Suhyoon MA-120R Manual

MIXER AMPLIFIER FM/AM
RECEIVER
Features
AMPLIFIER SECTION.
■
* Full protection for product reliability
Overload and speaker line short limiter circuit p
Over current limiter circuit
Over heating protection
* Selectable Impedance : 25V,35V,50V,70V and 100V
* Soft start circuit for AC power on
* Output LED indicator
* Input gain volume control for MIC/LINE
* Tone control for MIC/LINE
* Input : 5 balanced Mic (XLR & PL-55) and 2 Aux (RCA) Input : 5 balanced Mic (XLR & PL-55) and 2 Aux (RCA)
* Selectable phantom power microphone
* RCA jack for recording output
* Telephone paging
* Music –on hold CD, tuner
* VOX Mic 1. (Muting for priority) for on/off switch
* Input 4 CH : mic / line control Switch
* Input 5 CH : mic. / CD, tuner control switch
* Master volume control
* Designed for operation either AC mains or DC24V
MA-120/240R
TUNER SECTION
■
* Tuner LCD Display
* LED Backlight g
* Up/Down Switch
* Band Selector FM 1,2,3, AM 1,2
* Memory Switch 1,2,3,4,5,6
