QUARK QKA/2A MKIII
FLASHLIGHT
"C L I C K Y" I NT E R FAC E A ND
O P E R AT I O N
QUARK lights have a "clicky" user
interface – the light is controlled by
clicking or pressing the tail cap switch to
turn the light on or off.
A light "press" on the switch activates
the light in momentary mode. A full
"click" latches the light on or off.
MO D E S A ND M E M O RY
When the light is on, change modes with
a quick off/on cycle (less than 1 second).
Mode memory is a "hybrid" type that
remembers the last setting, but reverts
to mode 1 of the current configuration
on the next mode change.
U SE R PR O G R A M MI NG
The QUARK has six user selectable
configurations. Enter the configuration
menu by cycling the light 10 times in
less than 3 seconds. Use a momentary
"press" (not a "click") when entering
configuration mode. The light blinks a
number of times equal to the configura-
tion number selected. Cycling the
button one time changes to the next
configuration. Leaving the light off for 5
seconds saves the current configuration
to memory.
C O N FI GURATIO N S
(1) High + Burst
(2) Max / Strobe
(3) Medium / High + Burst
(4) Low / Medium / High + Burst
(5) High / Medium / Low + Burst
(6) L/M/H/Strobe/SOS/Beacon + Burst
Please Note: Configuration 2 does not
have Burst mode because the default
output is already 100%.
M O DE S : Q KA ( Q K2A)
Low (Moonlight) = 1.5 Lumens
Medium = 40 (80) Lumens
High = 150 (300) Lumens
Max = 250 (500) Lumens
Burst = 250 (500) Lumens
SOS = International Distress Signal
Strobe = 250 (500) Lumens @ 20Hz
Beacon = 2 blinks every 5 seconds
B URST M O DE (100% O UTP UT)
Typically 100% output is not needed.
Burst mode is a battery saving feature.
If you do need full output, activate burst
mode with two very quick cycles (‹.25
seconds). Burst mode has no memory,
so the light will return to the last saved
mode.
The light maintains Burst Mode for 30
seconds and then ramps down to High
mode over the next 30 seconds to
prevent over heating.
LO W BATT ERY WARN IN G
The driver does not have a built in low
battery warning. If the light dims, fails to
activate, or begins to blink, the battery
needs to be replaced/recharged.
Best practice is to replace/recharge
the battery before it is completely
empty. Modern rechargeable batteries
will last longer if you recharge them
before they are fully depleted.
Blinking is caused by the light powering
on/off and may cause the light to
accidentally enter the configuration
menu and change the saved program.
BAT TERY I NSTA LLATIO N
The battery should be installed with the
(+) terminal facing the head. NEVER
install batteries backwards.
BAT TERY C OM PAT IBIL ITY
The best battery to use is the NiMH
rechargeable
provided
with
your
flashlight. To purchase batteries and
chargers, please visit the link at the
bottom of the next page.
Alkaline batteries will power QUARK
lights, however they release corrosive
gas during discharge, are prone to
leaking, and will eventually destroy the
light.
