- Page 1 User Manual Delft Light...
-
Page 2: Table Of Contents
Delft Imaging does not assume responsibility for the misuse of the Delft Light soft- and hardware. Since Delft Imaging cannot control the use of the Delft Light, it shall not be held responsible for any direct or consequential personal injury or damage. -
Page 3: Introduction
(ALARA principle). Because of its nature there is no ‘standard’ setup for the Delft Light while this always depend on the venue used, amount of space, patient flow etc. Some considerations for a correct use are: •... -
Page 4: Installation
Installation Assembly of the X-ray and detector (wall) stand Attach the upper part of the detector and X-ray stand to the lower using the provided guidance strip and bolts. Determine the best way to setup the stands in the available venue, see above considerations on correct placement. Take all components out of the backpack. -
Page 5: X-Ray Tube/Generator Installation (Atxtreme)
X-ray tube/generator installation (ATXtreme) 1. Unpack X-ray stand from flight case and assemble. (Refer to Delft Light instruction movie how-to). 2. Using the grip on the ATXtreme attach the grip to the spring- arm of the X-ray stand and securely fasten the provided screw, level the ATXtreme using the provided level. -
Page 6: Operator Laptop
CANON NE software. Workflow step by step After installation of all components the system can be used to start screening. The Delft Light supports several methods of Patient identification: • Using an existing (radiology) Information System using Dicom Modality Worklist protocols •... -
Page 7: Making An Image
Making an image 1. Press EXAM TAB. Depending on the method of entry either scan the bar- or QR-code or manual enter the required patient demographics. Press Start Exam. 2. Select the required protocol (CHEST PA) Press Start. 1. After initialisation a green bar showing Ready will appear on the right upper corner. -
Page 8: Shutting Down System
4. Ask the participant/patient to breath in and hold and immediate press the expose button. After a few seconds the image will appear. Check image and collimation adjust ROI if necessary, press END EXAM. 5. Press CAD4TB button to display CAD4TB score and heatmap. -
Page 9: Annex A Technical Specifications Delft Light
ANNEX A TECHNICAL SPECIFICATIONS DELFT LIGHT Items Specification Electrical Power 1,35 kW @ 90 kV, 15 mA Device power source 22.2 VDC (Battery) 22.2 VDC (Battery) Battery DC 59,2 V, Li+ battery Frequency 120kHz kV, mA 40-90 kV / 2 kV steps X-ray exposure time 0.01 ~ 1 sec / 0,01 steps... -
Page 10: Annex B Suggested Exposure Time Table For An Average Person Weighing 70 Kg
ANNEX B Suggested exposure time table for an average person weighing 70 kg. Region Diagn. Ref. Pro- Grid value (cGy x jection (cm) cm²) Cranium Thorax 120-180 120-180 Abdomen Cervical spine Thoracic spine Lumbar spine Pelvis Shoulder + Clavicle Upper arm AP/LAT Elbow Hand + Wrist... -
Page 11: Annex C Mobisun Solarpanel
ANNEX C MOBISUN SOLARPANEL The Delft Light (backpack X-ray) has an option to use it with the Mobisun solarpanel, Li-ION battery and inverter. This system is to power all required components with a portable(6kg) solar/powerpack! The internal battery capacity is enough to recharge the X-ray and detector batteries and power the CANON laptop and CAD4TB tablet.
