Smart LED Bulb User Guide
Dimmable White
Model: WL100010106
FCC ID: 2ASHKWL100010106
If you have any questions of the installation or usage, contact us in the following ways:
Phone: 1-855-955-7007 (24x7)
Website: www.consciot.com
Email: support@consciot.com
Tunable White
Model: WL100010004
FCC ID: 2ASHKWL100010004
Ver 1.1
Advertisement
Table of Contents
Related Manuals for Consciot WL100010106
Summary of Contents for Consciot WL100010106
- Page 1 Smart LED Bulb User Guide Dimmable White Tunable White Model: WL100010106 Model: WL100010004 FCC ID: 2ASHKWL100010106 FCC ID: 2ASHKWL100010004 If you have any questions of the installation or usage, contact us in the following ways: Phone: 1-855-955-7007 (24x7) Website: www.consciot.com Email: support@consciot.com...
-
Page 2: Table Of Contents
Content Cautions …………………………………………………………………… 1 Products Overview …………………………………………………… 2 Consciot APP …………………………………………………………… 3 Add Smart Bulb(no hub required) …………………………… 4 Control the Smart Bulb …………………………………………… 6 Remove the Smart Bulb …………………………………………… 7 Scenes ……………………………………………………………………… 8 Timer ………………………………………………………………………… 9 Home ………………………………………………………………………… 11 Room …………………………………………………………………………... -
Page 3: Cautions
Cautions To avoid personal injury and/or possible product damage, the following cautions must be followed: 1. Risk of electrical shock. Disconnect power at fuse or circuit breaker before installing or servicing. 2. To prevent early lamp failure, lamp should only be installed in operating environments ranging between -20°C and +40°C (-4°F and +104°F). -
Page 4: Products Overview
Products Overview Model WL100010106 WL100010004 Type Dimmable White Tunable White Hub Required Wattage Lumens 800lm 800lm Warm White Warm White to Daylight Light Appearance 2700K 2700-6500K Light Dimming 1%-100% 1%-100% Timing √ √ Scenes √ √ Work with Alexa √... -
Page 5: Consciot App
Get the "Consciot" app from App Store or Google Play. At Welcome page, tap "Create account", then "Agree" the Consciot app is applicable for iOS 8 or higher, Android 4.1 or Terms of Service and Privacy Policy. Input your Email address higher. -
Page 6: Add Smart Bulb(No Hub Required)
S e l e c t W i - F i: t a p " Ta ke m e to m y s et t i n g s", s e l e c t "SmartLight-***" in the WLAN settings page. After your phone is connected to "SmartLight-***", return to Consciot APP. Check if the bulb blinks twice when it is on power. If yes, tap "Next";... - Page 7 Power off the smart bulb, then power on. If it blinks twice, it was not added to any account of Consciot; If no blinks, it means the bulb was added to a Consciot account already. You cannot add it to your account unless you reset the smart bulb.
-
Page 8: Control The Smart Bulb
Control the Smart Bulb On/off Settings of the smart bulb You can turn on/off the smart bulb at Home page. at the top right corner of bulb page for setting change. You can set the name, change the icon of the bulb, change Dimming the group it is listed in and so on. -
Page 9: Remove The Smart Bulb
Remove the Smart Bulb The smart bulb, if removed, will restore its factory defaults and no longer be listed on your account. Two ways to remove the bulb: Method 1 Long press the bulb you want to remove at Home page, tap at the top left, tap "Yes"... -
Page 10: Scenes
Scenes Scenes function enables you save many customized smart Set all Devices you need, then tap "Save" to complete the home scenes you like. You can quickly switch to the scene Scene settings. At Scene page, taping the corresponding you prefer if needed. Scene allows you to switch quickly to relevant Scenes. -
Page 11: Timer
Timer Set the timer timer. Tap on the left to set the status of Devices when At Automation page, tap at the top right corner, select triggered. If you want to remove a Device, swipe it to the left, and tap "Remove". "Time of Day"... - Page 12 Timer View/Edit Automation Remove Automation At Automation page, tap the Automation option into details Swipe the Automation card to the left at Automation page. page. You can view or edit this Automation then. After editing, You can remove that card by tapping "Remove". please remember to tap "Save"...
-
Page 13: Home
Home Create Another Home Home Setting Tap the "Home" you created(default name: My Home) at In "Home Management", tap the "Home" you want to edit to Home page, turn to "Home Management". Tap "Create" at do the settings. At here, you can change the Home name, the top right corner to create a new "Home". - Page 14 Invitation". Click "Accept invitation" to confirm the acceptance. Then the invitee is able to log in his Consciot account to Tap "Home share" in Settings page of the room you want to control the shared Home.
-
Page 15: Room
Room "Room" helps you organize the devices within "Home". If you Edit Room have too many devices to remember where they are, use In "Room Management" page, choose a "Room", edit or "Room" to manage them. remove the "Room" in "Room Settings". Remember to tap "Save"... - Page 16 Room Room Switch All Control In Home page, slide horizontally to view "ALL", "EVERYTHING All control is a function allows you to control all devices, ..." and Room created in the list, switch to one with a single especially smart light, included in the same Room together. tap.
-
Page 17: Work With Alexa
Go to Alexa app, tap the icon at the top left, select "SKILLS Choose the displayed "Consciot", then tap "ENABLE TO USE". & GAMES" and tap the search icon at the top right. Enter In the new page, fill in your Consciot account and password, "consciot" and search. then tap "Log in". - Page 18 Work with Alexa Step 3 Tap "Discover Devices" in the new page, Alexa will begin discovering your Consciot devices. Once the devices are found, you’re able to voice control them with Alexa. Another way to "Discover Devices": Tap the "+" at the top right corner of "Devices" on Alexa APP, choose "Add Devices", scroll to the...
-
Page 19: Fcc Compliance Information Statement
Responsible party: Company name: LEEDARSON AMERICA INC Street Address: 300 Technology Ct., Suite 100, Smyrna GA, United States Website: www.consciot.com E-mail: louisa@leedarson.co FCC Compliance Statement (for products subject to Part 15) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
