Page 1: Table Of Contents
As usual we ask you to study this manual to familiarise yourself with the operating controls of the unit. For further in depth knowledge of how to use the HomeMix, please read the contents of this manual in its entirety.
Page 2: Safety Instructions
SAFETY INS TRUCTIONS EXPLANATION OF SYMBOLS • Heed Warnings. All warnings on the appliance and in the operating This symbol is intended to alert the user instructions should be adhered to. of the presence of uninsulated “dangerous voltage” within the product’s encasement that •...
Page 3 ENGLISH SAFETY INS TRUCTIONS • Do not use a cart or stand not HAVE THE UNIT SERVICED IF: recommended by the manufacturer. • The power cord or the plug has been damaged. • Do not try to roll cart with small castors •...
Page 4 SAFETY INS TRUCTIONS For your convenience a mains plug with a fuse has been fitted to this appliance. For your safety please PLUG FITTING observe the following information. (UK ONL Y) • Should the fuse fail in the plug remove it from the wall socket and replace the fuse with a 3 Amp ASTA approved BS 1362 fuse.
Page 5: Connections
Please observe the correct orientation which is indicated on the base of the chassis. Batteries are liable to leakage, so please remove from the CDJ-1 if it will not be used for long periods of time. Also remove when discharged. The CDJ-1 requires a large amount of current to operate at high volume levels.
Page 6 It is necessary to bring the processed signal back into the CDJ-1, this can be done by using another set of phono leads to connect to the output of the effects unit to the FX return sockets on the CDJ-1.
Page 7: Cd Controls
CD CONTROLS 1/11. CD LID OPEN BUTTON 8/16. PITCH ACTIVATION The CDJ-1 is fitted with a spring catch which is Hold this button down, and by repeatedly pushed down to release the CD door. To close pressing the PITCH BEND UP or PITCH BEND...
Page 8: Mixer Control Panel
�� 33. MEMORY KEY 24. MIC LEVEL �� The CDJ-1 has 8 memory locations for the radio Rotate the mic level knob to adjust the mic level �� tuner. up or down. To save a radio station to memory, first use the 25.
Page 9: Tape Control Panel
ENGLISH T APE CONTROL PANEL 37. CASSETTE DOOR The CDJ-1 is fitted with an acrylic cassette door. Care should be taken not to exert excessive force on this door which may cause it to snap, or damage the hinge mechanism.
Page 10: Troubleshooting
12 o’clock. batteries are in good condition. NO VOLUME In the event of any problems installing or using the CDJ-1, please • Check the main VOLUME knob on the unit is turned up.
Page 11: Specifications
ENGLISH SPECIFICA TIONS POWER OUTPUT: 2 x 5 Watts RMS @ 10% THD. 25 Watts total music power. AMP OUTPUT: 775 mV. SEND OUTPUT: 500 mV. RETURN INPUT: 500 mV. TREBLE RANGE: + / - 6 dB at centre frequency 10 K Hz. BASS RANGE: + / - 6 dB at centre frequency 100 Hz.
