Olive Union Olive Pro Instruction Manual

Olive Pro Instruction Manual
※ This product is not a hearing aid
※ For the most recent version of this manual, please check our website.
www.oliveunion.com/us/
Battery Olive: Lithium-ion battery 65mAh
Charging case: Lithium-ion battery 410mAh
Power input Olive: DC (DC) 5V, 130mA
Charging case: DC(DC)5V, 410mA
Usage time calculated based on a volume level of 〇%.
Usage time -
-
Charging time
Main unit 〇 hours / Charging case 〇 hours
※ Battery life may vary depending on environment and usage factors
such as distance between communicating Bluetooth devices.
Size and Olive: 20mm × 20mm × 31mm / 7g
weight
Charging case: 66mm × 23mm × 45mm / 28g
Main unit and - Olive unit for left ear x 1
accessories
Olive unit for right ear x 1
- Charging case x 1
- 1 USB Type-C cable
- Urethane Eartips: Small, Medium, Large (x2 for each size)
(Size M is attached to the left and right Olive at the time of purchase)
Compatible Compatible with iOS 11 or later, Android 4.4.3 or later.
models Usage at a distance of ● meters is not guaranteed to work.
Compatibility with older or newer versions is not guaranteed.
Compatibility with old Bluetooth standards is not guarantee.
Bluetooth radio waves may interfere with other radio waves.
Please make sure to set up indoors.
Step 1. Check The Olive And Accessories
Olive Charging Case ×1
(Left ear ×1、Right ear ×1)
LED light
Urethane Eartip (Size M)
Touchpad
L R
USB Type-C
(Left ear) (Right ear)
Cable outlet
USB Type-C cable ×1 Urethane eartips ×4
S/L size 2 each
※ Please make sure to use the included cable. ※
Size M is attached to the left and right sides
at the time of purchase.
※
S-size Red / M-size Green / L-size Blue
Step 2. Charging Your Olive
1
Put the Olives into the charger, close the lid, connect the cables, and charge for 1 hour.
USB Type-C cable
2
The amount of remaining charge in the Olive
Charging Case can be checked by opening the
case and looking at the LED light display below.
0~25%
26~50%
51~75%
76~100%
Step 3. Wearing Your Olive
For an authentic sounding Olive experience, make sure to choose the best fitting eartip
and install it correctly.
1 2
Remove the Olive from the case Pinch the urethane ear tip with
and grasp it from the sides. your fingers so it shrinks. It will
expand once fit into your ear,
※Be careful not to touch the touchpad
creating a tight fit and seal.
The [R] at the bottom of the earbud
indicates the right earpiece.
What if Olive doesn't fit my ears?
Finding the right fit for your Olive
is very important.
Make sure to try all 3 sizes (S, M,
and L) to find the best comfort
and fit.
Charging
The LED lights will flash quickly
Charging completed
The LED lights will flash slowly
USB AC Adaptor
(Purchase separately)
How do I charge my Olive on the go?
Your Olive can be charged at anytime by returning
them to the portable Charging Case.
The Charging Case can hold ~2 full charges,
and both earbuds can be fully recharged
in around 1 hour.
3
Correct
mounting
Insert the Olive Pro into your
ear canal, gently twisting and
rotating them to ensure a deep
and secure fit.
Please attach the earpiece
firmly to the back of the Olive.
Step 4. Powering On Your Olive
1
With the Olive in the charging case, open the lid of the charging case and the olive automatically
powers on. Place the olives in the charging case and close the lid to turn the Olives off.
2
After charging your Olive, please try the touchpad.
Left Right
Turn on Hear mode
Press and hold the right ear for a long time.
Left Right
Lower volume
Tap the right ear twice.
Step 5. Install the Dedicated Olive Application
While your new Olive may perform well on it's own, use it with the "my Olive" App to experience the full
potential of your Olive. Follow the instructions below to download the "my Olive" App.
1 2
Please open your smartphone's Aim the camera at the QR code
camera app. above. Once read, the "mt Olive"
App download screen should
appear.
If I'm having trouble reading the QR Code?
Please search for "my Olive" in the AppStore or
GooglePlay and download the apps shown to the right.
my Olive
Try Olive's exclusive app right now.
Left Right
Turn off Hear mode
Press and hold the left ear for a long time.
Left Right
Raise volume
Tap the left ear twice.
3
Please tap the pop-up or link
that appears to transition to the
"my Olive" App installation
screen.
iPhone / iPad Android
