MBSX100 Bale Splitter
Operators Manual
The Maxilator Bale Splitter MBSX100 is an ideal
system for feeding round bales. The bale splitter
grips the plastic while splitting the bale in half for
easy feeding in feed rings, alleys and mixer
wagons. This system saves time and labor while
increasing safety. The bale splitter can reduce
mixing times by up to 70 percent while reducing
wear and tear on your equipment.
Skid Steer Attachment and Connections
Skid Steer Attachment
To mount the bale splitter, simply line up your loader's mounting plate to the rear mount-
ing plate, engage the attachment wedges, and lower levers until they're locked securely
in place.
Hydraulic Connections
Maxilator is a Division of
605 Stonehill Drive SW, Atlanta, Georgia 30336 www.tiedown.com • 800-241-1806 • 404-344-0000
1-866-HAYBALE (1-866-429-2253)
TM
www.maxilator.com • Info@maxilator.com
Specifications
Height open: 79"
Width:
44"
Weight:
1065 lbs
TIE DOWN ENGINEERING
Height closed:
Length:
Hydraulic Connection:
39"
83"
Double acting
Advertisement
Summary of Contents for MAXILATOR MBSX100
- Page 1 • Info@maxilator.com MBSX100 Bale Splitter Operators Manual The Maxilator Bale Splitter MBSX100 is an ideal system for feeding round bales. The bale splitter grips the plastic while splitting the bale in half for easy feeding in feed rings, alleys and mixer wagons.
- Page 2 (Pict 5). 13. All that should be left on the splitter is the wrap. Engage servo valve and release wrap (Pict 6). Pict. 4 Pict. 5 Pict. 6 1-866-HAYBALE (1-866-429-2253) www.maxilator.com • Info@maxilator.com...
- Page 3 Maxilator Equipment LLC is a Division of Tie Down Engineering (TIE DOWN Inc.), here after referred to as “TIE DOWN”. TIE DOWN will repair or replace, free of charge, any part, or parts of the Maxilator Bale Splitter that are defective in material or workmanship or both for 90 days from date of purchase.
- Page 4 MBSX100 Bale Splitter Replacement Parts To order replacement parts: contact TIE DOWN ENGINEERING Customer Service (800) 241-1806 or (404) 344-0000. Bale Splitter Bale Splitter Frame Weldment Cutting Arm Weldment Part #MAX-MKX1 Part #MAX-MKX2 Bale Splitter Cross Bar Bale Splitter Cutting Teeth...
