- Page 2 C-960 Crimper Press Thank You for purchasing the C-960 Swan-Matic Crimper and Corking Press. The C960 is proudly built in the USA by Automation Devices in Fairview, PA. For any technique assistance please feel free to call 814-474-5561. Contents Set-up ………………………..………..…………………….. 3 Maintenance ………………………….…………………….
- Page 3 Set-up and Operation Instruction Carefully unpack the m a c h i n e and any other associated equipment which may be in the container and check for damage. Set the machine on a level surface. Please observe all a safety regulations in your facility. Do not place fingers between ram head and cap/cork being pressed.
- Page 4 The fill cap is the small Philips screw on top of the oiler. Fill to the top of the glass bowl. Put cap back on. The oil flow adjustment has a range of 0-10. Swan-Matic machines are designed to run at <1 on the dial. Just below the adjustment knob there is a sight glass.
- Page 5 SWAN-MATIC WARRANTY Automation Devices, Inc. warrants the materials and goods supplied under the subject customer’s purchase order to be as specified and of good quality. No specific time life shall be stated, since the results of good workmanship are of timeless age, and good quality, properly used, shall be self-evident.
- Page 6 C960 Insert Press 1008 Isolator Foot C901 Main Column C902L Base Plate, Left C902R Base Plate, Right C903 Base Plate, Front Rail C904 Column Support Bracket 6 Hole C908 V Block Mount Bracket C909 V Block Back Stop C910 Bolt Assembly: M8 x 16.00mm Black...
- Page 7 C960 “The Bopper”...
- Page 8 Machine Specifications C960 “The Bopper” By Swan-Matic Cycles per Minute Variable Speed 45 cpm max Down Force 279lbs @ 100psi Stroke 2” inches Weight 20 lbs Shipping weight 30 lbs Finish Hard Anodize Black Air Supply Clean 130psi max...
