USER MANUAL

4K UHD Digital Signage Media Player

AS4L01X

Ver.1.1

Table of Contents

Need help?

Do you have a question about the AS4L01X and is the answer not in the manual?

Questions and answers

Summary of Contents for ADTECHNO AS4L01X

Page 1 USER MANUAL 4K UHD Digital Signage Media Player AS4L01X Ver.1.1...
Page 2: Safety Precautions & Instructions
 NOTE: ADTECHNO Inc. shall not be responsible for any harm or injuries caused by improper use of our product. If in doubt of use of product, please contact our customer service at info@ad-techno.com. Pictures shown in this manual are for reference only. Appearance and specifications are subject to change in the real product.
Page 3: Table Of Contents
■ SAFETY PRECAUTIONS & INSTRUCTIONS ........................2 CONTENS ......................................3 ■ INTRODUCING THE AS4L01X ..............................5 ■ PACKAGE CONTENT ................................. 5 ■ AS4L01X / REMOTE CONTROLLER ............................ 6 [AS4L01X] ................................................6 [REMOTE CONTROLLER] ..........................................6 ■ VESA BRACKET ATTACHMENT ............................7 ■...
Page 4 [APPEARANCE] ..............................................34 [CONNECTION AND SETUP] ........................................35 Connection and Diagram .......................................... 35 Connection Guide ............................................35 ■ TECHNICAL SPECIFICATION ............................... 37 AS4L01X – Media Player ......................................... 37 BX08R – Button Box (Optional Add-on) ..................................37 ■ WARRANTY AND SERVICES ..............................38...
Page 5: Introducing The As4L01X
USB flash drive that automatically replaces the existing files on the SD card with the media files on the USB flash drive – an extremely easy method to update media contents. The AS4L01X provides lots more other functions, such as FTP Auto Download Function and its log function, Auto Timer Function, Multi-Zone Display Function with mixture of video, picture, and text scrolling playback and RS-232 remote control.
Page 6: As4L01X / Remote Controller
■ AS4L01X / REMOTE CONTROLLER [AS4L01X] [REMOTE CONTROLLER] Power On/ Off ： Display： Open “Output Setting” OSD display Menu： Open/ Exit OSD display Info： Open “Content Info” OSD display Mute： Mute sound ▲： Move the cursor up Move the cursor left ：...
Page 7: Vesa Bracket Attachment
■ VESA BRACKET ATTACHMENT Attach enclosed VESA 75/100 bracket for easy attachment on TV Use enclosed screws to attach VESA bracket at the back of AS4L01X. ■ CONNECTION DIAGRAM Premium HDMI cable is recommended for 4K content display. ■ SUPPORTED FILE FORMAT...
Page 8: Setting Up The Sd Card
Create /media folder on SD Card, and save all the playing content. Settings.txt file Copy “Settings.txt” on SD Card. Insert the SD to the AS4L01X, the AS4L01X will apply the new settings automatically. – copy “Settings.txt” on SD Card only when you want to change the setting values. Refer to “Import Settings file”...
Page 9: Playing Content Information
■ PLAYING CONTENT INFORMATION Press “Menu” on Remote Controller. Move the cursor to “Content Info” by pressing “▲” and/or “▼”, and then press “Enter”. Press “Menu” or move the cursor with “▲” and/or “▼” to close the Content Info OSD display. ■...
Page 10: Settings
■ SETTINGS [OUTPUT SETTING] Press “Menu” on Remote Controller. Move the cursor to “[Control]” by pressing “▲” and/or “▼”, and then press “Enter”. Move the cursor to “Output Setting” by pressing “▲” and/or “▼”, and then press “Enter”. Move the cursor to “Resolution” by pressing “▲” and/or “▼”, and then press “Enter”.
Page 11: [Timer Setting]
NOTE: If the mixture of none supported resolution and color space under HDMI 2.0 Specification is selected, AS4L01X will output TMDS bandwidth that both AS4L01X and connected TV support. Make sure to save the new setting value by pressing “[Save Settings]”.
Page 12 Move the cursor to “Year” by pressing “▲” and/or “▼”, and then press “Enter” Move the cursor to the present year by pressing “▲” and/or “▼”, and then press “Enter”. Follow the same way for setting up “Month”, “Day”, “Week”, “Hour”, ”Minute”...
Page 13 “▲” and /or “▼”, and then press “Enter”. Enter 2-digit hour (HH)/ minute (MM) and press “OK”. Change the Power Off Settings following the same procedure. Make sure to save the new setting value by pressing “[Save Settings]”. 10. AS4L01X will automatically reboot the system.
Page 14: Read Time From Ntp Server
Read Time from NTP Server The AS4L01X has a built-in Real Time Clock (RTC). The current time value can be synchronized with either by RTC or Network Protocol Timer (NTP) Server. Make sure that your AS4L01X is connected to WAN if you want to synchronize the current time with NTP server.
Page 15: [Network Setting]
Auckland, Wellington (GMT+02:00) Cairo (GMT+12:00) Fuji, Kamchatka Pen., Marshall Is. (GMT+02:00) Harare, Pretoria (GMT+13:00) Nuku’alofa [NETWORK SETTING] Connect LAN cable to RJ-45 connector of AS4L01X, and setup the network settings. NOTE: Ask your system administrator for your network system information.
Page 16 Press “Menu” and open the Main Menu. Move the cursor to “[Control]” by pressing “▲” and/or “▼”, and then press “Enter”. Move the cursor to “Network Setting” by pressing “▲” and/or “▼”, and then press “Enter”. Move the cursor to each black box, and change the value. NOTE: Change to “ON”...
Page 17: [Ftp Auto Download]
AS4L01X will automatically reboot the system. [FTP AUTO DOWNLOAD] FTP Auto Download Function enables AS4L01X to download new playing contents through the Internet. This also features download log function. The downloading method can be selected by interval mode or access mode.
Page 18 IP and port number. Refer to “Download List” P.19 for more details of “List Path”. AS4L01X access timing of FTP server can be selected either from “Interval mode” or “Access Mode”. FTP Auto Download Function can be disabled by selecting “OFF” for both Interval Mode and Access Model slide switch.
Page 19: Download List
AS4L01X. Cut and paste the [downloadlist.txt] to your PC. Download List [downloadlist.txt] file describes “Where (from which FTP server folder) the content to download from” and “Which content to download”. Use a text editor on PC to edit the information. AS4L01X follows the Download List downloading new content.
Page 20: Download Log Function
AS4L01X settings can be changed through FTP Auto Download Function. Save [Settings.txt] file on FTP server folder where you setup on List Path. AS4L01X will reboot the system once the downloading is finished, and change the settings value according to the downloaded [Settings.txt] automatically. Refer to “Import Setting File” P.27 for the details of...
Page 21: [Synchronized Playback]
Files Stored on SD for a device A (Master) Files stored on SD for a device B (Slave) Setup one AS4L01X device as “Master” and other devices as “Slave”. Master will send sync signal once a new device is found in the same subnet mask.
Page 22 Make sure to save the new setting value by pressing “[Save Settings]”. AS4L01X will automatically reboot the system. ！Timing of Sync Signal Output Master device sends a sync signal to slave devices whenever a new slave device is found in the same subnet. Slave devices reply the content from the beginning upon receiving the sync signal.
Page 23: [Picture Setting]
[PICTURE SETTING] Picture setting allows you to enable or disable a picture slideshow display function. The playing order of picture slideshow is by the file names in ascending order alphanumerically. The AS4L01X also supports mixture playback of picture and video files.
Page 24: [Display Setting]
Enter 3-digit numbers of picture display interval time, and press “OK”. Make sure to save the new setting value by pressing “[Save Settings]”. AS4L01X will automatically reboot the system. [DISPLAY SETTING] OSD Display Rotation NOTE: OSD Display Rotation is not available if Multi-Zone Setting is ON.
Page 25: Multi-Zone Display And Text Scrolling
11. Move the cursor to items that suites your TV installation, and then press “Enter”. Multi-Zone Display and Text Scrolling AS4L01X supports the following variations of display; ① Video ② Picture ① Video ② Picture ① Video ② Picture ③ Picture...
Page 26 ① Video ② Picture ③ Text Scroll ① Video ② Picture ③ Text Scroll ① Video ② Picture ③ Picture Text Scroll ④ Press “Menu”. Move the cursor to [Control] by pressing “▲” and/or “▼”, and then press “Enter”. Move the cursor to Display Setting by pressing “▲” and/or “▼”, and then press “Enter”.
Page 27 “▼”, and then press “Enter” to change the slide switch to NOTE: Refer to “Content for Text Scrolling” P.27 NOTE: Text Scrolling Function is available only when Multi-Zone Display function is enabled. Make sure to save the new setting value by pressing “[Save Settings]”. AS4L01X will automatically reboot the system.
Page 28: Picture Content For Multi-Zone Display
Picture Content for Multi-Zone Display Follow the following naming rules for picture content. Resolution Video Display Picture Display File Name Location Video Picture 10 Secs 30 Secs Any name 60 Secs 3260x2160 Sync with Video: 010.mp4 Left 691x2016 or lower Video Picture: 010.jpg Fixed...
Page 29: Content For Text Scrolling
Add the content of Text Scrolling after “Text_Scrolling = “ The number of the text for the scrolling supports up to 512 bytes, unicode. [IMPORT SETTINGS FILE] AS4L01X also support changing settings value by importing Settings File [Settings.txt] from SD Card. Obtain Setting File [Settings.txt] Press “Menu”.
Page 30: Edit Settings File [Settings.txt]
Move the cursor to [Export Settings File] by pressing “▲” and/or “▼”, and then press “Enter”. Press “Enter”. Edit Settings File [Settings.txt] User a text editor to edit the Settings.txt.
Page 31: Import Settings.txt
Import Settings.txt Save edited Settings.txt on SD Card root, inset the SD to AS4L01X and turn on the device. AS4L01X will automatically import Settings.txt and change the setting value. Imported Settings.txt will automatically be deleted from SD. Also refer to “Remote settings change by FTP Auto Download”...
Page 32: [Repeat Default]
NOTE: Unauthorized copy protection file [userdat.dat] is necessary for USB auto copy function. Obtain the file from your supplier. Copy content from USB to SD Step1. Insert USB pen drive to USB port of AS4L01X *It takes about 5 seconds to initiate the copy Step2. Copying process shows as below;...
Page 33: Change Settings Value With Setting File [Settings.txt]
Step3. USB auto copy is completed. Unplug USB pen drive. Copied new content will be played automatically. Change Settings value with Setting File [Settings.txt] The AS4L01X settings value can be changed through the USB auto copy function. Save [Settings.txt] file with new setting value on USB pen drive for the auto copy.
Page 34: Introducitng The Bx08R (Optional Add-On)
■ INTRODUCITNG THE BX08R (OPTIONAL ADD-ON) The BX08R is an optional play button control device designed to be used in conjunction with the AS4L01X. The BX08R is equipped with RJ-11 ports which users can connect up to 8 LED play buttons for interactive applications. The BX08R also has RS-232C signal connectors (D-Sub9) and a DIP switch for daisy chaining of up to 3 units of BX08R, providing up to 24 play buttons to control video or image playback contents.
Page 35: [Connection And Setup]
Connection Guide Step1. Insert SD card into the AS4L01X, push the SD card all the way in until a soft click sound is heard and the SD card locks into place (ensure that the SD card is inserted in the correct direction) Step2.
Page 36 TERM. ID Dip Switch Corresponding 9-16 17-24 Button Step3. Connect the BX08Rs together with Terminal 1’s D-Sub9 In to Terminal 2’s D-Sub9 Out, and Terminal 2’s D-Sub9 In to Terminal 3’s D-Sub9 Out. Step4. Turn on the power of the AS4L01X...
Page 37: Technical Specification
■ TECHNICAL SPECIFICATION AS4L01X – Media Player Model No. AS4L01X Dual Core 1.5GHz OpenGL E3.1 Memory eMMC (8GB) / DDR 4 (2GB) Network RJ45 (1000Base-T) Supported Media Device SD(XC) Card x 1 Supported File Format Video： H.265/ H.264/ MPEG-2/ MPEG-4/ VP9/ (*.mov/*.mp4/*.mpg) Picture：...
Page 38: Warranty And Services
Any delivery costs of shipping the product are to be covered by the user during servicing within or after the warranty period. Terms of Warranty: ADTECHNO Inc. warrants that its products will be free from defects in materials and workmanship for one year, starting from the date of purchase (As per recorded in the invoice or receipt).
