ASSEMBLY INSTRUCTIONS
CONTENTS
Main aluminium parts
P1
P2
Adding the long rails
P3
P4
Centre legs
P5
Squaring & fixing
P6
Back rails
P7
P8
P9
Watering
P10
Fitting liner
P11
P12
Fitting glass
P13
P14
Troubleshooting
P15
Notes on using the frame P16
Please keep all packaging
until installation is complete
Assembly instructions for model:
Eltham-D
Eltham-D
AX2(1.00m/3'4")
Video instructions:
Helpful video clips are available at
www.garden-products.co.uk/instructions
BX2(1.51m/5'0")
CX2(1.94m/6'5")
Can we improve?
We hope that you find our
instructions clear and concise. If
you have any suggestions for
improvements email:
instructionfeedback@garden-
products.co.uk
Access Garden Products
Crick
NORTHAMPTON
NN6 7XS
Tel: 01788 822301
Fax: 01788 824256
sales@garden-products.co.uk
www.garden-products.co.uk
Date: Nov 2021 Rev 10 File: X2
Advertisement
Related Manuals for Access Garden Products Eltham-D
Summary of Contents for Access Garden Products Eltham-D
-
Page 1: Table Of Contents
Shelving instructionfeedback@garden- Watering products.co.uk Fitting liner Fitting handles Fitting glass Front corner trims Troubleshooting Access Garden Products Crick Notes on using the frame P16 NORTHAMPTON NN6 7XS Tel: 01788 822301 Fax: 01788 824256 Please keep all packaging sales@garden-products.co.uk until installation is complete www.garden-products.co.uk... - Page 2 Back parts BX2 CX2 Infill plate ’h’ rail Bottom rail FIT THE WASHER UNDER THE HEAD OF ALL HEX HEAD BOLTS UNLESS OTHERWISE INSTRUCTED. Additional Items AX2 BX2 CX2 Handle 725mm Grey watering pipes Front parts BX2 CX2 Watering pack I-SP-1 End parts BX2 CX2...
-
Page 3: End Sections P2
Top leg rests against the FLAT FACE of back leg—it is not bolted to the back leg Slide the tongue YOU ALSO NEED: of the front leg Top leg rests into the groove against flat 10mm BOLTS on the top leg. face of back leg METAL WASHERS NUTS... - Page 4 PARTS NEEDED DO NOT FIT A WASHER AT POINTS MARKED X ON POWDERCOATED UNITS TAKE CARE NOT TO OVERTIGHTEN THESE BOLTS OTHERWISE THE COATING WILL BE DAMAGED FIXING DETAIL USE THE TWO 20MM BOLTS WITH THIS RAIL YOU ALSO NEED: 10mm BOLTS 20mm BOLTS METAL WASHERS...
-
Page 5: End Plates P4
PARTS NEEDED FOR EACH END YOU ALSO NEED: 10mm BOLTS METAL WASHERS NUTS EXPLODED VIEW EXPLODED VIEW Located in pack: SCREW-H1 RIGHT HAND END LEFT HAND END Remove any plastic protective film from the end plates and put ‘Access’ sticker on the large end plates. - Page 6 PARTS NEEDED DO NOT FIT A WASHER AT THE 2 POINTS MARKED X IF POWDERCOATED TAKE CARE NOT TO OVER- TIGHTEN BOLT AS WILL USE 20mm BOLT DAMAGE PAINT YOU ALSO NEED: 10mm BOLTS 20mm BOLTS METAL WASHERS NUTS Located in pack: SCREW-H1 CENTRE LEGS PRIOR TO FITTING Fit legs as shown into the frame.
- Page 7 PARTS NEEDED FULLY TIGHTEN ALL SQUARING THE FRAME BOLTS Use a piece of glass to square the unit up as shown. Slacken the nuts if Anchorage pack FR-AK x 2 necessary to move the framework into a square position. Once the frame is completely square tighten up all the nuts. Remove glass once squaring is complete.
- Page 8 PARTS NEEDED Lipped section Notched edge of first infill plate on BX2 & CX2 PARTS ALSO NEEDED 10mm BOLTS 40mm BOLTS METAL WASHERS NUTS 20mm NYLON SPACERS Located in pack: SCREW-H6 Remove the plastic protective film from the infill plate(s) FIT THE WASHER UNDER THE HEAD OF ALL HEX HEAD BOLTS AX2 model...
-
Page 9: Back Corner Trims P8
PARTS NEEDED Take one of the corner trims and push it up into the back ’h’ rail and the 'h' section. Aluminium corner trims Swing the corner trim so that it is vertical and drops into the channel below. You also need: 2 bags marked as TRIM-4 Plan View Upright leg... -
Page 10: Shelving P9
FITTING The AX2 model has 2 wide full length PARTS NEEDED shelves. Square rod profile The BX2 & CX2 models have 4 wide half Flat face is uppermost support length shelves. Wide shelves: wire miss one hole Lightly tap rawlplug inserts into both ends of the tubular aluminium shelf rods with a hammer. - Page 11 PARTS NEEDED: Choose which end you would like the watering inlet. NOZZLE ASSEMBLY B/CX2 SINGLE TEE TIP: Dip the end of the grey pipe in water. For a BLANKING PLUG better fit, twist the pipes as they are inserted. ‘L’ BRACKET B/CX2 GREY PIPES B/CX2...
- Page 12 FITTING THE CHANNEL LINER The white liner (W66-2M) fits on the inside vertical face of top FRONT rail only. This is a loose fit so strips of double sided tape are included to secure it until the glass is in place. LINER LINER The black plastic liner (W65-5M) goes in the...
- Page 13 WARNING FITTING THE HANDLES WARNING! Toughened glass if broken will fragment safely. If broken, toughened glass will fragment safely. If the edges are knocked or chipped the glass will spontaneously fragment. This is a natural occurrence due to the toughening If the edges are knocked or chipped the glass will process.
-
Page 14: Fitting Handles P12
1” to release it from behind the corner trim. A. Fitting the glass Glass in channel with two Roof glass overlapping sheets overlapping AX2 3’4” Eltham-D BX2 5’0” Eltham-D CX2 6’5” Eltham-D 750mm x 750mm Qty: 2... -
Page 15: Front Corner Trims P14
BLACK ‘WEDGES’ Aluminium corner trims The small black thimble wedges (w) are designed to be pushed into the top channels of the end glass to stop the glass moving. Use two wedges per sheet of glass. You also need: 2 bags marked as TRIM-4 PARTS NEEDED Take one of the corner trims and push it up into the top... - Page 16 CORNER TRIMS WILL NOT FIT The most common cause of this problem is the end glass protruding over the front leg. This is normally caused because the frame work is not square against the wall. See page 7. GLASS STICKS TOGETHER This is normally due to the handles not being put on the right side of the glass.
- Page 17 PERIODIC MAINTENANCE Every Spring take the glass out of the greenhouse and wash glass and framework with warm soapy water. Lubricate the automatic louvre vent bi-monthly and remove if subject to very heavy frosts. When inserting the glass, always check that the glass is properly seated in its top and bottom channels before letting go of the sheet. CHECK THE TIGHTNESS of all bolts regularly, especially in very windy areas or powder coated frames.
