RECHARGEABLE 29V BATTERY PACK

OPERATING INSTRUCTIONS

1. Be sure the battery is fully charged before use. To confirm this, press the Test button on the side of the
unit. If the indicator light is green then the battery is ready to use. If the indicator light is red, plug it into
an outlet to charge.
2. To install, connect the cord with the female connector to the male 2-pin plug hard wired to the recline
motor. Be sure to position the battery pack in a location where the cord will not be damaged in the recline
mechanism.
3. Press the test button on the side of the battery pack to check the status of the battery while in use. If the
battery has enough power to properly operate the furniture the test button will activate a GREEN LED.
When the battery drops to 20% capacity, the test button will activate a RED LED. When this occurs, plug
the battery pack into a standard wall outlet to recharge.
4. During the charging process a LED light will constantly indicate the current status of the battery pack.
A RED LED indicates the charging process is not complete. A GREEN LED indicates the battery is fully
charged.
*You have the option of using the battery while it is charging but this will require a much longer charging time before the
battery is fully charged.
**Do not completely drain the battery as this may reduce the life of the battery.
***Once the battery is fully charged, unplug it from the wall outlet. Leaving the battery plugged into a wall outlet while
fully charged will cause the battery to drain more quickly during use.
Notes:
1. Do not dispose of electrical appliance as unsorted municipal waste, use proper collection facilities.
2. Contact your local government for information regarding the collection system available.
3. Use only a power supply cord, Type SPT-1, 22awg, two conductors, rated minimum 105°C, 300V, VW-1. One
end terminates in an attachment AC plug of 15A, 125V (NEMA 1-15P) or 15A, 250V (NEMA 2-15P), the other
end terminates in a molded on connector which mates with the Power appliance
length.
USER MANUAL
SPS 2A29VDC BBFM
inl
et. Minimum 2.3m in
