Summary of Contents for GIRtech BASE
- Page 1 BASE Assembly instructions...
- Page 3 BASE ASSEMBLY INSTRUCTIONS tech The table is delivered disassembled. Each of the component parts is numbered 1 to 9. The details are shown in the figure. A complete set contains the following parts: Table construction elements - 6 pcs. 2. Bolt М6х30 - 8 pcs.
- Page 4 Mount part pos.1 on a solid surface, assemble two parts pos.2 and tighten bolts pos.6 and nuts pos.8 with hex key pos.9...
- Page 5 Fasten parts pos.3 with bolts pos.6 and nuts pos.8 using hex key pos. 9...
- Page 6 Mount part pos.4, screw it up with bolts pos. 6 and nuts pos.8, using hex key pos. 9.
- Page 7 Attach part pos. 5 to part pos.4, tighten it with bolts pos.7 and nuts pos.8, using hex key pos.9...
- Page 8 OPERATION MANUAL The table can be installed on any surface. To do so, adjust the table-legs pos.1 for height. Rotating the table-leg clockwise or anti-clockwise, you can adjust it for height.
- Page 9 The design envisages 2 positions of part pos. 5 for ease of storage. To remove the table-flap into the low position, feel for two latches at the joint of details pos.4 and pos.5 Upholding part pos.5, press the latches and press the part down.
