Summary of Contents for ASTUS QC25
- Page 1 101, boul. Roland-Therrien, Longueuil, Bureau 500, QC J4H 4B9, Canada Tel. +1-450-442-7887 www.astus.com ASTUS QC25 - HARDWARE USER GUIDE Rev. 0 2021-12-06...
-
Page 2: Table Of Contents
The information contained in this document is confidential 101, Boul. Roland-Therrien Bureau 500, and proprietary to Astus Inc. Any distribution or Longueuil, QC J4H 4B9, Canada reproduction without prior authorization is prohibited. Tel.450-442-7887, Fax 450-442-0605 www.astus.com DOCUMENT HISTORY Rev. Date... -
Page 3: Copyright Notice And Disclaimer
Copyright Notice and Disclaimer ©2021 Astus Inc. All rights reserved. Astus is registered trademark of Astus Inc. The names of other companies and products mentioned in this document may be the trademarks of their respective owners. The information contained in this document represents our current views on the subject matter as at the date of publication. -
Page 4: Support
One I/O that can be set as an input (0 – 32 Vdc) or output (set to GND when enabled) 1 x CAN interface for connection to the vehicle OBD2 or J1939 bus. 1 x CAN interface for connection to a second bus (vehicle or future Astus expansion devices) ... - Page 5 Figure 2 - Astus Telematic Architecture 1. The QC25 collects telemetry, diagnostic and localization data from vehicle. 2. The Data is communicated over a cellular network then the internet to Astus servers. 3. The Astus server analyses module data and presents real-time information, reports and alerts.
-
Page 6: Installation
Installation 4.1 Safety and General Considerations 1. Do not connect the QC25 directly to the vehicle's OBD2 port or install the product in a location if it interferes with the driving or safety of the driver and passengers. 2. The QC25 must be kept away from any source of heat, high humidity or possible liquid spills (eg coffee). - Page 7 See section 4.3 for other installation options. 3. Secure the QC25 to the OBD2 connector using a tie wrap. Figure 4 - Suggested place (in green) to hold back with a tie wrap...
-
Page 8: Use Of A Connection Harness
The vehicle does not have an OBD2 port. The direct connection to the OBD2 port is not secure. The QC25 must be hidden. The QC25 must be installed in a more optimal area. To connect a 2 CAN to the QC25. - Page 9 The information contained in this document is confidential 101, Boul. Roland-Therrien Bureau 500, and proprietary to Astus Inc. Any distribution or Longueuil, QC J4H 4B9, Canada reproduction without prior authorization is prohibited. Tel.450-442-7887, Fax 450-442-0605 www.astus.com ETL-1700-0084 (Universal J1939 Y harness)
-
Page 10: Connecting The 2 Nd Can
3. On the QC25, locate the bi-color LED. 4. The QC25 should establish the CAN bus connection, connect to the remote Astus server and obtain valid GPS positions in 5 minutes or less. The LED should then flash in green 4 times in 4 seconds. -
Page 11: Regulatory Information
2. this device must accept any interference received, including interference that may cause undesired operation. Warning - Part 15.21 Any changes or modifications to this equipment not expressly approved by Astus Inc. may cause harmful interference and void the user's authority to operate this equipment. FCC Interference Statement - Part 15.105.b This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 12: Compliance Statement
2. this device must accept any interference received, including interference that may cause undesired operation. Industry Canada ICES-003 Compliance Label: CAN ICES-3 (B) / NMB-3 (B) For product QC25 WW BLE, contains IC: 5131A-ME910G1WW and 12208A-04 For product QC25 NA1 BLE, contains IC: 5131A-LE910SVV2 and 12208A-04 Astus QC25 - Hardware user Guide... -
Page 13: Déclaration De Conformité
Étiquette de conformité à la NMB-003 d'Industrie Canada: CAN ICES-3 (B) / NMB-3 (B). Pour le produit QC25 WW BLE, contient IC: 5131A-ME910G1WW et 12208A-04 Pour le produit QC25 NA1 BLE, contient IC: 5131A-LE910SVV2 and 12208A-04 6.3 European ECE Approval...
