Summary of Contents for Fetaphon Fetaphon

Page 1 User Guide...
Page 2: Table Of Contents
......30 Control button, activating the device ..09 Short instructions for Fetaphon use ... . 31 Main Menu .
Page 3: Fetaphon Introduction
• Th e CTG test which you do with Fetaphon can be easily evaluated by your own obstetrician/gynaecologyst/physician, even without being present when examination is performed. Th e evaluation is done via highly protected Internet interface of Fetaphon device.
Page 4: Fetaphon Operation
Fetaphon operation Fetaphon operation is based on unique, newly developed Hungarian patented process, operating on an absolutely passive principle. This means that it does not emit any kind of radiation (not even ultra sound). The measurement head (transducer) is a highly...
Page 5 GSM network please place the device in a place where adequate mobile (GSM) network is assured. Operational scheme of Fetaphon system Important: for more information about mobile network coverage please contact our Customer Service +36/30-462-22-03...
Page 6: Preparing For The Test
Preparing for the test • Relax • Sit or lay back comfortably, as can be seen in the picture (ﬁ g 1). Th e measurement process takes 20 minutes • Put the ﬁ rst belt around your belly, right on dry and clean skin, in the height of your navel, so that the smooth side of the velcro can touch directly the skin.
Page 7 • If you need to replace the mushroom-shape sensor base, pull it straight out from the trans- ducer and push the appropriate mushroom-shape base fully into place (fig 6–8). • Place the fetal heartbeat transducer marked with (ﬁ g 9–10) on lower elastic harness. To secure it on the harness, hold the hemisphere-shape transducer in your hand so the white ring-shape base of the hemisphere would look towards Your belly and the cabel of the transducer would look upwards.
Page 8: Fetaphon Placement
Fetaphon placement • Place the device on a solid base where it is clearly visible and easy to access - you should have an easily access to the control button. • Use the back cover to ensure stable placement. •...
Page 9: Control Button, Activating The Device
• Fetaphon has no on/off button • Fetaphon device is already switched on, in a so-called standby mode. This state is indicated by the flashing dim light in the centre of the control button. • The device can be operated using the control button next to the display.
Page 10 • Leave the device connected to the power supply Important: if Fetaphon display is dark and until the battery charge reaches 30%. As soon you fail to activate the device after pressing as the battery is recharged, the device can be...
Page 11: Main Menu
Main menu • Menu selection is possible with pressing the upper or down part of the control button. A thick strip indicates the se- Main Menu lected menu item. Test : • After selecting the menu item, enter “Demo”, press on the Read message: Demo:...
Page 12 • The hours shown on the display of the Fetaphon unit is for information only, and is not related to the exact time of the measurement input. If the time and date shown on the display is reset, make sure you inform your doctor about it and contact our Customer Service.
Page 13 Menu selection to start the test • Menu selection is possible with pressing the upper or down part of the control button. A thick strip indicates the selected menu item. After selecting the menu item, enter “Test” and start the measurement process, press on the control button.
Page 14: Detecting And Listening Of Fetal Heartbeat
Locating and listening to fetal heart beat • The most important momentum in the test is to find the point on the abdominal wall where the fetal heartbeat can be heard at the loudest. • Patience! Sometimes it may take a minute, sometimes much more time, but the effort invested has its return during the test.
Page 15 • When locating the fetal heartbeat, it is recommended to set the „Volume” Important: Prior to the level low (about 3) in the displayed menu, otherwise the noise detected by test, listen to the sound the device may be so strong that the real heartbeat won’t be heard properly. sample available in the •...
Page 16: Conducting The Test
Locating heartbeat without conducting the test • If you use Fetaphon, you can locate the heartbeat of the fetus even without conducting the test! • For this please enter Main Menu, and select „Start”, but do not select the option! Now You will be able to hear the fetal heartbeat after the fetal heartbeat transducer is attached on Your belly as explained above.
Page 17 Conducting the test • Select the „Test” menu item in the „Main Menu” by pushing the Important: If You can also hear button, otherwise the fetal heartbeat won’t be heard. your heartbeat beside the fe- • Th e device can distinguish between the fetal and the maternal tal heartbeat of an appropriate heartbeats.
Page 18: Signalling Fetal Movements During Test
Signalling fetal movements during the measurement process • If the fetus moves during the test, please, indicate it by shortly pushing the right side of the control button. Indication of fetal motions essential for evaluation of the test. Pushing the OK button increases the number in “Move”section on display by one.
Page 19: Pausing / Stopping / Ending The Test
Pausing / stopping the test • When the heartbeat is diﬃ cult to to be heard or it is completely Important: measurements com- gone, pause the test by pushing the left side of the control button once. Pausing the test results in the “Continue” status pleted sooner than 20 minutes shown at the display.
Page 20: Factors Affecting The Measurement
Factors affecting the measurement 1. Ambient noise. The fetal heartbeat transducer is very sensitive, so loud ambient noise may lead to faulty measurement. 2. Movement. Relax for the measurement, and do not move while the testing is carried out. Enjoy listening to the calming little heartbeats of Your unborn child peacefully.
Page 21: Sending Test Data, Battery Recharge
If the charger cannot be connected, the device will automatically return to the Main Menu in 2 minutes and it will enter standby mode in 1 more minute, and the display will go blank. The Fetaphon device stores the tests conducted and automatically transfers the results when the charger is connected.
Page 22 Sending measurement results is indicated by “Data transfer to start” message on the display. At this point, the modem integrated into Fetaphon device activates and connects to the mobile (GSM) network. Then it sends the test results to Fetaphon internet server. (Measurements shorter than 5 minutes will not be stored and sent by the device.) •...
Page 23 • At periods between tests, keep the device connected to the charger whenever pos- sible. • The batteries can not be overcharged! The battery status is indicated by an icon in the upper right corner of the display. Important: in case the device is not used for a long period make sure that the battery doesn’t go completely flat, as this may cause fatal damage...
Page 24: Reading Message
Reading message • Fetaphon device can only receive messages when it is connected to the charger. Choose “Read message” sub- menu. Enter sub-menu by pushing the OK button. • The message is sent by the physician who carries out the evaluation of test results via internet to the display of Fetaphon device.
Page 25 Important: Fetaphon device can receive messages only when it is connected to the charger. For data transfer process mobile (GSM) net- work coverage is necessary.
Page 26: Most Common Errors
Most common errors If You find that The problem is the following What to do • Th e display remains dark even after • Th e battery is low • Connect the device to the charger. pressing the on the control button •...
Page 27 If You find that The problem is the following What to do • A crackling noise is heard, which • Th e connecting cable of the trans- • Adjust the cable ensuring that it does coincides with my breathing ducer is chafed by something not touches anything, if possible •...
Page 28: Fetaphon Maintenance And Cleaning
Fetaphon maintenance and cleaning Maintenance of the device is not required. If the device is damaged, please notify Your doctor. Cleaning: Important: • Carrier bag: If the bag bacame dirty - re- don’t use move rough dirt dry with a soft brush, then damaged device! use a cloth wet with warm soapy water.
Page 29: Accessories
2 transducers with connector • 2 elastic harnesses with velcros • Special charger for the charging of Fetaphon device, connectible to the electrical power supply network. • 2 mushroom shaped bases (1 shorter, 1 longer base) for suitable for detecting uterine contractions.
Page 30: Fetaphon Techical Data
Fetaphon technical data • Fetal heartbeat transducer sensitivity: 5mV/N/m • Limits of uterine contractions sensitivity: 10-900g • Audio output power: max: 1W • Operating temperature: 15-40 oC • Storage temperature: 0-40 oC • Charger input voltage and current: 100-240 VAC, 50-60Hz, max.
Page 31: Short Instructions For Fetaphon Use
Short instructions for fetaphon* use Apply the measurement heads on clean and dry skin. Start the measurement only if the feat heartbeat can be heard properly and without interruptions! Do not use cream or gel as this would damage the heads and make them unusable.
