Airbond Splicers

701 Series 2 Splicers

Splicers for heavy yarns and tows

GTW Developments Group Ltd., Unit 1, Pavilion Industrial Estate, Pontypool, NP4 6NF, UK

Tel. +44 1495 755661

Fax. +44 1495 752619

Web: www.airbondsplicer.com

Email: enquiries@airbondsplicer.com

No part of this publication may be copied or reproduced

by means electronic, mechanical, photocopy, recording or stored in a retrieval system or

transmitted in any form or by any otherwise without the prior permission of GTW Developments Ltd. The Pentwyn Splicers logo is a registered trade mark,

property of GTW Developments Ltd.

Table of Contents

Need help?

Do you have a question about the 701 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for airbond 701 Series

Page 1 Airbond Splicers 701 Series 2 Splicers Splicers for heavy yarns and tows GTW Developments Group Ltd., Unit 1, Pavilion Industrial Estate, Pontypool, NP4 6NF, UK Tel. +44 1495 755661 Fax. +44 1495 752619 Web: www.airbondsplicer.com Email: enquiries@airbondsplicer.com © GTW Developments Ltd., 2020...
Page 2: Table Of Contents
CONTENTS The new generation Airbond splicers - background Model 701 Series 2; summary Changes to the specifications Getting started Splicer threading Important service information General product information 701 Series: Model range • Model 701 H • Model 701 HF • Model 701 HW •...
Page 3: The New Generation Airbond Splicers - Background
We’ve done this by investing in cutting-edge new additive-manufacturing (3d printing) technology. From 2020 onward, all Airbond products will be printed, in materials which are more durable than those used in the past. The first generation of printed products will be familiar to our customers; they are direct replacements for the existing products - identical in shape and function.
Page 4: Model 701 Series 2; Summary
The range of application of the 701 Series 2 is just as remarkable as its predecessor. A unique and patented form of splicing chamber and splicing system is so powerful that a single specification can handle yarns of widely different counts.
Page 5: Changes To The Specifications
701 Series 2: Changes to the specifications In its original form, the Model 701 Splicer had an injection-moulded ABS body shell. Some fittings were made of metal, and were held in place by elements of the body shell, and screws. An example of this construction was the hanger wedge, which fitted into a recess in the body, and was secured by two screws.
Page 6 Model 701 Series 2: C hanges to the specifications in the Series 2 Here are two examples of how the splicer specification has been improved This example shows the body of the 701 HW Series 2 splicer. In the Series 1 splicer, the hanging...
Page 7: Getting Started
Getting started...
Page 8 Model 701 – getting started Please read this section before you start operating the splicer. The rest of the manual deals with maintenance, and with details of products; those sections will not be needed immediately. Remove all packaging. For each splicer, you will have the appropriate splicing chamber – which will usually already be fitted.
Page 9: Splicer Threading
The Model 701 has been designed to splice low to heavy-count yarns in materials such as glass and carbon. Airbond research has shown that standard splicers – which typically make joints of around 30 mm in length – produce splices which are weak. Heavy-count yarns demand longer splices, typically up to 150 mm for 4800 tex.
Page 10 Now make the third. After the third splice, cut off the waste ends of yarn using a scissors. This technique has proved very successful with a number of materials; the picture below shows splices in glass, carbon and aramid. It is clear that the result for carbon is excellent –...
Page 11: Important Service Information
Important service information Apart from accidental damage, the Model 701 requires little attention. However, cleaning and specific lubrication should NEVER be neglected. Obviously, there should be frequent examination for signs of fibre build-up in the inner parts of the splicer. Fibre should be removed. Most important, the valve which actuates the chamber need lubrication.
Page 12: General Product Information
Model 701 – General product information...
Page 13 The 701 splices 4800 tex as routine, and in most circumstances it can handle 9600 tex. Now the Model 701 series 2 splicer is the direct counterpart to the Model 701 – similar in appearance but 3D printed in tough PA12 polyamide. Being 3d-printed, the Model 701 cases are made in one piece –...
Page 14 General description The Model 701 Splicer has a number of components mounted inside a case structure in which airways conduct the compressed air for the splicing action. Trigger - pressing the trigger initiates the splicing operation. Valve - operation of the trigger moves the valve allowing compressed air to pass into the body head for splicing.
Page 15 Splicer Model 701 HFW, fitted with wedge hanger and flow control (flow control is visible on the other side). Note the QR code; scanning this code will enable the user to access the Airbond web site - and an on-line version of this technical manual for the splicer.
Page 16 701 H...
Page 17 The outer surface of the lower shell of the 701 H Series 2 splicer. Note: The rectangular insert at the top of the shell; in the real splicer this houses the identification label, complete with QR code. The inner surface of the lower shell of the 701 H Series 2 splicer.
Page 18 The outer surface of the upper shell of the 701 H Series 2 splicer. Note: The five holes for the securing screws. The inner surface of the upper shell of the 701 H Series 2 splicer.
Page 19 701 HF...
Page 20 The outer surface of the lower shell of the 701 HF Series 2 splicer. Note: The rectangular insert at the top of the shell; in the real splicer this houses the identification label, complete with QR code. The inner surface of the lower shell of the 701 HF Series 2 splicer.
Page 21 The outer surface of the upper shell of the 701 HF Series 2 splicer. Note: The markings 0, 1,2,3, for the flow controller are visible at the base of the handle The inner surface of the lower shell of the 701 HF Series 2 splicer.
Page 22 701 HW...
Page 23 The outer surface of the lower shell of the 701 HW Series 2 splicer. Note: The rectangular insert at the top of the shell; in the real splicer this houses the identification label, complete with QR code. The outer surface of the lower shell of the 701 HF Series 2 splicer.
Page 24 The outer surface of the upper shell of the 701 HW Series 2 splicer. Note: The hanging wedge, printed as an integral part of this lower shell, is clearly visible at upper right. The inner surface of the upper shell of the 701 HW Series 2 splicer.
Page 25 701 HFW...
Page 26 The outer surface of the lower shell of the 701 HFW Series 2 splicer. The inner surface of the lower shell of the 701 HFW Series 2 splicer. Note: The air connector at the base of the handle now incorporates a part of the flow control system (the small hole in the air connector structure is clearly visible).
Page 27 The outer surface of the upper shell of the 701 HFW Series 2 splicer. Notes: The hanging wedge, printed as an integral part of this lower shell, is clearly visible at upper right. The flow control scale (0, 1,2,3) is visible at the base of the handle.
Page 28: Model 701 Hw
Model 701 – Maintenance...
Page 29 The body shells of the 701 Series 2 are held together by self-tapping screws, 4 x Items 1191 and 1 x Item 1194. Note that the screw (Item 1194) at the base of the handle is shorter than the others. Remove all of the screws to detach the upper case from the lower.
Page 30 The lower body shell of the 701 Series 2. Components: Lanyard – lower left Item 1611. Push-fit brass connector – input side, Item 1618. Blue plastic air supply tube, Item 1617. Pale blue trigger, Item 1614, and steel trigger return spring, Item 1609.
Page 31 Then release the feed tube from the upper compression fitting. This will permit the removal of the air union and feed tube. Lift away the trigger assembly, together with the chamber pad. Keep the assembly as one unit, unless you need to remove the chamber for maintenance or replacement.
Page 32 If required, press out the pad retaining pin, Item 1605, and separate the trigger Item 1614 and closure pad Item 1610 The closure pad mounting pin is an interference fit in the splicer trigger lever. This arrangement retains the closure pad, while allowing the pad to be a loose fit, so that it can align itself to the face of the splicing chamber..
Page 33 Lift the splicing unit out of the case, and detach the air feed tube, by compressing the quick-fit connector, and withdrawing the tube. Remove the splicing chamber. With a small tool, press the chamber securing pin, Item 1604, until it slides out. The chamber can then be removed from the Valve, Item 1606.
Page 34 To continue with complete strip-down: With the chamber removed, the compression washer can be seen; it is retained in place by two pins Item 1603. Using the same small tool as before, press out the pins, so that they come free from the main splicer body.
Page 35 Grip the end of the valve, and gently withdraw the inner assembly The inner assembly withdrawn from the splicer body. The inner assembly in process of being dismantled into its component parts. The inner assembly with all component parts separated.
Page 36 This photograph shows the splicer unit completely dismantled. Top: valve, Item 1606 with oring, Item 1651 From left: Retaining disc, Item 1601. Brass spacer, Item 1602 O-ring, Item 218 Shell, Item 1607, O-ring, Item 218 Brass spacer, Item 1602 Return spring, Item 787 Bottom: valve body, Item 1600 with Connector, Item 1618 To reassemble:...
Page 37 Splicing unit: detail The splicing unit itself sits inside the outer moulding, so that it is not easily damaged in service. The entire splicing action is contained within the block shown in the photograph. The closure pad is at the top left. The splicing chamber is secured to a valve which runs inside the main splicer block.
Page 38 Components of the splicer unit. From left to right: • Splicing chamber (part number to be specified by customer) • Chamber retaining pin 1604 • Valve 1606 (O-ring 1651 placed on the valve) • NOTE: NO LUBRICATION ON VALVE OR O-RING •...
Page 39: Compressed Air - Noise
Compressed air Pneumatic splicers are operated by compressed air. Therefore the air supply must be appropriate. The following points are important: Splicers generally operate at a pressure between 3 and 8 bar. Pressure may vary according to application, but it must be as uniform as possible. The air supply should be reasonably dry and clean, with the lowest possible flow resistance.
Page 40 Compressed air and safety All our splicers have been designed with safety in mind. The few moving parts have been enclosed or shielded to reduce the possibility of injury to the operator. In normal use, the only component which is in any way a source of hazard is the knife assembly.
Page 41 Compressed air and noise A splicer uses compressed air, which for a brief period - about 1 to 2 seconds – is vented to atmosphere while the splice is being made. Air at perhaps 7 bar pressure escapes through a small blast hole, creating intense turbulence in a small volume. Noise is inevitable.
Page 42: Troubleshooting
Troubleshooting Trouble with splicers generally takes one of two forms: poor splicing or component malfunctioning. 1) Splicing performance. If there is no apparent damage to the splicer, there may still be something subtle, which cannot easily be seen. It will be best, however, to look at the possible causes which are easy to spot. These include: Simple checks: •...
Page 43 Sticking valve Occasionally, the main valve in the splicing unit may stick. This could be the result of some form of damage to the internal components, but the explanation is normally much simpler; a lack of lubrication around the O-rings which seal the pad assembly, or an extension spring which has come adrift.
Page 44 Model 701 Series 2 Splicer - Parts list Description Item No. Part No. Quantity 'O' Ring BS 110 01-11-10 Air valve return spring 10-136-018 M4 x 12 torx cap head self tapping screw 1191 19-44-12 M4 x 8 torx cap head self tapping screw...
Page 45 Description Item No. Part No. Quantity Hanging Assembly parts Splicer holding clip 201-1199 SPECIFY Outer Case Left 701HW including bottom connector 1644 10-156-709 Outer Case Right 701HW 1648 10-156-713 Flow Control parts O-ring BS006 01-10-06 Flow restrictor valve 1623 10-113-128 Outer Case Left 701HF including bottom connector 1645 10-156-710...
Page 46 Model 701 Series 2 Exploded diagram assembly...
Page 47 Model 701 Valve body exploded diagram assembly...

This manual is also suitable for:

701 1 series 701 2 series 701 h 701 hf 701 hw 701 hfw
