Airtecnic ENERGY BOX AC-A Operation Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

ENERGY BOX AC-A

ENERGY BOX AC

Ceiling Type Heat / Energy Recovery Unit

with Heat Pump

ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ

OPERATION MANUAL

500

750

1.000

1.500

2.000

3.000

4.000

www.airtechnic.gr

www.facebook.com/Airtechnic.gr

V. 4

Table of Contents

Need help?

Do you have a question about the ENERGY BOX AC-A and is the answer not in the manual?

Questions and answers

Summary of Contents for Airtecnic ENERGY BOX AC-A

Page 1 ENERGY BOX AC-A ENERGY BOX AC Ceiling Type Heat / Energy Recovery Unit with Heat Pump ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ OPERATION MANUAL 1.000 1.500 2.000 3.000 4.000 www.airtechnic.gr www.facebook.com/Airtechnic.gr V. 4...
Page 2: Table Of Contents
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r INDEX Introduction ............................2 Warnings & Safety Informations ....................3 Check List ............................5 Technical Specifications AC Fan ....................6 Unit Dimensions AC Fan .......................7 Technical Specifications EC Fan ....................8 Unit Dimensions EC Fan .......................9 Installatıon ............................10...
Page 3: Warnings & Safety Informations
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r WARNINGS & SAFETY INFORMATION PROHIBITED • This unit has to be used under proper conditions according to its technical specification and design purpose.
Page 4 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r • This product must not be disassembled under any circumstances. Only authorized repair technicans are qualified to conduct disassembly and repairs.
Page 5: Check List
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r CHECK LIST In the event of unit failure and pre-commissioning checks to be made are determined as follows; after checking this information, please contact our company in case failure continues. Controls 1.
Page 6: Technical Specifications Ac Fan
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r TECHNICAL SPECIFICATIONS - AC FAN ENERGY- AC-Α/ AC AC-Α/AC AC-Α/AC AC-Α/AC AC-Α/AC AC-Α/AC AC-Α/AC 1.000 1.500 2.000 3.000 4.000 Air Flow (m³/h) 1.000 1.500 2.000...
Page 7: Unit Dimensions Ac Fan
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r UNIT DIMENSIONS - AC FAN ENERGY-BOX AC-A / AC Ø D 1.250 1.000 1.250 1.000 1.000 1.400 1300 * All measurement values are mm. * The gaps of the service area values are specified as “S”...
Page 8: Technical Specifications Ec Fan
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r TECHNICAL SPECIFICATIONS - EC FAN AC-Α / AC AC-Α / AC AC-Α / AC AC-Α / AC AC-Α / AC AC-Α / AC AC-Α / AC ENERGY-BOX 500 EC 750 EC 1.000 EC 1.500 EC 2.000 EC 3.000 EC...
Page 9: Unit Dimensions Ec Fan
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r UNIT DIMENSIONS - EC FAN ENERGY-BOX AC / AC-Α Ø D 1.250 1.000 1.250 1.000 1.000 1.400 1.300 * All measurement values are mm. * The gaps of the service area values are specified as “S”...
Page 10: Installatıon
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r INSTALLATION ØD ØD NOT: * Top view * Fan access panels are under the unit. * The gaps of the maintenance area are specified as “S” on the technical picture. (”Unit Dimension”...
Page 11 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r continue to next page >> +30 211 70 55 500 / +30 2311 82 40 00 w w w . a i r t e c h n i c . g r ...
Page 12 WARNING Before attaching the duct connection flanges, check that no foreign matter has found. Energy Box AC-A / AC Anchor Bolt INSTALLATION OF THE UNIT Series Unit Hang the unit on the anchor bolts and adjust in such a way that the unit is installed horizontally.
Page 13: Selection Of Electrıcal Cable Cross-Section
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r SELECTION OF ELECTRICAL CABLE CROSS-SECTION (energy BOX AC-A / AC) ENERGY- Unit Cable Cross- Unit Power Input Current Fuse Voltage Section(mm²)
Page 14 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r CABLE CROSS-SECTION FORMULAS 100.P.L 100.P.L I cable > I fuse ≥ I current I current ꞊ %e ꞊ k.S.U² , S ꞊ k.%e.U²...
Page 15 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r CABLE CROSS-SECTION FORMULAS 100.P.L 100.P.L I cable > I fuse ≥ I current I current ꞊ %e ꞊ k.S.U² , S ꞊ U.CosQ k.%e.U²...
Page 16 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r SELECTION OF ELECTRICAL CABLE CROSS-SECTION (energy BOX AC-A EC / AC EC) ENERGY-BOX Unit Cable Cross-Section Unit Power Input...
Page 17 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r CABLE CROSS-SECTION FORMULAS 100.P.L 100.P.L I cable > I fuse ≥ I current I current ꞊ %e ꞊ k.S.U² , S ꞊ k.%e.U²...
Page 18: Electrical Connection
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r ELECTRICAL CONNECTION System Connection 1- Cut the gaskets in cable connection hole from the center. 2- Pass the on/off switch cables through the cable connection hole. 3- Connect the main power cable and ground wires to the terminals in the junction box.
Page 19 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α / AC-500/750/1.000 Units Crankcase Heater Pressure Switch 4 Way Valve Filter Faut OA Thermistor RA Thermistor...
Page 20 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α / AC-500/750/1.000 Units Crankcase Heater Pressure Switch 4 Way Valve Filter Faut OA Thermistor RA Thermistor...
Page 21 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α/ AC-3.000/4.000 Units Crankcase Heater Pressure S witch 4 Way Valve Filter Faut OA Thermistor RA Thermistor...
Page 22 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α / AC-500 EC Unit Crankcase Heater Pressure Switch 4 Way Valve Filter Faut OA Thermistor RA Thermistor...
Page 23 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α / AC-750 EC/1.000 EC/1.500 EC/2.000 EC Units Crankcase Heater Pressure Switch 4 Way Valve Filter Faut...
Page 24 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α/ AC-3.000 EC Unit Crankcase Heater Pressure Switch 4 Way Valve Filter Faut OA Thermistor RA Thermistor...
Page 25 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Wiring Diagram With AIRTECHNIC DX Control Card For ENERGY-BOX AC-Α / AC-4.000 EC Unit Crankcase Heater Pressure Switch 4 Way Valve Filter Faut OA Thermistor RA Thermistor...
Page 26: Control-Dx
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r CONTROL-DX Operation Description Basic Panel Pro Panel 3 steps fan speed control of supply and exhaust fan is 3 steps (2 fans) Fan Speed Control available.
Page 27 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Fan Speed Control Function: Control board has 4 different fan speeds: “low”, “medium”, “high”, “boost”. These fan speeds are set to specific values by default. The maximum fan speed is “boost”. If it is desired to change fan speeds, “low”...
Page 28 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r By-pass Function (Optional) By-pass function only exists on units which have by-pass module. It is used when filtered fresh air is desired to be supplied to indoor without passing through heat exchanger (transition seasons).
Page 29 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Boost Function This function is used when large amount of exhaust and fresh air is needed (at the time of using kitchen/bathroom/wc, etc.) while ventilation is still going on.
Page 30 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Log Function Log Function is available on Pro Panel. It records all the activity of the unit as date and hour.
Page 31 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Basic Panel Control Functions 1.ON/OFF: Press for 3 seconds. 2. Press to increase fan speed. 3. Press to decrease fan speed. 4.
Page 32 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Pro Panel Control Functions WARNING Please connect 1. ON / OFF: Press for 3 seconds. the Pro Panel when unit is off.
Page 33 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Pro Panel Screen 1. Screen 2. Screen 3. Screen 4. Screen Screen Brightness Screen Brightness Timer Company Introduction and Contrast Setting 1.Screen Symbols (Main Screen) Standard mode Supply fan...
Page 34 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r There is no Outdoor air pre-heater. temperature Indoor air Pre-heater is off. temperature Pre-heater is on. Set temperature Compressor is off. There is no (Cooling mode) by-pass.
Page 35 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r 2.Screen Symbols (Timer) TIMER is off TIMER is on: 5 weekdays Start-up time of unit TIMER is on: Shut down time of unit Weekdays+Saturdays Time hh.mm.ss TIMER is on: All days...
Page 36 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Error Code List Register 25 Pro Panel Description Value Screen Code ----- Unit is working normally. ERR 1 Fire alarm ERR 2 Heater alarm ERR 3...
Page 37 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r 3. Physical Connection Communication network is showed below. Control board can be connected to RS485 on which is connected more than one unit.Address conflicts on this line should be removed and necessary software settings should be done for data communication.
Page 38 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Table 3,2 Function 03 Transfer Package Example Master Transfer Address Function Code Register ID Data Length Failure Control Information 0 x 01 0 x 03 0 x 00,0 x 02...
Page 39 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Modbus Register List * Pro-Panel register values ** DX unit register values +30 211 70 55 500 / +30 2311 82 40 00 w w w .
Page 40 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Basic Panel Dimensions 90 mm 15 mm 65 mm Pro Panel Dimensions 82 mm 24 mm 106 mm w w w . a i r t e c h n i c . g r +30 211 70 55 500 / +30 2311 82 40 00 ...
Page 41 Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r Basic Panel Installation Pro Panel Installation +30 211 70 55 500 / +30 2311 82 40 00 w w w . a i r t e c h n i c . g r ...
Page 42: Maintenance
Energy Box AC-Α, AC w w w . a i r t e c h n i c . g r MAINTENANCE • Turn off all the power switches before the maintenance is performed. • Do not operate the system without the air filter to protect the components of the unit against being clogged.
