Summary of Contents for ambient power AP087
- Page 1 16th December 2020 Lighting Controller User Manual Page of Lighting Controller User Manual AP087 Ambient Power E&OE...
- Page 2 16th December 2020 Lighting Controller User Manual Page of Table of Contents Introduction Connections Power Requirements Configuring The Module Storing In Memory Resetting To Factory Default Mode Reference Table Fixing Method Specifications Ambient Power E&OE...
- Page 3 Resetting To Factory Default Press and hold button 1 while switching on power. The board will reset to Mode 3 (Medium Warm Light). The colour cycle flash confirms the board reset. Ambient Power E&OE...
- Page 4 Do not use conductive tapes or adhesives. Avoid obscuring the LED as light output will be reduced, and consider if access to configuration pins is required. Specifications Dimensions - W 11.0mm, H 10.8mm, D 3.0mm Weight - 5g Voltage - 12V DC Current - 25mA Ambient Power E&OE...
