Summary of Contents for Maker Hart DD-PAD
- Page 1 DD-PAD Assembly Manual *G6047096R0-00* G6047096R0-00...
-
Page 2: Parts List
PARTS LIST Panel Board 控制板 BASE (6pcs) 機座 Main Board 主機板 Sensor (5pcs) 感測片 Stay (9pcs) 連接支座 Cable Black/Yellow (8pcs) 黃黑線 Rubber pice (5pcs) 矽膠片 Cable Black/Red (8pcs) 紅黑線 Screw bolt (5pcs) [CUP 3x6] (18pcs) [BIND 3x4] (5pcs) [LED SET] (5pcs) [NUT M3x2t] (5pcs) [LED NUT] (5pcs) [Rubber foot] (48pcs) -
Page 3: Tool List
TOOL LIST TAPE widtch10 Use Fix Cable Screwer + Tools... - Page 4 ASSY-Control Board L - hole 4 point Screw bolt (4pcs) BASE 機座 NUT M3x2t (4pcs) Rubber foot (6pcs) (6pcs) Rubber foot to paste on the Base...
- Page 5 BIND 3x4 (4pcs) Main Board ( notice the direction) Panel Board 1-2 ~ 1-3...
- Page 6 ASSY-PAD x 5set Sensor 感測片 Release paper to remove Sensor to paste on the Base BASE 機座 Into the hole 2-1 ~ 2-2...
- Page 7 insert 穿入 LED SET Into the hole LED NUT Screw [LED NUT] 2-3 ~ 2-5...
- Page 8 LED-Foot to turn 90° Cable Black/Red Yellow Cable (+)POLE Black Cable (-)POLE LED long foot is (+)pole LED short foot is (-)pole 2-6 ~ 2-7...
- Page 9 Use Tape to Fix Cable Rubber foot (6pcs) (6pcs) Use Tape to Fix Cable Fix Cable 整線 Rubber foot to paste on the Base Rubber pice 矽膠片 1. Release paper to remove 2. Rubber pice to paste on the Base 矽膠片...
- Page 10 ASSY TOP DD-PAD Stay CUP 3x6 (2pcs)
- Page 11 - POLE + POLE Sensor Using in Sensor Correspondence position...
- Page 12 Volume Dynamic Sensitivity Mode 模式 Mode Mode PAD 1 PAD 2 PAD 3 PAD 4 PAD 5 Closed Open Crash 1 Kick 1 Snare 1 Hi Hat Hi Hat Closed Crash 2 Kick 1 Snare 2 Low Tom Hi Hat Splash Side Kick 2...
-
Page 13: Assembly Example
Assembly Example 1 Main Board PAD 1 PAD 4 Sensor Cable Sensor Cable to [a] point to [d] point LED Cable LED Cable PAD 3 to [1] point to [4] point Sensor Cable to [c] point LED Cable PAD 2 PAD 5 to [3] point Sensor Cable... - Page 14 CONNECTIONS AUX-IN PHONE OUT USB CHARGER AC ADAPTOR MINI USB ADVICE POWER SUPPLY： AC ADAPTOR (8V ~ 15V) or USB POWER (4.5V ~ 5.5V)
- Page 16 CONTACT MAKER HART INDUSTRY CORP. 2F., NO.3, LN. 263, CHONGYANG RD., NANGANG DIST., TAIPEI CITY 11573, TAIWAN (R.O.C.) Email info@makerhart.com http://www.makerhart.com https://www.facebook.com/Makerhart2015/...
