- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL with PARTS LIST S Series Pumps Model S-12 All Prime Pumps a Division of Power & Pumps, Inc. 803 N. Myrtle Ave. Jacksonville, FL 32204 phone: 800-803-0353 phone: 904-356-5881 fax: 904-356-8717 e-mail: sales@allprimepumps.com date: 07/2013...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Pg. 04 SAFETY – SECTION A Pg. 05 INSTALLATION – SECTION B Pg. 06 - Pump Dimensions . Pg. 06 PRE INSTALLATION INSPECTION . Pg. 07 POSITIONING PUMP Pg. 07 - Lifting Pg. 07 - Mounting Pg. - Page 3 TABLE OF CONTENTS (Continued) TROUBLESHOOTING – SECTION D Pg. 19 - Preventive Maintenance . Pg. 21 PUMP MAINTENANCE AND REPAIR – SECTION E Pg. 22 - Performance Curve Pg. 22 - Parts List Pg. 23 PUMP AND SEAL DISASSEMBLY AND REASSEMBLY Pg.
-
Page 4: Introduction
CAUTION! manual or in other literature accompanying this Hazards or unsafe practices which COULD unit, please contact your All Prime distributor, result in minor personal injury, product or property damage. These instructions describe the requirements and the possible damage... -
Page 5: Safety - Section A
SAFETY – SECTION A These warnings apply to S-series basic pumps. All Prime has no control over or particular WARNING! knowledge of the power source which will Do not operate the pump without the guards in be used. Refer to the manual accompanying place over the rotating parts. -
Page 6: Installation - Section B
For further assistance, contact your All Prime Most of the information pertains to a standard distributor or All Prime Pumps. static lift application where the pump is... -
Page 7: Pre Installation Inspection
Materials or if anything appears to be abnormal, contact Either pipe or hose maybe used for suction and your All Prime distributor or the factory to discharge lines: however, the materials must determine the repair or updating policy. Do be compatible with liquid being pumped. -
Page 8: Line Confi Guration
If hose is used in suction lines, it must be the Fittings rigid-wall, reinforced type to prevent collapse Suction lines should be the same size as the under suction. Using piping couplings in suction pump inlet. If reducers are used in suction lines, lines is not recommended. -
Page 9: Suction Lines Positioning
If it’s necessary to position infl ow close to the Suction Line Positioning suction line, install a baffl e between the infl ow and the suction line. The baffl e will allow The depth of submergence of the suction line entrained air to escape from the liquid before is critical to effi... -
Page 10: Bypass Lines
Therefore, it is recommended that a All Prime Automatic Air Release Valve be installed in the Bypass Lines bypass line. -
Page 11: Automatic Air Release Valve
1 to 5 gallons per minute, to the specifi c hydraulic operating conditions until the pump loses prime or stops. of the application, the All Prime Automatic Air Release Valve will permit air to escape through the bypass line, and then close automatically... -
Page 12: Alignment
(page 15) piping is used for the bleed line, avoid the use of elbows whenever possible. When mounted at All Prime Pumps, the driver and pump are aligned before shipment. NOTE: Misalignment may occur in transit and handling. -
Page 13: Coupled Drivers
WARNING! Align non-spider type couplings by using a feeler When checking alignment, disconnect the gauge or taper gauge between the coupling power source to ensure that the pump will halves every 90 degrees. The coupling is in remain inoperative. alignment when the hubs are the same distance apart at all points. -
Page 14: V-Belt Drives
V-Belt Drives When using V-belt drives, the power source and the pump must be parallel. Use a straightedge along the sides of the pulleys to ensure that the pulleys are properly aligned (see Figure 6D). In drive systems using two or more belts, make certain that the belts are a matched set; unmatched sets will cause accelerated belt wear. -
Page 15: Operation - Section C
OPERATION – SECTION C WARNING! Review all SAFETY information in Section A. After fi lling the pump casing, reinstall and tighten the fi ll plug. Do not attempt to Follow instructions on all tags, labels and decals operate the pump unless all connecting piping attached to the pump. -
Page 16: Operation
Lines With a Bypass is 160º F (71º C). Do not apply it at a higher operating temperature. If an All Prime Automatic Air Release Valve Overheating can occur if operated with the has been installed, the valve will automatically valves in the suction or discharge lines closed. -
Page 17: Strainer Check
Strainer Check CAUTION! If a suction strainer has been shipped with If the application involves a high discharge the pump or installed by the user, check the head, gradually close the discharge throttling strainer regularly, and clean it as necessary. valve before stopping the pump. -
Page 18: Bearing Temperature Check
BEARING TEMPERATURE CHECK Bearings normally run at higher than ambient temperatures because of heat generated by friction. Temperatures up to 160º F (71º C) are considered normal for bearings, and they can operate safely to at least 180º F (82º C). Checking bearing temperatures by hand is inaccurate. -
Page 19: Troubleshooting - Section D
TROUBLESHOOTING - SECTION D Review all SAFETY information in Section A. WARNING! Before attempting to open or service the pump: 1. Familiarize yourself with this manual. 2. Lock out or disconnect the power source to ensure that the pump will remain inoperative. 3. - Page 20 TROUBLE POSSIBLE CAUSE PROBABLE REMEDY PUMP STOPS OR Air leak in suction line. Correct leak. FAILS TO DELIVER RATED FLOW OR Lining of suction hose collapsed. Replace suction hose. PRESSURE Leaking or worn seal or pump gasket. Check pump vacuum. Replace leaking or worn seal or gasket.
-
Page 21: Preventive Maintenance
TROUBLE POSSIBLE CAUSE PROBABLE REMEDY EXCESSIVE NOISE Cavitation in pump. Reduce suction lift and/or friction losses in suction line. Record vacuum and pressure gauge readings and consult local representative or factory. Pumping entrained air. Locate and eliminate source of air bubble. -
Page 22: Pump Maintenance And Repair - Section E
PUMP MAINTENANCE & REPAIR – SECTION E MAINTENANCE AND REPAIR OF THE WEARING PARTS OF THE PUMP WILL MAINTAIN PEAK OPERATING PERFORMANCE. Performance Curve STANDARD PERFORMANCE FOR PUMP MODEL S-12 Based on 70º F (21º C) clear water at sea level with minimum suction lift. -
Page 23: Parts List
Figure 1. & 2. - Pump Model S-12... -
Page 25: Pump And Seal Disassembly And Reassembly
PUMP & SEAL DISASSEMBLY & REASSEMBLY WARNING! Use lifting and moving equipment in good repair Review all SAFETY Information in Section A. and with adequate capacity to prevent injuries to personnel or damage to equipment. Follow the instructions on all tags, label and decals attached to the pump. -
Page 26: Pump Disassembly
Pump Disassembly Service to the wear plate, impeller, or seal To loosen the impeller, remove the socket head assembly may be accomplished from either side capscrew, the impeller washer, and roll pin. of the pump casing. The following instructions are based on service from the suction side. Install two capscrews in the 3/8-16 UNC tapped holes located in the impeller hub, and use a Install a lifting eye bolt in the 5/8-11 UNC tapped... -
Page 27: Seal Disassembly
Seal Disassembly Support the pump casing using a suitable hoist and remove the remaining capscrews NOTE! ant lockwasher. Separate the casing from the There is an air fi lled cavity with an open pedestal assembly. drain hole located directly behind the seal plate. -
Page 28: Shaft And Bearing Reassembly
Shaft & Bearing Reassembly Clean the bore of the pedestal and seal plate, Replace the bearing cap o-ring and oil seal. as well as the shaft and component parts with Position the lip of the oil seal toward the oil a cloth soaked in cleaning solvent. -
Page 29: Seal Reassembly
Seal Reassembly - Component Type The seal is not normally reused because of the high polish on its lapped faces, but if it is necessary to reuse the old seal, wash all metallic parts in cleaning solvent and dry thoroughly. Inspect the seal components for wear, scoring, grooves, and other damage that might cause leakage. -
Page 30: Pump Reassembly
Pump Reassembly Reinstall the impeller adjusting shims. until they are snug against the suction head. The clearance should now be correct. Reinstall the impeller key, and press the impeller onto the shaft. A clearance of .010 to .020 Lubricate the seal as indicated in the inch between the impeller and the seal plate LUBRICATION section. -
Page 31: Lubrication
LUBRICATION Seal Chamber Sight-glass tube should be kept approx. 1-1/2” to 2” above the bottom of the glass. Clean and reinstall the vented plug. Maintain the oil at this level. Bearing Chamber The bearing housing was fi lled when it was shipped from the factory. Check the oil level regularly through the sight glass tube which should be kept approx. -
Page 32: Bearings
CAUTION! Monitor the condition of the bearing lubricant regularly for evidence of rust or moisture condensation. This is especially important in areas where variable and cold temperatures are common. For cold weather operation, consult the factory or a lubricant supplier for the recommended grade of oil. -
Page 33: Warranty Statement
RIME UMPS - 12 MONTH LIMITED WARRANTY - WARRANTY / REPAIRS BY MANUFACTURER Unless otherwise agreed in writing by Manufacturer, the Equipment shall be warranted in accordance with this Warranty. Company, unless otherwise authorized by Manufacturer, shall instruct its customers to send all Warranty claims to it rather than to Manufacturer, and Company shall send all customer Warranty claims received, or its Warranty claims, to Manufacturer in writing, immediately on learning of the claim.
