hose Attaching the Nozzle Tip ( Refer to the Operation Manual 6-6 ) joint section of the powder case, inside of the powder case, Securely attach the Nozzle Tip to the handpiece nozzle by referring to the and inside of the powder case cap.
- Page 2 Also, perform idle running with air alone to expel any internal water. • Make sure you clean the smartGun PERIO in an ultrasonic bath once a week to prevent the instrument from clogging ( refer to the Operation Manual 8-1 ).
- Page 3 Troubleshooting Powder Clogging ( Refer to the Operation Manual 8,10 ) Remove the Nozzle from the Handpiece and clean the inside of the Nozzle and Handpiece with the supplied Cleaning Wires and Cleaning File. In the same way, clean the Handpiece Joint Section and the Internal Nozzles of the Powder Case. Powder Case Nozzle Internal Nozzles...
