- Page 2 160Μ 200E 300E 1010 1010 1275 1275 2050 2050 2050 2580 EXTERNAL DIMENSIONS - ALL MODELS STORAGE TANK COLLECTOR SUPPORT BASE TOTAL WEIGHT EVERHOT Dimensions Weight Dimensions Collectors Surface Weight Weight MODEL EMPTY FULL (per collector) 200E 570x1320 2050x1010x90 4,20...
- Page 3 Assembly diagram of the support base on a flat surface ASSEMBLY INSTRUCTIONS Support base for 200 & 300 (with 2 collectors) Before choosing the location and the installation point, ensure that it is not shaded by any obstacle (trees, build - ings…...
- Page 4 Support base for 200 (with 1 collector)
- Page 5 Analytical description of the storage tank’s and collector’s components Storage tank 01A+B Storage tank’s suspension point (used only in production process, ignore them ) Handles Filling pipe (for the closed circuit) Safety valve 3 BAR Elbow raccord (4 pcs) Thermal fluid inlet pipe (to the stor - age tank from the collector) (indica - tion “jacket”) Small connection tube...
- Page 6 The responsibility for the cor- rect use of the antifreeze liquid quantity is for the account of the installer and in no case of Al Huraiz The use of water only or other liquid may cancel the validity of the warranty.
- Page 7 Assembly diagram of the support base on a surface with maximum inclination of 32 ASSEMBLY INSTRUCTIONS Before choosing the location and the installation point, ensure that it is not shaded by any obstacle (trees, build - ings… etc, see obstacle diagram here below).
-
Page 8: Connection Of The Cables
DESCRIPTION OF THE PARTS OF THE ELECTRIC RESISTANCE AND THERMOSTAT Plastic cover Electric resistance Thermostat’s socket Resistance’s cover Base of multiple plug (for the electric lines) Metal wires for the connections of the resistance with the ther- mostat Rubber flange for water tight - ness Central nut Tightening nuts...
