File No.: 12DF100V2
DEFORD New Power Co., Ltd.
Version: A2
Page: 1 of 10
Lithium Iron Phosphate Battery with
Bluetooth Communication for
Leisure & Marine
Customer Code:
P/N
DCU100B-V2
Customer Code
Prepared by
Liang Zhichao
Approved by
Cc Zhou
Company Name
Signature and Date
Customer Approval
Company Stamp
+
®
Li
AGE
is registered trademark of DNP, find us online at:
www.deford.com.cn
Advertisement
Table of Contents
Summary of Contents for DEFORD New Power DCU100B-V2
- Page 1 File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 1 of 10 Lithium Iron Phosphate Battery with Bluetooth Communication for Leisure & Marine Customer Code: DCU100B-V2 Customer Code Prepared by Liang Zhichao Approved by Cc Zhou Company Name...
- Page 2 The specification applies to Li AGE DCU100B-V2 LiFePO4 battery with Bluetooth communication designed and manufactured by DEFORD New Power Co., Ltd (the “DNP”) for universal deep cycle use on RV, caravan, camping, marine. The specification describes the battery mechanical, electrical characteristics and usage.
-
Page 3: Physical And Mechanical Specifications
File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 3 of 10 Discharge Temperature -20℃~60℃ Discharge is cut-off at 65℃ ≤100A Charge Current Recommend: 20A~50A ≤100A for continuous Discharge Current 100A~120A in 10 minutes Peak: >150A in 6 seconds... - Page 4 File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 4 of 10 4. Battery Safety Test 4.1 Test Conditions Temperature: 20±5℃ Relative Humidity(RH): 45% ~75% Atmosphere Pressure: 86kPa ~106kPa All tests are based on UL1973-2013 and IEC62619:2017. 4.2 Tests...
- Page 5 File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 5 of 10 5. Battery Management System (the “BMS”) Item Contents Criteria Overcharge detects voltage 3.75 ± 0.025V Overcharge protection Overcharge release voltage 3.60 ± 0.025V Delay time Over discharge detects voltage 2.80 ±...
- Page 6 File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 6 of 10 6. Battery Drawing (Front & Top) ® is registered trademark of DNP, find us online at: www.deford.com.cn...
- Page 7 File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 7 of 10 7. Battery Bank Application The Li AGE DCU100B-V2 can be connected up in series or parallel when needed but only in the below configurations: Item 1S(12V) 2S(24V) 3S(36V)
-
Page 8: Charging Instructions
8. Charging Instructions When charging Li AGE DCU100B-V2 makes sure that you are not using a charger meant for other Lithium ion chemistries, which are typically set to a higher voltage than required by LiFePO4 batteries. Most mains lead acid battery chargers can be used if the voltage setting is within the parameters of LiFePO4 batteries but some smart chargers might only charge up to 90%. - Page 9 File No.: 12DF100V2 DEFORD New Power Co., Ltd. Version: A2 Page: 9 of 10 9. Accessing the Li AGE App The App is available for iOS and Android phones. Search the Apple App Store for LiAGE and download for free.
-
Page 10: Limited Warranty
Page: 10 of 10 11. Limited Warranty DEFORD New Power Co., Ltd (the “Manufacturer”) warrants this battery for 36 + 24 months from the date of shipping against defective materials or workmanship that may occur under normal use and care.
