S M A R T D O O R L O C K R O O K S M A R T ™ Available on Apple & Google Play Store APP CONTROL PASSCODE FINGERPRINT KEY FOB 2 SPARE KEYS Owner’s Manual EXPERT 24/7/365 SUPPORT: support@rooksmart.com...
TA B L E O F CON T E N S In clud e d in Th e Box In form at i o n & S afety Warni n gs Sa le s & Se r vice Te rm s In s t alla t io n S te ps Op e ra t i o n Te st in g Sys tem D e t ails...
Information & Safety Warnings Introduction This user manual will guide you through the functions and usages of the ROOK™ Smart Lock. It is important that you follow the instructions. Please consult this manual before you attempt to use this lock. If you have any questions that we haven’t answered by this manual or in need of non-routine service, please get in...
Limited Lifetime Mechanical and Finish Warranty against defects in materials and workmanship under normal use to the original residential user. You must register for this Warranty within 7 days of receiving your ROOK™ Smart Lock. Help Us Continue to Improve Our Instructions: Any error or question in our manual or sales terms, please feel free to contact •...
Installation Steps STEP 1 PREPARATION Check the door’s dimensions - this will tell you if you need to expand the deadbolt mechanism. The ROOK™ Smart Lock mechanism is expandable and can be installed on any door!
Page 7
STEP 2 INSTALLING DEADBOLT AND STRIKE PLATE NOTE: Drilling this hole is optional but recommended. Screw A STEP 3 PREPARING KEYPAD Solenoid (Optional) Screw D...
Page 8
STEP 4 INSTALLING KEYPAD Wire goes in under the latch This side up Adjust lock cylinder to horizontal insert...
Page 9
STEP 5 INSTALLING MOUNTING PLATE Silicone Weather Seal Bulge on this side Turn the knob to test lock & unlock functions before fully tightening the screws. Make sure the bolt extends and retracts smoothly. Do not over tighten the screws. PRO TIP: We have a video tutorial.
Page 10
STEP 6 PREPARING INTERIOR ASSEMBLY When installing the Back Plate (interior of your home), make sure the Lock Switch is set to correct function. Lock on Left Side (inside view) Lock on Right Side (inside view)
Page 11
STEP 7 GENTLY CONNECT THE CABLE Bolt is retracted...
Page 12
STEP 8 INSTALLING INTERIOR ASSEMBLY & TESTING Screw C Screw B Push extra wire back into door hole thru this hole Test & check if the bolt moves in & out smoothly...
Page 13
STEP 9 BACK UP KEY TESTING At the same time, Rotate 120 degrees counter-clockwise Push the bottom side of the cover Emergency power Test & check if the bolt moves in & out smoothly...
Page 14
STEP 10 INSTALLING BATTERIES & COVER Reset button Reset to Slide the cover on Factory State There is one reset button on the back panel. You can press this button for 2 seconds, you should hear 2 beeps. This means the lock is under factory state, the default passcode is: 123456.
Password Card Back Panel Lock Button Thumb Knob Cover Cylinder USB Port Unlock Button Use the card or password to unlock the smart lock System Details Project Parameter Main material Zinc Alloy, ABS Door thickness 35mm to 55mm Battery power...
Page 16
W W W . R O O K S M A R T . C O M ROOKSMARTHOME T A G U S O N S O C I A L T O B E F E A T U R E D ISSUES WITH YOUR ORDER? LET US HELP! EM AI L SUB J ECT: H EL P NOW ! For quick s uppor t SUPPORT@ROOKSMART.COM...
