PRODUCT SAFETY

When using electrical equipment, basic safety precautions should always be followed, including the following:
READ THESE INSTRUCTIONS BEFORE USING THIS PRODUCT.
Do not mount near gas or electric heaters.
Equipment should be mounted in locations and at
heights where it will not readily be subjected to
tampering by unauthorized personnel.
The use of accessory equipment is not recommended
by Encelium as it may cause an unsafe condition.
Do not use this equipment for other than the
intended use.
SAVE THESE INSTRUCTIONS.

GETTING STARTED

Overview
The Edge Controller configures and monitors the various components of the Encelium Edge standalone wireless lighting control
system. For optimum performance, the Edge Controller may be installed onto a wall or ceiling surface. Installation into plenum-rated
spaces is possible but NOT preferred.
INSTALLATION INSTRUCTIONS
The Edge Controller must be installed in dry, indoor
locations ONLY. Damp locations are defined as:
interior locations subject to moderate degrees of
moisture such as basements, barns, cold-storage
warehouses, as well as partially protected locations
under canopies, marquees and open roofed porches.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Edge Controller and is the answer not in the manual?

Questions and answers

Summary of Contents for Encelium Edge Controller

  • Page 1 The Edge Controller configures and monitors the various components of the Encelium Edge standalone wireless lighting control system. For optimum performance, the Edge Controller may be installed onto a wall or ceiling surface. Installation into plenum-rated spaces is possible but NOT preferred.
  • Page 2 Push the assembled Edge Controller through the ceiling tile. Place the upper bracket on to the Edge Controller (above the ceiling tile from the plenum area) until it locks with the lower bracket. Connect the Ethernet cable to the PoE port using the POE-IN arrow point on the Edge Controller for alignment.
  • Page 3 Edge Controller INSTALLATION INSTRUCTIONS Wall Junction Box Installation Connect the Ethernet cable to the PoE port using the POE-IN arrow point on the Edge Controller for alignment. Install the Edge Controller onto the box screws. Wall Surface Installation Pre-drill two holes (3.28 inch or 83.3mm apart) on the wall using the supplied template.
  • Page 4 PoE Cable to/from Edge Controller AC Line Input TOP VIEW BOTTOM VIEW Junction Box Installation Attach the Edge Controller Power Supply to a NEMA approved Junction Box. Power Supply Wires from Edge Controller Power Supply Unit Power Supply Wires from Edge Controller...
  • Page 5 AC Line Input to Edge Controller Power Supply Troubleshooting There are no user-serviceable parts inside. For detailed information about how to set-up, install, use, and maintain Encelium hardware and software, please visit: help.encelium.com Regulatory Approval Modifications not expressly approved by the manufacturer could void the user’s authority to operate the equipment under FCC rules.
  • Page 6 Copyright © 2021 Digital Lumens, Incorporated. All rights reserved. Digital Lumens, the Digital Lumens logo, We Generate Facility Wellness, SiteWorx, LightRules, Lightelligence, Encelium, the Encelium logo, Polaris, GreenBus and any other trademark, service mark, or tradename (collectively “the Marks”) are either trademarks or registered trademarks of Digital Lumens, Inc.
