iquatics Aqualumi Universal Quick Start Manual

TIGHTENING SCREW
MAX 50MM
MODEL REPLACEMENT
SPECIFICATION TUBE
Aqualumi Universal 550mm 24w (435mm)
Aqualumi Universal 600mm 24w (435mm)
Aqualumi Universal 700mm 28w (590mm)
Aqualumi Universal 800mm 28w (590mm)
Aqualumi Universal 920mm 35w (742mm)
Aqualumi Universal 1000mm 45w (895mm)
Aqualumi Universal 1200mm 54w (1047mm)
Aqualumi Universal 1500mm 54w (1200mm)
Aqualumi Universal 1800mm 80w (1450mm)
FITTING FLAPS
The AquaLumi Universal has been
designed to incorporate your existing
aquarium covering flap set. The lighting
system should be positioned so that the flap
set fully covers the aquarium. Your existing
flap set will determine where the installation
point should be.
For aquariums without a flap set the unit
can be positioned wherever required.
If required the AquaLumi Universal can be
extended to fit your aquarium. Simply
unscrew the plastic screw located on the
top of each of the end caps, slide out the
extension brackets to the required length
and tighten the screw back up.
Be sure not to over-tighten the screw.
Each side will extend upto 50mm.
Maximum extension - 100mm
Please see table below for product
specification.
MIN MAX DIMENSIONS
LENGTH LENGTH W X H (MM)
533mm 633mm 83 x 52
593mm 693mm 83 x 52
693mm 793mm 83 x 52
793mm 893mm 83 x 52
903mm 1003mm 83 x 52
993mm 1093mm 83 x 52
1180mm 1280mm 83 x 52
1480mm 1580mm 83 x 52
1780mm 1880mm 83 x 52
THE FUTURE OF AQUARIUM LIGHTING
sales@iquaticsonline.co.uk
THANK YOU FOR PURCHASING THE IQUATICS AQUALUMI UNIVERSAL
