Floodline
Leak and Flood Detection Systems
128 Multi Zone Leak Detection
System - 32/64/96/128)
Installation and Operation Manual
Andel Limited
Unit 1 Dodworth Business Park South,
Upper Cliffe Road,
Dodworth,
Barnsley
S75 3SP
Tel +44 (0) 1484 845000
Tel +44 (0) 1484 845222
www.andel.co.uk
FL 128 Multizone System 15.01.2021 1
Advertisement
Table of Contents
Related Manuals for Andel Floodline 32
Summary of Contents for Andel Floodline 32
-
Page 1: Floodline
Floodline Leak and Flood Detection Systems 128 Multi Zone Leak Detection System - 32/64/96/128) Installation and Operation Manual Andel Limited Unit 1 Dodworth Business Park South, Upper Cliffe Road, Dodworth, Barnsley S75 3SP Tel +44 (0) 1484 845000 Tel +44 (0) 1484 845222 www.andel.co.uk... -
Page 2: Table Of Contents
Contents Floodline ......................1 Introduction ......................6 Floodline 128 Multi-Zone System ................ 6 Floodline Sensors ....................8 Principle of Operation ..................9 Floodline 128 Control System ................9 Base Unit ......................9 Introduction ......................9 Mounting Floodline 128 Base Unit ..............10 Connection of Mains Supply ................ - Page 3 Set Relay Status ....................20 Engineers Menu (Access code) ................20 View Events Log ....................21 Read Zone Resist ....................22 Next Page (Engineers Menu Page 1) ..............23 Previous Page (Engineers Menu Page 2) ............23 Set Zone Message ....................23 Set Leak Threshold .....................
- Page 4 Introduction ....................... 35 Fix & Connecting to Floodline Panel and Junction Boxes ........36 Returning Sensor to Use ..................37 Question/Answers ..................... 37 Point Sensors (Horizontal and Vertical) ............. 37 Introduction ....................... 37 Fixing ........................38 Connecting to the Floodline Panel ..............38 Returning Sensor to Use ..................
- Page 5 Returning Sensor to Use ..................42 Using other, non-liquid, types of sensors with the Floodline system ....43 Remote Alarm ....................43 Introduction ....................... 43 Installation ......................43 Operation ......................43 Maintenance – Day to Day ................. 43 Yearly ......................... 44 Appendix A Base Unit Motherboard Layout ............
-
Page 6: Introduction
Introduction Floodline leak detection systems are designed to detect water/liquid leaks within buildings. The alarms generated by the Floodline systems allow early action to be taken to prevent damage, reduce disruption and limit loss caused by unnoticed leaks. Floodline systems are installed in sensitive and critical areas to give early warning of leakage from any source and typical installations include modern offices, call centres, historic buildings, communication rooms, dealing rooms, etc. - Page 7 When a zone or certain system alarms are detected a full text message of the nature of the alarm is displayed on the control unit’s LCD, a red LED indicator flashes and buzzer sounds. Any person pressing the MUTE button can silence the buzzer, but this does not cancel the alarm or clear any of the visual alarms.
-
Page 8: Floodline Sensors
In the event of an alarm the appropriate relays activate providing a “clean contact” output for connection to a remote monitoring system, BMS etc. Although the mute button being pressed can silence the buzzer the relay outputs can only be cancelled by using the control unit’s menus. The standard output relays can also be linked and the three options available are: 1. -
Page 9: Principle Of Operation
Principle of Operation The Floodline system works from the principle that water, or other conductive liquid must touch one or more of the sensors for an alarm to be activated. (Any liquid will activate the OIL Sensor). The system essentially detects differences in loop resistance on each of its zone inputs. The leak detection and system fault alarms are activated when the loop resistance falls between, below or above set limits as detailed below. -
Page 10: Mounting Floodline 128 Base Unit
A retaining clip is provided with the IEC plug to ensure it is not accidentally disconnected. The Floodline 128 must be provided with an EARTH (Ground) to ensure correct operation and for safety reasons. If the base unit is not correctly earthed Andel Limited cannot guarantee correct operation of the system. -
Page 11: 32 -Zone Leak Detection Module
32 –Zone Leak Detection Module The 32-zone leak detection module are house in card slots within the base unit and connect to the motherboard via a ribbon cable. A read indicator on each module shows that it is connected. The base unit can handle up to four 32-zone leak detection modules giving a total of 128 zone if required. - Page 12 Alarm Active Indicator Mute Button Display Window Up Scroll Key Menu Access Key Menu Key Down Scroll Key Enter Key Leak Alarm A leak alarm is generated on a per zone bases when the loop resistance of the zone falls below the set limit as set by the engineer at time of commissioning.
-
Page 13: Short Circuit Alarm
Short Circuit Alarm A short circuit alarm is generated on a per zone bases when the loop resistance of the zone falls below 1k ohm. When a short circuit alarm is generated the audible alarm in the control unit is activated, the alarm indicator on the control unit flashes and the display window indicates the zone in which the alarm was activated as shown below. -
Page 14: Module Communications Failure Alarm
Module Communications Failure Alarm A module communication failure alarm is generated on a per module bases (module 1 to 5) when communications between the base unit’s motherboard and one of the 32 zone leak detection modules or communications module has failed. When a module communications failure alarm is generated the audible alarm in the control unit is activated, the alarm indicator on the control unit flashes and the display window indicates the module number as shown below. -
Page 15: Display Disconnected Alarm
Display Disconnected Alarm A display-disconnected alarm is generated if the physical connection between the base unit and the control unit is lost. When a display disconnected alarm is generated the audible alarm within the base unit pulses, the self-test relay activates if relays are armed, and the “Display Disconnected” indicator on the front of the base unit activates. -
Page 16: Remote Disconnected
Remote Disconnected This alarm is generated when the remote alarm (if connected) is disconnected. When a remote disconnected alarm is generated the audible alarm in the control unit is activated, the alarm indicator on the control unit flashes and the display window indicates that the remote has been disconnected as shown below. The self-test relay in the base unit will also activate if the relays are armed. -
Page 17: Menu Options
> The ‘ > ‘ character on the left identifies the menu item which will be actioned when the enter key is pressed. To Scroll through the available options use the up and down scroll keys and the ‘ > ‘ character will move up and down the available option. - Page 18 Once the system has reset “System Reset” will be displayed for a period of 1 second on the display after which the user menu will again be displayed as shown below. Set Date Time Allows the user to change the data and time of the real time clock contained within the base unit. To select this option, move the ‘>’...
- Page 19 Next Page (User Menu page 1) Selects user menu page 2. To select this option, move the ‘>’ character on the far left using the up and down scroll keys until it is opposite “Next Page” on the display then press the enter key. Once this item has been selected the display will change to user menu page 2 as shown below >...
-
Page 20: Set Relay Status
The far-left character of the code will be flashing and is the character to be change first. Note: The access code is issued by Andel Limited and cannot be change. FL 128 Multizone System 15.01.2021 20... -
Page 21: View Events Log
The access codes individual characters can be in the range ‘a’ – ‘z’ and ‘0’ –‘9’ and are selected using the up and down scroll keys. The engineer starts by selecting the far left character and once the required character is displayed pressing the enter key selects that character the remaining three character are selected in the same manner. -
Page 22: Read Zone Resist
Read Zone Resist Allows the engineer to take resistance readings in k ohms of the loop resistance of each zone connected to the system. To select this option, move the ‘>’ character on the far left until it is opposite “Read Zone Resist” on the display then press the enter key. -
Page 23: Next Page (Engineers Menu
Next Page (Engineers Menu Page 1) Selects Engineers menu page 2. To select this option, move the ‘>’ character on the far left using the up and down scroll keys until it is opposite “Next Page” on the display then press the enter key. Once this item has been selected the display will change to engineer’s menu page 2 as shown below >... -
Page 24: Set Leak Threshold
To change the currents character, use the up and down scroll keys to scroll through the available characters and once the required character is displayed press the enter key to select that character for that position. The flashing cursor will then move to the next character on the line. The Character which are available are A to Z, 0 to 9 and a space. -
Page 25: Floodline 128 Communications Module Instructions
Floodline 128 Communications Module Instructions The Floodline 128 communications module supports both RS232 and RS485 for connection to BMS etc. It interfaces to the systems motherboard via a 20Way-ribbon cable and must be connected to JP5 that is reserved for this purpose. The baud rate for both the RS232 and RS485 is set at 4800 and the data format is No parity, 8 data bits and 1 stop bit. - Page 26 Byte No Description Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Short Crt. Z 17 - 24 Short Crt. Z 25 - 32 Short Crt. Z 33 – 40 Short Crt. Z 41 – 48 Short Crt.
-
Page 27: Query Format
Query Format All queries sent to the Floodline 128 have the same format as detailed in the table below: Field Name Value (HEX) Notes Start Character Each query must start will this character Slave Address Address of Floodline comms. module Start Address 0 to 39 Index into status bytes 0 to 57 decimal... -
Page 28: Exception Codes
Exception Codes The comms module returns 3 exception codes if the command received is invalid and these are given in the table below. Exception Code Description Invalid start address (address greater than 57 decimal) Invalid end address (no. Bytes too large, i.e. start address add number of bytes greater that 58 decimal) Stop Character missing The 7th bit of the return start address is set to logic 1 if any exception is generated (see sample below). -
Page 29: Single Zone Detection (Sensing) Tape
Single Zone Detection (Sensing) Tape Introduction The Single Zone Detection Tape is the simplest of all the Floodline detection sensors and is a low-cost solution where a large amount of basic leak detection is required. It is very absorbent and will therefore react to the smallest amount of liquid. -
Page 30: Returning Sensor To Use
Returning Sensor to Use The single zone detection tape can be wetted and dried any number of times as long as it does not become contaminated with a substance which irrevocably changes its electrical characteristics. Eg.vending machine syrup, some chemical floor treatments, paint etc. The detection tape will dry out naturally and the effected part of the cable must be completely dry before the zone can be reset. -
Page 31: Fixing
Fixing The detection cable is laid flat on the floor in the pre-determined pattern and special 4 Zone Junction Boxes are used to connect the detection cable “string” to the leader cable coming from the control panel and at the start of each subsequent zone in turn. A further junction box is used at the end of line. The detection cable is usually fixed with screwed “P”... -
Page 32: Returning Sensor To Use
Colour coding – Connection within the Control Panel Colour of Detection Cable Core Colour of Leader Cable Core Zone Inputs Connections Identification White and Blue wrapped Blue White wrapped White Black Black Yellow Yellow next “string” White and Blue wrapped Blue White wrapped White... -
Page 33: Fixing
The multi-8-zone detection cable should not be tie-wrapped to pipes (– use multi-4 Zone detection cable instead) As with all Floodline sensors water contacting the cable changes its electrical characteristics (resistance) and when the change is sufficient the Floodline control panel, to which the sensor is connected will generate the appropriate alarm. - Page 34 Please note the 2 black core of the detection cable must not touch, as this will cause a short circuit alarm because the back is not an insulator. Colour coding – Connection within 8 Zone Junction Box Colour of Detection Cable Core Colour of Leader Cable core Junction Box Terminal Identification...
-
Page 35: Returning Sensor To Use
Colour coding – Connection within the Control Panel Colour of Detection Cable Core Colour of Leader Cable Zone Input Terminal core Identification Black 1 (Between Blue and Green Cores) Black Black 2 (Between Yellow and White Cores) Brown Blue Blue White White Purple... -
Page 36: Fix & Connecting To Floodline Panel And Junction Boxes
The M8- detection cable should not be tie-wrapped to pipes (– use M4 detection cable instead) As with all Floodline sensors water contacting the cable changes its electrical characteristics (resistance). When the change is sufficient an appropriate alarm will be generated at the Floodline panel. The M8 detection cable has an outside diameter of 4.5mm. -
Page 37: Returning Sensor To Use
Note: The zone numbers are for the zones on the string. When more than 8 zones are used you simply connect the cores into the appropriate zone numbers (i.e. zone 1+, - can be wire to zone 17 +, - or any other zone). -
Page 38: Fixing
Where it is not possible to fix to the wall surface or other convenient surface the assembly can be bolted to struts or other fabricated bracket and special right angle supports are available from Andel. The Horizontal Point Sensor must be used in conjunction with a guard plate and can be mounted on any flat surface with the tips of the sensing probes facing downwards. -
Page 39: Returning Sensor To Use
A diagram of the connection details for the point sensors is presented in Appendix E. Once the point sensor, or last sensor in a string has been connected to the leader cable the 1M “sleeper” resistor, from the zone input terminals in the control panel, should be fitted to the output terminals of the point sensor. -
Page 40: Returning Sensor To Use
Returning Sensor to Use Flexi-pad sensors can be wetted and dried any number of times provided the sensor element/ fabric cover is not contaminated with a substance that irrevocably changes its electrical characteristics. An example may be vending machine syrup, chemical floor treatments paint etc. After activation, the fabric cover can be replaced with a spare or removed for drying. -
Page 41: Oil Sensor
Oil Sensor Introduction The Floodline oil sensors can be used with a Floodline Control Panel to provide a dedicated oil leak alarm system or as part a larger water leak detection system. The oil sensor is usually mounted vertically and activates when oil (or any other liquid) touches the infra-red sensing dome at its base. -
Page 42: Returning Sensor To Use
Colour of Leader Cable Core Function Panel Terminal Identification + 12 Vdc supply AUX O/P 12V Black 0Vdc supply AUX O/P 0V Blue Zone input connection Yellow Zone input connection “n” + (n = 1 to 32) Returning Sensor to Use Oil sensors require no attention after activation and once the oil (or other liquid) is no longer in contact with the sensor dome the sensor will automatically reset. -
Page 43: Using Other, Non-Liquid, Types Of Sensors With The Floodline System
Using other, non-liquid, types of sensors with the Floodline system The flexibility of Floodline allows certain types of detection devices other than water/liquid sensors to be connected to the system. These could be temperature or humidity sensors and some smoke detectors etc. There are certain restrictions which must be observed such as not exceeding the available power and the ability to latch, or hold, a set of clean contacts for sufficient length of time for the Floodline Control Panel to recognise the alarm. -
Page 44: Yearly
Yearly It is recommended that the system is checked on an annual basis and costs can be forwarded to incorporate the following schedule: This inspection involves a complete Panel function re-test in accordance with our factory testing schedule for all new Panels. •... -
Page 45: Appendix A Base Unit Motherboard Layout
Appendix A Base Unit Motherboard Layout FL 128 Multizone System 15.01.2021 45... -
Page 46: Appendix B Single Zone Tape Connection Details
Appendix B Single Zone Tape Connection Details FL 128 Multizone System 15.01.2021 46... -
Page 47: Appendix C Multi-4-Zone Detection Cable Connection Details
Appendix C Multi-4-Zone Detection Cable Connection Details FL 128 Multizone System 15.01.2021 47... - Page 48 FL 128 Multizone System 15.01.2021 48...
-
Page 49: Appendix D Multi-8-Zone Detection Cable Connection Details
Appendix D Multi-8-Zone Detection Cable Connection Details FL 128 Multizone System 15.01.2021 49... - Page 50 FL 128 Multizone System 15.01.2021 50...
- Page 51 FL 128 Multizone System 15.01.2021 51...
-
Page 52: Appendix D-1 Multi-8-Zone Plug & Play
Appendix D-1 Multi-8-Zone Plug & Play CONNECTIONS TO ALARM PANEL Z0NE/SENSOR INPUT TERMINALS PATCH LEADER CABLE FLOODLINE JUNCTION BOX FLOODLINE JUNCTION BOX FLOODLINE JUNCTION BOX Auto- Coupler Auto- Coupler STRING REFERENCE STRING REFERENCE STRING REFERENCE ZONE ZONE ZONE ZONE ZONE ZONE Zone 1 M8-Detection Cable Zone 2 M8-Detection Cable... -
Page 53: M8 Plug & Play Cable Plug Connection Details
M8 Plug & Play Cable Plug Connection Details HEAT SHRINK BLUE WHITE BROWN LEADER CABLE PURPLE ORANGE BLACK GREEN YELLOW HEAT SHRINK BLUE WHITE BLACK 2 M8 DETECTION PURPLE ORANGE CABLE BLACK 1 GREEN YELLOW Note Black 1 is between Blue and Green core Black 2 is between Yellow and White core The 2 Black cores are conductive polymer they must note be allowed to touch each other as this will cause an alarm. -
Page 54: Appendix E Point Sensor Connection Details
Appendix E Point Sensor Connection Details FL 128 Multizone System 15.01.2021 54... -
Page 55: Appendix F Flexi-Pad Sensor Connection Details
Appendix F Flexi-pad Sensor Connection Details FL 128 Multizone System 15.01.2021 55... -
Page 56: Appendix G Pipe-In-Pipe Sensor Connection Details
Appendix G Pipe-in-pipe Sensor Connection Details FL 128 Multizone System 15.01.2021 56... -
Page 57: Appendix H Oil Sensor Connection Details
Appendix H Oil Sensor Connection Details FL 128 Multizone System 15.01.2021 57... -
Page 58: Appendix I (Overflow/Tundish Connection Details)
Appendix I (OVERFLOW/TUNDISH Connection Details) FL 128 Multizone System 15.01.2021 58... -
Page 59: Appendix J Remote Alarm Connection Details
Appendix J Remote Alarm Connection Details FL 128 Multizone System 15.01.2021 59...
