Page 1 INFINITY INVERTER POOL HEAT PUMP USER MANUAL...
Page 2: Table Of Contents
Table of contents Foreword B. Safety Precautions 1. Warning 2. Attention 3. Safety C. About your heat pump 1. Transportation 2. Accessories 3. Features 4. Operating range 5. Introduction of different modes 6. Technical parameter 7. Dimension D. Installation guidance 1.
Page 3: Foreword
A. Foreword Thank you for choosing the EZIHEAT high efficiency inverter pool heat pump. All EZIHEAT heat pumps are designed and built using the most advanced technology to the highest standards. Before attempting to install your pool heat pump please read and understand all the important information provided in this manual.
Page 4: Safety Precautions
B. Safety Precautions We have provided important safety messages in this manual for the installation, maintenance and repair on your heat pump. Please read, take note and obey all safety messages. Environment friendly R32 Refrigerant is used in this heat pump 1.
Page 5: Attention
Safety inspections must be carried out before maintenance or repair for heat pumps with R32 gas in order to minimise the risk. During installation of the heat pump if you notice any R32 gas leak stop the installation and call EZIHEAT on 1300 363 555 or your nearest service centre.
Page 6: About Your Heat Pump
C. About your heat pump 1. Transportation a. Always keep upright b. Do not lift heat pump via the water unions (Otherwise the titanium heat exchanger may be damaged) 2. Accessories Connection of the condensate drainage kit:...
Page 7: Features
3. Features DC Twin-rotary inverter compressor of Mitsubishi DC Brushless fan motor EEV Technology Reverse cycle defrosting with 4-way valve High-efficiency twisted titanium heat exchanger Sensitive and accurate temp control and water temp display High pressure and low-pressure protection Full protection on electrical system 4.
Page 8: Technical Parameter
6. Technical parameter ---------------------------------------------------------------------------------------------------------------------------------------------- Remarks: This heat pump is able to perform normal within air temp -10°C ～ +43°C, efficiency will not be guaranteed out of this range. Please take into consideration that the pool heat pump performance and parameters are different under various conditions. Related parameters are subject to adjustment periodically for technical improvement without further notice.
Page 9: Dimension
7. Dimension --------------------------------------------------------------------------------------------------------------------------------------- ※ Above data is subject to modification without notice. Note: The picture above is the specification diagram of the pool heat pump, for technician’s installation and layout reference only. The product is subject to adjustment periodically for improvement without further notice.
Page 10: Installation Guidance
D. Installation guidance 1. Installation reminder Only competent or professional persons are authorised to install the heat pump. All installations must be installed in line with the relevant building codes and standards of their current state or local governing body for all electrical, mechanical and water services to prevent danger or damage to the heat pump.
Page 11 b. Water pipe connection The inlet and outlet water unions must be plumbed in rigid pvc pipes. Flexible hoses must not be used DO NOT install water pipes in a way that they pass behind the heat pumps evaporator.
Page 12: Wiring
c. Typical installation diagram 1) The heat pump must be securely fixed with the use of the rubber feet (accessory), fixed by bolts (M10) to concrete foundation or fixed to walls by wall brackets. The concrete foundation must be solid and fastened; the bracket must be strong enough and antirust treated, 2) Do not stack substances that will block air flow near the inlet or outlet area, and there should be no obstruction within 50cm behind the heat pump, or the efficiency of the heat pump will be significantly reduced and could damage could occur.
Page 13: Electric Wiring Diagram
Fuse Earthing Breaker Note: Must be hard wired, plug is not allowed. 2) The swimming pool heat pump must be earthed well. 4. References for protecting devices and cable specification MODEL MSC90 MSC130 MSC170 MSC210 MSC280 MSC350s Rated Current 10.5 14.5...
Page 14: Operation Guidance
E. Operation Guidance 1. Controller Functions Symbol Heating & Cooling Function Power On/Off Wi-Fi setting Lock/Unlock Screen Heating mode (18-40°C) Cooling mode (12-30°C) Auto mode (12-40°C) Boost Silence Temperature Setting Attention: The controller has power-down memory function and will not display when locked. The buttons will turn dark when touchpad is locked.
Page 15: Operation Instructions
2. Operation Instruction a. Screen Lock 1) Press for 3 seconds to lock or unlock the screen 2) Automatic Lock Period: 30 seconds if no operation b. Power On Press for 3 seconds to unlock screen. Press to power on machine. c.
Page 16 f. Defrost Cycle When the heat pump is operating at low temperatures it is very common for ice to build up on the external coil. The heat pump has a built in defrost protection program which will activate when it senses ice starting to form.
Page 17 Parameters Settings | Checking ”and “ ” together for 5 seconds to enter “parameter checking” status, parameter code “P0” will blink on Press“ the left, parameter value “2” will display on the right. Press “ ” Key and “ ” Key to check the parameters. Press “...
Page 18: Testing
F. Testing 1. Inspect heat pump before use a. The air inlets and outlets are operating correctly and are free of debris and obstructions. b. It’s prohibited to install refrigeration pipe or components in corrosive environment. c. Inspect the electric wiring is correctly connected to the electrical schematic. d.
Page 19 G. Commissioning the heat pump Flow Rates The heat pump requires optimisation in order for it to achieve high efficiency and trouble free operation. For best performance the heat pump temperature difference between the inlet and outlet temperature should be between 2-3 degrees. Each heat pump has a minimum flow rate requirement, check the specification table to ensure the circulation pump in use is adequately sized.
Page 20: Maintenance
H. Maintenance “SWITCH OFF” power supply of the heat pump before cleaning, examination and repairing 1. In the winter season when the heat pump is not in operation for long periods of time, a. Switch off the power supply to prevent any machine damage. b.
Page 21: Trouble Shooting For Common Faults
H. Trouble shooting for common faults 1. Repairing Guidance ----------------------------------------------------------------------------------------------------------------------------------------- WARNING: If repair or removal is required, please contact an authorized service center. Requirements for Service Personnel Any person who is involved with working on or breaking into a refrigerant circuit should hold a current valid certificate from an industry-accredited assessment authority, which authorizes their competence to handle refrigerants safely in accordance with an industry recognized assessment specification.
Page 22 Protection & Failure code Error Which component? Error detected? Solutions High pressure protection High gas pressure switch 1. Check the water flow from the filtration pump and ventilation clearances. 2. Check high pressure switch is closed circuit 3. Replace PCB 4. replace inverter board Low pressure protection Low gas pressure switch...
Page 23 Current protection Power off and restart Inverter board Compressor Cooling plate overheat protection Power off and restart Check fan motor Check cooling plate Fan motor failure Fan motor Check the fan motor wiring, check if the fan is broken or loose. Power filter plate...
Page 24: Water Pump Control Connection
I. Water pump control connection Water pump: 230V voltage, ≤500W capacity Breaker/fuse Power Cable (Not Supplied) Earthing Power Supply 230V~/50Hz External auxiliary input Water Pump Breaker/fuse (Not Supplied) Power Supply 230V~/50Hz Earthing...
Page 25 Water pump: 230V voltage, ＞500W capacity Breaker/fuse Power Cable (Not Supplied) Earthing Power Supply 230V~/50Hz External auxiliary input Water Pump Breaker/fuse (Not Supplied) Contactor Power Supply 230V~/50Hz Earthing...
Page 26 Water pump: 400V voltage Breaker/fuse Power Supply (Not Supplied) Power Cable 230V~/50Hz Earthing External auxiliary input Water Pump Breaker/fuse (Not Supplied) Contactor Power Supply 400V~/50Hz Earthing...
Page 27 Water pump control and timer connection 1: Water pump timer 2: Water pump wiring of Heat Pump Note: The installer should connect 1 parallel with 2 (as above picture). To start the water pump, condition 1 or 2 is connected. To stop the water pump, both 1 and 2 should be disconnected.
Page 28: Wi-Fi Operation
J. Wi-Fi Operation Follow the instructions below to connect a smart phone to the heat pump via a Wi-Fi network. It is crucial that the Wi-Fi network signal strength is of high power at the heat pump location otherwise connection will not be achieved.
Page 34 EZIHEAT AUSTRALIA PTY LTD ABN 11 158 163 298 Phone: 1300 363 555 Web: eziheat.com.au Email: info@eziheat.com.au...
