Everheart Dongii Gen 2 Quick Start Manual

SPECIFICATION

Dongii Gen 2
Model No.: EH-032BT
Product Name:
Multifunctional Type-C Converter
Dimensions(W*H*L): 31mm * 52.6mm *17.2mm
USB A Port: Support USB data transmission,
compatible with charging protocol of QC3.0/QC2.0,
FCP, AFC, SFCP and Apple 2.4, BC1.2 and Samsung 2.0A.
HDMI Port: Support up to 4K@60hz video out.
USB Type-C Port: Support audio/video and USB data transmission, PD fast charging(requires to be used with a PD
protocol 45W or above power adapter) Bluetooth Port: (For Dongii Bluetooth Version only) Support Bluetooth 5.0
with audio transmission.

MAINTENANCE

• To prevent damage to the product hardware due to improper use, please keep the product
dry.
• Do not place the product in an area where the temperature is too high or too low.
• Avoid being subjected to strong impact or heavy objects.
• Keep away from dangerous chemicals and strong magnetic fields.
• Do not disassemble or modify the product without permission.
• Please place these electronic products out of the reach of children, and put them in a
sealed or dry area when not using the product for a long time.

FCC Statement

This device complies with Part 15 of the FCC rules. Operation is subject to the
following two conditions: 1) this device may not cause harmful interference, and 2)
this device must accept any interference received, including interference that may
cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
--Reorient or relocate the receiving antenna.
--Increase the separation between the equipment and receiver.
--Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
--Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
USB Type-C Power Adapter
Model No.:
U6PD
Dimensions(W*H*L):
31mm * 52.6mm *51.6mm
Input: AC 100-240VAC, 50/60Hz, 1.5A
Output:
5V= 3A, 9V = 2A, 12V=3A
15V=3A, 20V=3.25A
Max Output:
65w
