Amusement machines of Guang Yang

MANUAL Of"

Thanks for choosing Guang Yang Amusement' s products---------Let's express

our greatest gratitude here!

Please read this manual carefully before using and mending this machine,so

that you can use it correctly.

Meteor Shower

Guang Yang Amusement Technology Co.,Ltd.

Tel.:

0760- 8706688

Http://www.gooyooo.com

Fax:

0760- 61196

Need help?

Do you have a question about the Meteor Shower and is the answer not in the manual?

Questions and answers

Summary of Contents for Amusement Machines of Guang Yang Meteor Shower

Page 1 Amusement machines of Guang Yang ” MANUAL Of“ Meteor Shower Thanks for choosing Guang Yang Amusement' s products---------Let's express our greatest gratitude here! Please read this manual carefully before using and mending this machine,so that you can use it correctly.
Page 2 ： Company Profile Guang Yang Amusement Technology Co.,Ltd.was found in 2004,and became a listed company in 2015 which is the first one in amusement industrial in China (Ticker Symbol: 832956).Moreover,we got the license from government named “ National High-tech Enterprise”. We are specialized in development,design,production and sales of Redemption machines, Video Games and Kiddie Rides which is one of the main suppliers for indoor amusement equipment.We've combined with the local famous chain amusement centers to create the...
Page 3 Contents 1. Parameters …… …………………………………………………………… ……… 2. Spare Parts for the machines……………………………………………………… 3. The plane size figure…… ………………………………………………………… 2 a. Side view… ……………………………………………………………………… 2 b. Front view……………………………………………………………………… c. Top view………………………………………………………………………… 2 4. Move, steady and maintenance…………………………………………………… a. The fixed an mobile…………………………………………………………… b.
Page 4 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower 1.Parameters ： W845 mm × D1020mm × H2100mm Size： Weight：105Kg Volt：AC220V 50Hz/60Hz Power：80W Player：1 person ☆Remark：if there is any change, there will be without advanced notice 2. Spare Parts for the machines The spare parts listed below are with the factory delivery.
Page 5 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower 3. Dimension a. Profile 830mm 830mm...
Page 6 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower...
Page 7 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower...
Page 8 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower (11)Bonus display (8)Dribble belt (10)Bonus Display (6)Goal hole (7)Decorative ball (5)Palm Button (4)Ticket-out ( 2 ) Slit Hole (1)Lock (3)Horn...
Page 9 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower (8)Coin box (6)Fairway (7)Horn (4)Motherboard (5)Lottery box (3)Power (1)Interface of power (2)Exhaust fan...
Page 10 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower ①solution for coin stuck: When the coin selector gets stuck,please stir coin-stuck button according to the direction of picture,then the coin will fall back to the coin slot.If not, it needs to open coin selector and then take out the coin.。...
Page 11 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower Ticket Installation: High level Put ticket which is right side facing up into the ticket Normally open guide slot,then press and hold the micro button to send Reversal ticket into the ticket dispenser automatically.
Page 12 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower c. Reader ticket counter coin counter volume button( turn right for up) Please open the door for the coin selector, you will see the tickets & coins table and volume setting use and maintenance of instructions of machine 1.
Page 13 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower...
Page 14 ” Amusement machines of Guang Yang MANUAL Of“ Meteor Shower...
Page 15 O F F O F F O F F O F F O F F O F F has been set <Meteor Shower> Linked mainboard parameter setting form Situation program content O F F O F F O F F...
