Interior Solutions DC420V Operating Instructions

FAUTEUIL DE DESSINATEUR EN CHROME ET EN VINYLE
7
8
5
8
3
1
Retirer toutes les pièces du carton, les séparer selon les numéros de pièces indiqués sur la liste de
pièces et vérifier les quantités de pièces.
ÉTAPE 1 Insérer cinq roulettes (2) dans la base (1), pousser fort jusqu'à sentir ou écouter la roulette (2) cliquer à sa place. Insérer
le cylindre pneumatique avec le couvercle (3) dans la base (1).
ÉTAPE 2 Attacher le coussin du dossier (7) au coussin du siège (6) en utilisant quatre vis (8).
SERRER LES VIS COMPLÈTEMENT.
ÉTAPE 3 Placer la plaque du siège (5) sous le coussin du siège (6) avec la flèche qui se dirige vers l'avant du fauteuil. Aligner
les quatre trous sur le repose-pied (4) aux quatre trous sur la partie avant de la plaque du siège (5). Attacher le repose-pied (4)
et la plaque du siège (5) au coussin du siège (6) en utilisant quatre vis (8). Attacher la partie arrière de la plaque du siège (5) au
coussin du siège (6) en utilisant deux vis (8). SERRER LES VIS COMPLÈTEMENT.
ÉTAPE 4 Placer le siège assemblé sur le cylindre pneumatique (3) et mettre de la pression vers le bas.
ATTENTION : S'ASSURER QUE TOUTES LES VIS SONT COMPLÈTEMENT SERRÉES AVANT D'UTILISER LE FAUTEUIL.
DC420V
INSTRUCTIONS DE MONTAGE
6
8
8
4
PIÈCE
1. Base . . . . . . . . . . . . . . . . . . . . . . . 1
2. Roulette . . . . . . . . . . . . . . . . . . . . . 5
3. Cylindre pneumatique avec
couvercle . . . . . . . . . . . . . . . . . . . . . . 1
4. Repose-pied . . . . . . . . . . . . . . . . . 1
5. Plaque de siège . . . . . . . . . . . . . . . 1
6. Coussin de siège . . . . . . . . . . . . . . 1
7. Coussin du dossier . . . . . . . . . . . . 1
8. Vis Courtes . . . . . . . . . . . . . . . . . 10
9. Clé Allen (non montrée) . . . . . . . . . 1
2
© Office Star Products Juillet 2012
1
QTÉ
LIMITED WARRANTY
Office Star chairs are warranted from the date of purchase against failure due to material and workmanship as follows:
• 5 Years on all non-moving metal parts.
• 2 Years on component parts including Control mechanisms, pneumatic cylinders, wood, plastic parts, base and casters.
• 1 Year on upholstery fabric and foam against wear and deterioration.
To make a warranty claim, contact Parts Department. Provide model number, proof of purchase, description of the problem and
obtain return authorization. At it's option Office Star Products will:
(a) Supply compatible components of current manufacture.
(b) Repair the customer's component. The customer must prepay freight on any components returned to the factory. Return
freight on components still in warranty will be paid by Office Star Products.
*All warranties are limited to the original purchaser for normal Residential usage by persons weighing 200 lbs. or less. This warranty will not cover labor,
freight or damage from misuse, abuse, negligence, alteration, accident, vandalism, rusting, acts of nature or any other event beyond the control of Office Star
Products. The warranty does not cover cosmetic damage that may result from normal use. Liability for incidental or consequential damages is excluded. The
user assumes all risk of injury resulting from use of this product. This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Our quality standards are among the highest in the industry. Sometimes, no matter how hard we try, there are times when parts
are damaged or missing. Our Parts Department will do everything possible to promptly remedy the problem. Contact us via e-mail
parts@officestar.net, by Fax 1-909-930-5629, or toll free parts number 1-800-950-7262, Monday through Friday 8:00 a.m. - 5:00
p.m. Pacific Time.
DC420V
CHROME & VINYL DRAFTING CHAIR
OPERATING INSTRUCTIONS
FEATURES
To raise seat remove pressure from seat and lift
lever (1). To lower seat height sit on chair and
lift lever (1).
NOTE: It is normal for chair to slightly lower under
body weight.
WARNING
1. Use this product only one person at a time.
2. Do not use this chair unless all bolts screws and knobs
are securely tightened.
3. Check that all bolts screws and knobs are tight every
three months or as needed.
4. Dispose of packing material properly. Do not use
plastic cover as head covering. It may cause
suffocation.
5. Do not use chair as a stepladder.
6. Use this chair for its intended purpose only.
7. Use mild detergent only for cleaning.
