Pantograph Motorization
All EuroDual models are ready to be retrofitted with our pantograph
motorization kit Ref. SUD3159 (sold separately).
This kit contains two special pantographs, two servomotors and respective
mounting screws and can be purchased directly from Sudexpress or via your
reseller.
This kit will only function with a compatible digital decoder.
To install a pantograph please follow first the instructions in fig. 1 to open the
model. Then unscrew the stock pantograph and remove the cover part to
expose the roof slot "N" (fig. 6). Assemble the new pantograph "Q" and the
re-screw "R". Put the servomotor "S" in place and screw the two supplied
screws "T" in the kit. Make sure that the pantograph arm and the servo
leading slide are mounted as shown in "U". Finally, connect the wire harness
to the connectors on the main PCB board.
The installation instructions described above apply to both pantographs.
