Summary of Contents for Fabman Bridge FB-V2
- Page 1 Fabman Bridge FB-V2 User Manual...
-
Page 2: Safety Instructions
1. Introduction The Fabman Bridge acts as an authorization device for the Fabman web application. It is connected to the internet over WiFi. After successful user authorization and granted access it powers an external load, which can be a machine like a laser cutter or milling machine, a door lock or any other electrically powered device. - Page 3 • Never position the product in direct vicinity of a bathtub, shower, bathroom, swimming pool, or similar. Lethal hazard due to electric shock. • The product must not be exposed to extremes of temperature, direct sunlight or strong vibrations. Keep the product away from strong magnetic fields generated by machines, electric motors or loudspeakers.
-
Page 4: Operation
You need a power outlet close to the Fabman Bridge. 3.2. Sign Up for a Fabman Account If you haven’t done it yet, sign up for a free Fabman Account on our website www.fabman.io. Click the “Try it for FREE”-Button and follow the instructions on the screen. - Page 5 Once the setup is complete, the bridge will begin pairing and will display a pairing code. You can then use this code and assign the Fabman bridge to your equipment such as a laser cutter or a 3D printer in just a few steps: •...
- Page 6 Click on “Assign a key” on the member’s details page and follow the instructions. Now you can test the Fabman bridge by swiping your member card close to the RFID symbol on the enclosure. If the configuration is correct, the bridge will switch on and show your name on the display.
- Page 7 More detailed setup instructions can be found at www.fabman.io/setup...
-
Page 8: Technical Data
4. Technical Data ELECTRICAL Rated input/output 100 V – 240 V AC, 50/60 Hz Max. load current 10 A / 16 A* Power monitor, max. threshold value Self-consumption standby/maximum 4W / 7W Operating conditions 0 to +40 °C, 0 to 75 % relative humidity, non-condensing Storage conditions -20 to +50 °C, 0 to 75 % relative humidity, non-condensing * up to 16A if the power supply is connected to the mains directly instead of using the cold-device plugs. - Page 9 • Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved in this manual could void the user's authority to operate the equipment. Fabman GmbH E-Mail: contact@fabman.io VAT-number: ATU70870934 Registration number: FN 451448w...
