- Page 1 The way a cabinet should sound UCoustic Sound Proof Enclosures ™ 9210 Manual...
- Page 2 The way a cabinet should sound UCoustic 9210 Floor Standing Cabinet ™ Thank you and congratulations for purchasing the UCoustic 9210 freestanding acoustic cabinet. Please follow these simple recommendations in order to get the best from your new enclosure. Handling...
- Page 3 Infill foam Left side infill Left side infill Quick fit soundproof blanking panels Pic 1 Front view UCoustic 9210 complete with blanking panels Order codes for soundproof 19” quick fit blanking panels are as follows: 1U RA0-0201-AA 2U RA0-0202-AA 3U RA0-0203-AA...
- Page 4 The way a cabinet should sound Cable Management: The UCoustic 9210 is fitted with six cable entry positions, three on both the lid and base, fitted to the rear and to each side of the cabinet (see Gland Pic 2)
- Page 5 Keep cable bundle flat where possible when passing through foam blocks Pic.6 Front to rear cable Infill foam Top right hand side front shown Keep cables flat where possible Pic. 7. Cable entry box. Rear base shown UCoustic 9210 manual V1...
- Page 6 NB. All accessories can be factory fitted. These along with other accessories can be purchased through your supplier/distributor or direct from USystems Ltd. 300mm Cable tray Pic 8 Side cable management and cable entry 150mm cable tray shown UCoustic 9210 manual V1...
- Page 7 USystems Ltd. Pic 11 Cable trunking can be Pic 10 Cable trunking fitted to front infills (front view of 8250 wall box shown). Cut to any length required UCoustic 9210 manual V1...
