Installation Instructions - PERGOLINE
Contents:
1. Safety
1.1. Explanation of the safety notes
1.2. General safety information
2.3. Wind classes: Definition and classification
2.4. Mounting situations: Wall and ceiling installation
2.6. Fastening technique
5. Dismounting
1. Safety notes, warnings and mounting information:
1.1. Explanation of the safety notes:
Safety notes and important information are integrated in the text as appropriate.
The following symbols are used to alert the reader/user of the instructions.
This symbol means that the relevant note is important for the safety of persons or
for the function of the awning.
This symbol highlights important product information for the installation engineer
or user.
1.2. General safety information:
The WO&WO PERGOLINE awning has been designed and manufactured in
conformity with DIN EN 13561. However, when the awning is mounted or operated,
the persons involved in the respective activity may be put at risk if the relevant
instructions are not observed.
Only qualified and duly specialised companies or trained specialist personnel may be
permitted to mount the awning.
Always observe the information and notes in the installation and operation
instructions.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7700 and is the answer not in the manual?

Questions and answers

Summary of Contents for Acrimo 7700

  • Page 1: Table Of Contents

    Installation Instructions - PERGOLINE Contents: 1. Safety 1.1. Explanation of the safety notes 1.2. General safety information 2. Installation 2.1. Tools, resources and materials 2.2. Preparing the installation 2.3. Wind classes: Definition and classification 2.4. Mounting situations: Wall and ceiling installation 2.5.

  • Page 2: Installation

    A failure to observe the relevant information will render the manufacturer’s liability null and void. The safety-at-work and accident prevention regulations specific to each country must be complied with. In particular, a person performing special work at height must be suitably secured.
  • Page 3 fresh 5 (according to Class 2 28 -37 km/h breeze Beaufort wind scale) strong 6 (according to Class 3 38 -48 km/h breeze Beaufort wind scale) Wind resistance class 2 Classification of the PERGOLINE: 2.4. Mounting situations: Wall installation of PERGOLINE DURCHGANGSHÖHE = HEADROOM approx.

  • Page 4: Mounting Height And Position Of The Brackets

    DURCHGANGSHÖHE = HEADROOM approx. 75mm approx. 175mm 2.5. Mounting height and position of the brackets Mounting height: The awning can produce crushing forces and shear stresses, for instance between the fall bar and the distance tube or casing and at the rollers of the moving fall bar.

  • Page 5: Mounting The Casing

    Mounting on thermally insulated facades: Insulating plaster and full multi-layer thermal insulation are not pressure stable. Dämmschutz ausgenommen Therefore, it is necessary to use backing Insulation protection for the entire surface, or at least taken out distancers for the area around the screws. The picture on the right illustrates one possible variant: Bracket mounting:...

  • Page 6: Mounting Rails And Posts

    pivoting part with SW 6 Allen key. To lower the awning, turn clockwise To raise the awning, turn counter- clockwise • If inclination corrected significantly, adjust the brackets alternately. 2.8. Mounting rails and posts: • If necessary, adjust the height of the posts to the situation on site.
  • Page 7 • Attach the guide rails to the pegs of the casing end caps. Ensure that the end with the sink hole bore points to the pegs! Do not move the guide rail too much to the side and up because the peg could be torn off due to the lever effect! •...

  • Page 8: Mounting The Distance Tube(S)

    2.9. Mounting the distance tube(s): To stabilise the parallelism of the system, mount at least one distance tube before aligning the system at the post. • Insert the washer and turn the distance tube holder into the end cap of the distance tube until it is fully in.

  • Page 9: Alignment Of The System

    2.10. Alignment of the system: • Align the system by moving the casing in the brackets or sideways movement of the two posts in the diagonal. PARALLELITÄT HINTEN – PARALLELISM REAR DIAGONALE - DIAGONAL – PARALLELITÄT VORNE PARALLELISM FRONT Deviations diagonal measurements by more than 5mm may result in malfunctions.

  • Page 10: Line Systems

    • Connect a test cable to the system and extend approximately 20cm. • Connect the guide rails with the pegs of the casing using the countersunk screws. 3. Line systems: To install line systems, at first mount all boxes and only then proceed with the guide rails and posts as described for the individual systems.

  • Page 11: Initial Operation

    4. Initial operation: Before the initial operation of the awning, remove all objects (e.g. ladders, tools etc.) from the full travel range (in/out) of the awning and from underneath the awning. During the trial operation, ensure that nobody is in this area – there is a risk of injury in case of a malfunction.
  • Page 12 Higher-level control unit Wait until higher-level signal is not prevents manual activated any more. operation System does not End positions of the Reset or re-program end positions extend or retract fully driving gear changed, or (see Driving Gear Instruction incorrect end position Manual) setting System does not...
  • Page 13 B. Alignment of the fall bar: Measure the distance between the fall bar and the rail end on both sides. The correction is made on the side that extends further. Remove countersunk screw (1) with SW 4mm Allen key and take off plastic cover (2).
