AudioBus DF2402 Safety And Use Instructions

DF2402
INSTRUCTIONS FOR:
INSTALATION
1. Connect the terminal.
2.
Put the magnetic base on the detector's lower part.
3. Remove the adhesive protection and fix the device in the
correct position, without interfering in the driver's view.
4. Connect the terminal and stare to the sensor lens untill
the indicative frontal LED becomes green, indicating a
correct face reading.
5. Sensor has to be installed in vertical position, do not
completely fix the adhesive untill a correct face reading.
6. To check the system's correct working , frontal led has to
be unblinking or blinking when it detects the driver's eyes
opened. Correct distance for an optimal reading is
600-900mm, seeking for the LED to be glowing as much
time as it's possible.
7. The Green LED blinking is normal while the driver opens
the eyes, especially wearing glasses with mount.
8. If the green LED keeps glowing or blinkin when the driver
turns the head left or right, or moves up and down, means
the installation of the detector is even better.
9. Device installation must me inside a 20 degrees inclina-
tion range from the normal driver's view position, and if it's
istalled in front of him/her, it must be 15 degrees.
audiobus@audiobus.com
FATIGUE
DETECTOR
+34 976 59 69 00
We present you our:
DF2402
www.audiobus.com
