COMFREE PH-5050-BL Quick Start Manual

Model
Name
Speaker spe.
Rated power of speaker
Rated power of headphone
SNR
Degree of separation
Working hours for outside sound
Distortion
Working hours of headphone
polymer lithium ion battery
Charging Voltage
Charging hours
Applicable device
Frequency response
Audio input port
BT solution CSR
BT distance
Microphone
Recharging:
When used as a general headset, it is not required to power.
When used as a speaker, it is necessary to supply power.
The headphone with a powerful amplified speaker, the speaker is energized by
a durable rechargeable Li-Polymer battery.
Blue LED for power-on and Red LED for charging indication; when fully charged red
Main Function
LED will go off; when the voltage is low, the blue LED flashes and a voice
"Batterylow" from the speaker(in speaker mode).

Bluetooth operation:

1. Activate your phone's Bluetooth function and enter its searching mode.
2. Press and hold the play/pause button on your headset until a voice "hello" from the speaker (in
speaker mode)—this will activate the pairing mode.
3. Your mobile phone will automatically find a new Bluetooth device called "PH-5050BL".connect
东莞宇佳电子实业有限公司
PH-5050-BL
Bluetooth Two-way Headphone
OD40MM 4Ω3W multi-media speaker
1.5W*2
30mW*2 （series resistance; if not series resistance, it can reach up
to 100 mW*2）
≥45dB
≥40dB
≥5 H Under 50% of volume
≤1%
No limits
3.7V/600MAh, decrease to 85% of capacity after 300 time charging
and discharging
USB port DC—5V I≥500MA
≤2.5H
MP3/MP4/Apple IPAD, Iphone 3,3GS,4,5,6，PC
200HZ---15000HZ
OD3.5 stereo sound port
V4.0
≧10 meters
-43dB±3dB
