Summary of Contents for Fuzi Kimiko
- Page 1 The World’s Most Advanced Massage Chairs ® User Manual Kimiko Massage Chair...
- Page 2 Staying Safe Important Safety Instructions Read all instructions before using this appliance. When using and electrical appliance, basic precautions should always be followed, including the following: – To reduce the risk of electric shock: DANGER Always unplug this appliance from the electrical outlet immediately after using and before cleaning. WARNING –...
- Page 3 Staying Safe SAVE THESE INSTRUCTIONS. Not Suitable For Below Persons We recommend those with any of the following conditions consult your physician before using. - Those who are using electronic medical instruments embedded in the body, such as a cardiac pacemaker.
- Page 4 Staying Safe Best Practices for Safe Use - Only for users who weigh below 300 lbs. - Appliance should only be used by one person, do not use by two or more persons at the same time to avoid damage to the product. - Do not use the product right after a meal, it may cause discomfort.
- Page 5 Your Chair External Structure Remote Control...
- Page 6 Thank you, and congratulations on purchasing your very own Fuzi Massage Chair product - you’ve made a great buying decision. Welcome to the Fuzi family. Inside this manual, you will find everything you need to setup and safely enjoy your chair.
- Page 7 Table of Contents - 43” L-Track - Zero Gravity - Zero Wall Space-saving Technology - Calf Rollers & Oscillation - Bluetooth Technology - Decompression Stretch - Reflexology - Automatic Footrest Extension - USB Charging Port - Lumbar Heat - Body Scanning - Four Wheel Massage Mechanism - Airbag Compression Therapy - Intelligent Voice Control...
-
Page 8: Table Of Contents
Table of Contents Contents Installation Site ......................................9 Clearance Space for the Chair ................................9 Floor Protection ..................................... 9 Move Methods ..................................... 10 Connect to Power ....................................10 Getting Comfortable ....................................11 Main Power Switch ....................................11 Adjust Pillow ....................................... 11 Body Scanning ..................................... -
Page 9: Installation Site
Preparations Installation Site Clearance Space for the Chair - 2” clearance for the recline of the backrest; 14” clearance for the extension of footrest and sliding forward of the chair. - Keep it 3 feet away from the TV, radio or other audio & video appliance to avoid signal interference. -
Page 10: Move Methods
Preparation Move Methods Apply pressure to the back of the massage chair from behind to pivot on the Castors. Have a second person up front to guide the Footrest until in the correct position. Maintain clearances as mentioned above. Gently lower into place. Do not pull on the side arms. -
Page 11: Getting Comfortable
Chair Setup Getting Comfortable Main Power Switch To power up the chair, flick the main power switch located on the back of the base of the chair to ON. - Children should be supervised to ensure that they do not play with the chair or touch the power box. - Always unplug the massage chair from the electrical outlet immediately after use. -
Page 12: Body Scanning
Chair Setup Body Scanning Select any auto program and press the OK button. The chair will automatically begin scanning your body, mapping your back, shoulders, and neck. During this process it is important to remain seated back into the chair without lifting your head. The scan can be viewed on the remote control screen. -
Page 13: Auto Programs
Getting Started Auto Programs When massage chair is operating, press the AUTO button on the remote control to enter Auto Program Menu. Choose from Quick, Full Body, Rest & Relax, Recharge, Recovery, Stretch, Neck & Shoulder, Back Relief, Lower Body, Stress Relief, Renew, and Athlete. - Page 14 Getting Started What for? Description A quick way to feel all the massage techniques and chair Rapid demonstration of all massage techniques and chair movements in a brief 8 minute session. motions. This program is the best choice to relax tired muscles and Comprehensive massage session using deep tissue increase physical vigor.
-
Page 15: Airbag Massage
Getting Started Airbag Massage Select AIR MASSAGE from Home display, press up or down button to navigate among: POSITION and INTENSITY. Airbag Region Navigate to POSITION, press right button, then use the up or down button to select your desired airbag region: Full Body, Upper Body, or Lower Body. Press OK button to select the airbag region Airbag Intensity Navigate to INTENSITY, press right button, then use the up or down button to select... -
Page 16: Foot Rollers
Getting Started Foot Rollers Select MANUAL PROGRAM from Home display, press right button, and then use the up or down button to navigate to FOOT ROLLERS. Press right button, then use the up and down buttons to select your desired foot roller speed: 1 = slow, 2, 3 = fast, or OFF (deactivate foot roller). -
Page 17: Intelligent Voice Control
20 minutes of an auto program ending. To activate the intelligent voice control function, simply say ‘Hey Fuzi’, pronounced ‘Fu-zi’, or press the voice control Turn Off Listening button on the remote control. You may now give your chair At any time, simply press and hold the any of the commands below within 6 seconds. -
Page 18: Intelligent Voice Control
Getting Started Intelligent Voice Control Your chair has the ability to save your favorite customized massage programs to memory. To create a custom memory setting you first need to set up the chair for what it is you want to record. To do this, create a manual massage program with all of your desired air, heat, speed, and intensity settings. -
Page 19: Setting Tool
Settings Setting Tool Select SETTING TOOL from Home display, then use the up or down button to toggle between TIMER, LANGUAGE, BLUETOOTH, or BEEP. Timer Navigate to TIMER, press right button, then press up or down button to select your desired timer: 10 minutes, 20 minutes, or 30 minutes. -
Page 20: Bluetooth Audio
Bluetooth setting: On or Off. Press OK button to select Bluetooth setting. Open Bluetooth from audio device and pair with Kimiko Massage Chair to play music. Remote Control Beep Navigate to BEEP, press right button, then use the up or down button to select your desired remote control beep function: On or Off. -
Page 21: Manual Programs
Create a Massage Manual Programs Select MANUAL PROGRAM from Home display, press up or down button to navigate among: MODE, POSITION, SPEED, WIDTH, FOOT ROLLERS, and CALF ROLLERS. Massage Mode Navigate to MODE, press right button, then use the up or down button to select your desired mode: 360°... -
Page 22: Massage Speed
Create a Massage Massage Speed Navigate to SPEED, press right button, then use the up or down button to select your desired speed: 1 = slowest, 2, 3, 4, 5 = fastest. Press OK button to select the speed. (Massage speed can only be adjusted when in manual mode). Massage Width Navigate to WIDTH, press right button, then use the up or down button to select your desired roller width: Wide, Medium, or Narrow. -
Page 23: Trouble Shooting
Fixing Issues Trouble Shooting Symptoms Possible Causes Possible Solution These noises are normal and arise No need to take any measures Noise is heard while in use from friction between the massage rollers and the leather cover Massage Chair does not The power cord is not secured into the Insert the power plug properly into the power Start... -
Page 24: Frequently Asked Questions
To do this power down the chair and unplug from the wall for 5 minutes then plug back in and power back up to see if it self-healed. If you are still having an issue, give Fuzi Massage Chair a call at 714-855-5456. - Page 25 The World’s Most ® Advanced Massage Chairs 11801 Westminster Ave, Garden Grove, CA 92843 Tel: (714) 855-5456 www.fuzichair.com...
